STAND-TV70A Dark Walnut Easel Studio TV Stand

Product Information

The Dark Walnut Easel Studio TV Stand is a versatile and stylish
stand that can hold flat screen TVs up to 88lbs or 40kg. It comes
with a base, two poles, four legs, upper and lower VESA brackets,
and various screws, washers, and spacers for assembly. The product
also includes security cables and clips for added safety.

The stand is designed to be assembled with a Phillips
screwdriver, drill, tape measure, level, and pencil. It should not
be installed into drywall alone and must be mounted on wood studs
or using the included hardware for brick and concrete walls.

It is important to note that the product has a weight capacity
limit of 88lbs or 40kg, and failure to adhere to this limit may
result in serious injury.

Product Usage Instructions

Start by screwing the legs (C) into the base (A).
Screw the poles (B) onto the top of the base.
Loosen the support rings on the poles using the 4mm Allen
wrench (H). Adjust rings to hold TV at desired height, using a tape
measure to ensure the rings are adjusted evenly, and tighten with
the 4mm Allen wrench (H). Note that the rings should be at least 2
inches below the tops of the poles.
Remove screws from lower VESA bracket (E) and open clamps.
If your TV has a flat back, position upper (D) and lower (E)
VESA brackets horizontally on the back of the TV. Make sure that
the upper bracket is on top and the lower bracket is below. Secure
using screws (M-A or M-B) with square washers (M-F) and D5 washers
(P-G), with security clips (P-B) installed to top holes. If your TV
has a curved back, use screws (M-C, M-D, or M-E) with square
washers (M-F) and spacers (M-G, M-H) with security clips (P-B)
installed to top holes.
Slide the TV with VESA brackets (D, E) onto poles. Close the
clamps on the lower VESA bracket over the poles and secure with
previously removed screws.
Peel backing from cable clips (G) and install clips on rear
legs. Use clips to organize cables. Optional: Secure cable clips
using 3/8 screws (F). Screws are able to thread directly into wood
without drilling pilot holes.

For further assistance or questions regarding installation,
contact VIVO-US at [email protected] or call 309-278-5303.

View Fullscreen

Dark Walnut Easel Studio TV Stand
Instruction Manual

SKU: STAND-TV70A
Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv70a
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

[email protected]

www.vivo-us.com Chat live with an agent!

309-278-5303

WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or inappropriate use.
TIPOVER WARNING
SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER:
· NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF TV OR TV STAND. · USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL
USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIPOVER.
PACKAGE CONTENTS

A (x1) Base
F (x6) ST4.2×12
Screw
M-C (x4) M6x30

B (x2) Pole
G (x6) Cable Clip
M-D (x4) M8x30

C (x4) Leg
H (x1) 4mm Allen
Wrench

D (x1) Upper VESA
Bracket

E (x1) Lower VESA
Bracket

M-A (x4) M5x14

M-B (x4) M6x14

M-E (x4) M8x50

M-F (x4) Metal Spacer

M-G (x8) Small Spacer

M-H (x8) Big Spacer

P-A (x1) Security
Cable

P-B (x2) Security
Clip

P-C (x2) Security Cable
Clamp

P-D (x1) 2mm Allen
Wrench

P-E (x4) ST4.8×38 Screw

P-F (x4) Concrete Anchor

P-G (x2) D5 Washer

NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED
WARNING: CHOKING HAZARD
SMALL PARTS – NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.

DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
2

88lbs (40kg)

TOOLS NEEDED

Phillips Screwdriver

Drill

Tape Measure

Level

Pencil

CAUTION!
DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting hardware for brick and concrete walls. If unsure, please contact us at vivo-us.com, email at [email protected], or call us at 309-278-5303.
ASSEMBLY STEPS
STEP 1
Screw the legs (C) into the base (A).
A

C
STEP 2
Screw the poles (B) onto the top of the base.
B

Re com men de d 50 -150 mm

STEP 3
Loosen the support rings on the poles using the 4mm Allen wrench (H). Adjust rings to hold TV at desired height, using a tape measure to ensure the rings are adjusted evenly, and tighten with the 4mm Allen wrench (H). NOTE: Rings should be at least 2″ below the tops of the poles.
H N··NPMsbouobertfeteoleeaer:tk:faehPoesealreestestauscaasercreethecwtsiautnechchrgeouhetlrihtesenehsgcteTfhratVeelchwoesloeccbhcrkTaekioceinVnklngegsw.sccMcaofraordalekllcsaleea.renr .
ba ck wa rds.
STEP 4
Remove screws from lower VESA bracket (E) and open clamps.
E2 E1
4

STEP 5
OPTION A: Flat Back Monitor Position VESA brackets horizontally on the back of the TV, making sure upper VESA bracket (D) is on top and lower VESA bracket (E) is below. Secure using screws (M-A or M-B) with square washers (M-F) and D5 Washers (P-G), with security clips (P-B) installed to top holes.

MjM- A-JA^ Pm-GGJd MPm–FBJ_ Mj -FJc

MjM–BBJ_ MmP–GBFJ_ Mj -FJc

D E1

M- A M- F

M- B M- F

OPTION B: Curved Back Monitor Position VESA brackets horizontally on the back of the TV, making sure upper VESA bracket (D) is on top and lower VESA bracket (E) is below. Secure using screws (M-C, M-D or M-E) with square washers (M-F) and spacers (M-G, M-H) with security clips (P-B) installed to top holes.
M- G
M- H

D E1

M- C

M- D

M- E

P-BG

M- F

M- C

M- E

M- D

M- F

STEP 6
Slide the TV with VESA brackets (D, E) onto poles. Close the clamps on lower VESA bracket over the poles and secure with previously removed screws. Peel backing from cable clips (G) and install clips on rear legs. Use clips to organize cables. Optional: Secure cable clips using 3/8″ screws (F). Screws are able to thread directly into wood without drilling pilot holes.
1 2
3 E2
1 IG
2 JF
3
6

STEP 7
OPTION A: Wood Stud Wall Using Security Cable Clamps (P-C) as guides, mark drilling locations on wall at the same height as the upper VESA bracket. Use of a stud finder is recommended. Drill holes at least 1.6″ (40mm) deep using a 1/8″ (3mm) drill bit. Mount clamps to wall using ST4.8×38 screws (P-E). Thread security cable (P-A) through security clips on TV and center holes in cable clamps as shown, then tighten clamps using the 2mm Allen wrench (P-D).
OPTION B: Concrete/Brick Wall Using Security Cable Clamps (P-C) as guides, mark drilling locations on wall at the same height as the upper VESA bracket, spaced 400mm – 650mm (16″ – 26″) apart. Drill holes at least 1.6″ (40mm) deep using a 9/32″ (7mm) drill bit. Insert concrete anchors (P-F) into holes and mount clamps to wall using ST4.8×38 screws (P-E). Thread security cable (P-A) through security clips on TV and center holes in cable clamps as shown, then tighten clamps using the 2mm Allen wrench (P-D).
7

Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us

LAST UPDATED: 09/02/2022 REV4.1
