TD60004C 12 Inch 1 Light Traditional Pendant
Product Information
The product is a 1-light chandelier that requires wiring for
installation. It comes with a mounting bar, fixture chain, larger
shade, smaller shade, canopy, canopy lock ring, socket, and bulb
(not included). The chandelier has a maximum power rating of 60W
and uses an E26 lamp socket. The input voltage required is 120V,
and the cord length is 7ft. The product should be cleaned with a
soft cloth and mild soap, avoiding abrasive materials.
Product Usage Instructions
- Insert the green grounding screw into the hole with two raised
dimples on the mounting bar. - Wrap the ground wire from the fixture (if supplied) around the
green grounding screw, then connect it to ground wire from the
outlet box (if not fixed on the outlet box) using a wire connector
(not supplied). - If ground wire from the fixture is not supplied, wrap the
ground wire (if not fixed on the outlet box) from the outlet box
around the green grounding screw and tighten it. - Note the color of the wire(s) on your fixture and identify
which group your fixture wire(s) falls into (Group A or Group
B). - Connect the wires according to the directions below:
- [Group A]: Connect to Black House Wire
- [Group B]: Connect to White House Wire
against the black wire from the outlet box. Do NOT twist wires
together before using wire connectors.
clockwise until you feel firmness.
the connector off, carefully re-do steps 3 and 4 as above and check
again for a firm connection.
the outlet box in the same manner. Make sure no bare wires can be
seen outside wire connectors.
screw Loop (D) to Socket (A).
(H).
details.
(F).
Note: Always switch off the electricity supply and allow to cool
for 10 minutes before changing light bulbs.
Instruction Manual
1-Light Chandelier
Wiring Instruction
1. Insert the green grounding screw into the hole with two raised dimples on the mounting bar. Wrap the ground wire from the fixture (if supplied) around the green grounding screw, then connect it to ground wire from the outlet box (if not fixed on the outlet box) using a wire connector(not supplied). If ground wire from the fixture is not supplied, wrap the ground wire (if not fixed on the outlet box) from the outlet box around the green grounding screw and tighten it.
NEVER CONNECT GROUND WIRE TO BLACK OR WHITE POWER SUPPLY WIRES.
2.Take note of the color of the wire(s) on your fixture. Identify which group your fixture wire(s) falls into and connect the wires according to the directions below:
Overview
Outlet box Green(Ground)
Wire nuts Bare copper wire(Ground)
D.Loop
Black Smooth
[GROUP A]White Ribbed
[GROUP B]I.Mounting strap
H.Screw
G.Canopy
F.Canopy lock ring
E.Fixture chain
A.Socket B.Larger shade
[GROUP A]: Connect to Black House Wire [GROUP B]: Connect to White House WireBLACK
WHITE
*PARALLEL WIRE (round & smooth) *PARALLEL WIRE (square & ridged)
WHITE OR GREY WITH TRACER WHITE OR GREY WITHOUT TRACER
BROWN, GOLD OR BLACK WITHOUT TRACER
BROWN, GOLD OR BLACK WITH TRACER
3.Take your fixture wire(s) from [Group A] and place evenly against the black wire from the outlet box. Do NOT twist wires together before using wire connectors. 4.Fit a wire connector over the wires and screw the connector clockwise until you feel firmness. 5.Try gently to pull the connector off the wires. If you can pull the connector off, carefully re-do steps 3 and 4 as above, and check again for a firm connection.
6.Connect the fixture wire from [Group B] to the white wire from the outlet box in the same manner. Make sure no bare wires can be seen outside wire connectors.
Product Specifications
C.Smaller shade
J.Bulb(not included)
Assembly Instruction
1.Pass the wire through the hole in the top of Larger shade (B), screw Loop (D) to Socket (A).
2.Link Loop (D) and Mounting strap (I) by Fixture chain (E). 3.Attach the Mounting strap (I) to outlet box with Screws (H). 4.Connect the wires according to the picture above.
(Please refer to the wiring instruction for details ) 5.Fix Canopy (G) to Mounting strap (I) with Canopy lock ring (F). 6.Install light bulb (not included). Use one E26 base bulb. 7.Hang Smaller shade (C) to the bottom of Larger shade (B).
Input voltage 120V Rated power 60W MAX Lamp socket E26 Cord Length 7ft.
Product Packaging
Socket × 1 Loop × 1 & Fixture chain × 1 Mounting strap × 1 & Canopy × 1 Screw × 2 & Wire nut × 3 Larger shade × 1 & Smaller shade × 1 Lamp instruction × 1
Cleaning
To clean, wipe fixture with a soft cloth. Clean glass with a mild soap. Do not use abrasive materials such as scouring pads or powders, steel wool or abrasive paper.
Safety Information
Always switch off the electricity supply and allow to cool for 10 minutes before changing the light bulbs.
