Circa LED Ceiling Lamp
Product Information
The product is called CIRCA FLUSH, a 120V fixture designed for
installation on ceilings or walls. It is available in the color
black. The assembly and installation instructions for this product
can be found on page 33 of the user manual.
The CIRCA FLUSH model comes in four configurations:
- CIRCA FLUSH DIRECT (CEILING MOUNTED)
- CIRCA FLUSH INDIRECT (CEILING MOUNTED)
- CIRCA FLUSH DIRECT (WALL MOUNTED)
- CIRCA FLUSH INDIRECT (WALL MOUNTED)
Note that the instructions provided in the manual demonstrate
the installation process for the CIRCA FLUSH DIRECT CEILING MOUNTED
configuration. However, the same instructions can be followed for
all the configurations listed above.
The product includes the following components:
- A TRANSFORMER
- B MOUNTING PLATE
- C JUNCTION BOX SCREWS
- D CANOPY SCREWS
- E CANOPY COVER
- F LAMP HEAD
For any inquiries, you can contact the manufacturer at
[email protected] or visit their website at
PABLODESIGNS.COM.
Product Usage Instructions
- Connect the building wiring to the 2-pole connector on the AC
input side of the transformer.
Ensure the wire colors match across the two-pole connector.
Wire Colors: White (AC input), Black (AC
input) - Connect the fixture wiring on the mounting plate to the 2-pole
connector on the DC output side of the transformer.
Ensure the wire colors match across the two-pole connector.
Wire Colors: Red (DC output), Black (DC
output) - Tuck the transformer and wiring into the junction box and screw
the mounting plate into the junction box using the provided machine
screws. - Fasten the canopy cover to the mounting plate using the
provided machine screws.
Ensure the transformer is positioned with the sticker facing
out. - To assemble the fixture head, hold the outside of the shade
with both hands and screw it into the canopy assembly. - If bulb replacement is required, use an LED flat panel bulb.
Contact the manufacturer for specific instructions on bulb
replacement.
An electronic low voltage dimmer is recommended for this
product.
CIRCA
FLUSH
120V
ASSEMBLY & INSTALLATION INSTRUCTIONS
BLACK
pg. 33
CIRCA FLUSH 120V ASSEMBLY INSTRUCTIONS
CIRCA FLUSH
IMPORTANT: WE RECOMMEND FIXTURE BE INSTALLED BY AN ELECTRICIAN WARNING: FIXTURE MUST BE WIRED CORRECTLY OR RISK DAMAGE TO COMPONENTS CIRCA FLUSH MODELS:
CIRCA FLUSH DIRECT (CEILING MOUNTED)
CIRCA FLUSH INDIRECT (CEILING MOUNTED)
CIRCA FLUSH DIRECT (WALL MOUNTED)
CIRCA FLUSH INDIRECT (WALL MOUNTED)
NOTE: INSTRUCTIONS SHOW INSTALLATION OF CIRCA FLUSH DIRECT CEILING MOUNTED, FOLLOW THE SAME INSTRUCTIONS FOR ALL CONFIGURATIONS LISTED ABOVE
COMPONENT LIST
A
A TRANSFORMER B MOUNTING PLATE C JUNCTION BOX SCREWS D CANOPY SCREWS E CANOPY COVER F LAMP HEAD
D
B
C
F
E
1 CONNECT BUILDING WIRING TO 2 POLE CONNECTOR ON AC INPUT SIDE OF TRANSFORMER
PUSH DOWN TAB AND INSERT WIRES INTO HOLES AS SHOWN THEN RELEASE TAB TO LOCK WIRES INTO POSITION
WHITE BLACK
ENSURE WIRE COLORS MATCH ACROSS THE TWO POLE CONNECTOR
pg. 34
CIRCA FLUSH 120V ASSEMBLY INSTRUCTIONS
CIRCA FLUSH
2 CONNECT FIXTURE WIRING ON MOUNTING PLATE TO 2 POLE CONNECTOR ON DC OUTPUT SIDE OF TRANSFORMER
RED BLACK
RED BLACK
ENSURE WIRE COLORS MATCH ACROSS THE TWO POLE CONNECTOR
TUCK TRANSFORMER AND WIRING INTO JUNCTION BOX AND SCREW MOUNTING PLATE INTO JUNCTION BOX USING PROVIDED MACHINE SCREWS
4 FASTEN CANOPY COVER TO MOUNTING PLATE USING
PROVIDED MACHINE SCREWS
ENSURE TRANSFORMER IS POSITIONED WITH STICKER FACING OUT
5 HOLD OUTSIDE OF SHADE WITH BOTH HANDS AND SCREW FIXTURE HEAD INTO CANOPY ASSEMBLY
BULB TYPE LED FLAT PANEL BULB REPLACEMENT CONTACT MANUFACTURER FOR BULB REPLACEMENT ELECTRONIC LOW VOLTAGE DIMMER RECOMMENDED pg. 35
CIRCA
FLUSH
pg. 36
[email protected] 888 MARIN STREET SAN FRANCISCO, CA 94124
PABLODESIGNS.COM
Pablo
