Vevor Bt-fl14a Ventilation Fan User Manual

BT-FL14A Ventilation Fan

Product Information:

The Ventilation Fan is a product offered by VEVOR. It is a
high-quality fan designed to improve air circulation and
ventilation in various spaces. It is important to read the user
manual carefully before operating the fan to ensure proper usage
and safety.

Technical Specifications:

• Brand: VEVOR
• Model: BT-FL14A
• Voltage: 120 V
• Frequency: 60 Hz
• Power: 31 W
• Speed: 2550 RPM
• Duct Size: 100/125
• Power Cord Length: 1.6 M
• Working Ambient Temperature: -10~45 °C

Product Usage Instructions:

Installation:

Prepare the following tools in advance: Cross screwdriver,
Hammer.

Installation Method – Step 1:

1. Use a Phillips screwdriver to unscrew and loosen the plastic
   buckle (refer to Fig.1).
2. Remove the motor box assembly from the flange bracket (refer to
   Fig.2).
3. Use the flange bracket to set your desired fan position. Mark
   the four mounting holes (refer to Fig.3).
4. Drill four holes into the marked locations, ensuring that your
   mounting area is structurally sound and free from obstruction
   (refer to Fig.4).

Installation Method – Step 2:

1. If you are mounting onto anything other than a wood support or
   stud, insert the included four wall anchors into the drilled
   mounting holes. You may need to use a hammer to secure them through
   the holes (refer to Fig.5).
2. Paste the cushion onto the flange bracket, aligning the hole of
   the cushion with the hole of the flange bracket (refer to
   Fig.6).

Please ensure that you follow these installation steps carefully
to ensure proper setup and functionality of the Ventilation
Fan.

VENTILATION FAN USER MANUAL
We continue to be committed to provide you tools with competitive price. “Save Half”, “Half Price” or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and doses not necessarily mean to cover all categories of tools offered by us. You are kindly reminded to verify carefully
when you are placing an order with us if you are actually saving half in comparison with the top major brands.

-1-

VENTILATION FAN
<Picture Only For Reference> NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us: [email protected]
This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appear- ance of the product shall be subject to the product you received. Please forgive us that we won’t inform you again if there are any technology or software updates on our product.
-2-

Contents
SAFETY PRECAUTIONS PRODUCT DESCRIPTION INSTALLATION DIMENSION AND SPECIFICATION POWERING AND SETUP CLEANING PROGRAMMING FAQ ATTENTIONS

WARNING

SAFETY PRECAUTIONS
Improper operation may cause personal injury. Improper operation may cause damage to the machine. Improper operation may cause others object damage. The symbol indicates that the user should pay high attention to and pay attention to the drawing shows the situation to be noted, and the left figure shows “Be careful of electric shock”
Disconnect the fan when moving from one location to another.

Do not use a power supply that does not meet the rated voltage The use of non compliant power supplies can cause fire or electric shock. If the machine emits smoke, odor, motor noise and other abnormal conditions,Please do not use it. It may cause fire or electric shock Do not disassemble, repair or rectify the machine during use.Doing so may result in fire or electric shock and personal injury

-3-

BE CAREFUL DO NOT use fan in window. Rain may create electrical hazard. Do not damage or arbitrarily change the original power cord, and do not bend, forcibly pull, bind or press the power cord under heavy objects.This will damage the power cord, causing electric leakage fire or electric shock If the machine is not used for a long time, please unplug the power cord from the socket If the power cord is damaged, contact your local service center or a qualified electrician to install an appropriate replacement cord to prevent any injury or damage Never insert fingers, pencils, or any other object through the guard when fan is running. When the power cord is unplugged from the socket, the plug should be unplugged. Do not pull the power cord to forcibly pull the wire, which may cause damage to the wire and lead to leakage or electric shock Please disconnect the power supply when cleaning
-4-

PRODUCT DESCRIPTION TECHNICAL PARAMETER

Brand

Model

BT-FL14A

Voltage

120 V

Frequency

60 Hz

Power

31 W

Speed

2550 RPM

Duct Size

100/125

Power Cord Length

1.6 M

Working Ambient Temperature

-10~ 45

PRODUCT STRUCTURE DIAGRAM

BT-FL16A 120 V 60 Hz 60 W
2600 RPM 150/160
1.6 M
-10~ 45

BT-FL18A 120 V 60 Hz 126 W
2500 RPM 200 1.6 M
-10~ 45

-5-

INSTALLATION Prepare tools in advance: Cross screwdriver, Hammer
-6-

Installation method: Step 1
1Unscrew and loosen the plastic buckle using a Phillips screwdriver See the(Fig.1.) 2Remove the motor box assembly from the flange bracket.See the(Fig.2.) 3Use the flange bracket to set your desired fan position. Mark the four mounting
holes.See the (Fig.3.) 4Drill four holes into the marked locations. Make sure your mounting area is
structurally sound and free from obstruction.See the(Fig.4.)

Fig.1.

Fig.2.

Fig.3.

Fig.4.

-7-

Step 2:
1If you are mounting onto anything other than a wood support or stud, insert the included four wall anchors into the drilled mounting holes. You may need to use a hammer to secure them through the holes. See the (Fig.5.)
2Paste the cushion onto the flange bracket to ensure that the hole of the cushion is aligned with the hole of the flange bracket. See the (Fig.6.)
3Align the flange bracket’s holes with the wall anchors. Screw in four wood screws with a screwdriver or drill to secure the flange bracket.Make sure its airflow arrow is pointing in your desired direction.See the (Fig.7.)
4Slide the motor box back into the flange bracket, making sure its airflow arrow is pointing in the same direction as the flange bracket’s arrow.See the (Fig.8.)

Fig.5.

Fig.6.

Fig.7.

Fig.8.
-8-

5Place the plastic clamps back onto the flanges and tighten the screws back to secure the motor box. See the (Fig.9.)
Fig.9.
Step 3
1If installing ducting, purchase a suitable duct and duct clamp and secure it to both ends of the fan to ensure tight sealing. Finally tighten the air duct clamp with a screwdriver.See the (Fig.10.)
2If installing with rope hangers, loop the ropes around the flanges and tighten the rope to secure the fan.See the (Fig.11.)
3Connect the power cord, turn on the switch to check whether the fan is running, then finish the installation.

Fig.10.

Fig.11.

-9-

1Dimension

DIMENSION

– 10 –

HOW TO USE
Speed control
The controller has a button, and the fan speed is stepless.Turn the button to adjust the wind speed from the highest to the lowest, and select the wind speed you need.See the(Fig.12.)
Fig.12. Tip:Slight motor sound is normal when running at low speed
MAINTENANCE 1. Regular maintenance is needed each year. Please power off before maintaining 2. Please DO NOT use such chemicals as gasoline, benzene and diluent to wipe the fan 3. Please DO NOT let water into motor and electric parts, and make the plastic parts in merge into water with temperature higher than 60 4. This appliance can be used by children aged from 12 years and above and persons with reduced physical sensory or mental capabilities or lack of experience and know edge if they have been given supervision or instruction concerning use of the appliance in a safe way an understand the hazards involved Children shall not play with the appliance. Clean and user maintenance shall not be made by children without supervision 5. If the power line is damaged, to avoid danger, it should be changed by the factory, its maintenance department or qualified professionals.
– 11 –

CLEANING
Step 1:
Remove the motor box from the mounting flange.(Refer installation steps 1 to learn how to of the mounting installation section to learn how to remove the motor box). (Fig.13.)
Step 2:
Use a damp cloth to clear the impeller and fan blades of any dust and debris. Remove the wind circle in between the motor box and input flange. (Fig.14.)

Step 3:

Fig.13.

Fig.14.

Clear the stator blades of any dust and debris on the opposite end. Clean the area inside

the output and exhaust flanges. (Fig.15.)

Step 4:

Secure the motor box onto the mounting flanges. Refer installation step 2-3 to learn how

to flanges. secure the motor box. (Fig.16.)

Fig.15.

Fig.16.
– 12 –

ATTENTIONS
– 13 –

This product is subject to the provision of Europe an Directive 2012/19/EC. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. This applies to the product and all accessories marked with this symbol. Products marked as such may not be discarded with normal domestic waste, but must be taken to a collection point for recycling electrical and electronic devices.
