SPECIFICATION SHEET
MODE 6201
PORTABLE ELECTRIC HEATER
Low-profile design provides floor-level heat from out-of-the-way locations.
FEATURES
- Instant safety shutoff when tipped on front or back
- Selector control for high, low, or fan only
- Built-in thermostat control
- Full 1500 watts for fast warm-up
- 1200 watt economy setting
- Light, small, easy to transport
- Integrated carrying handle
- Rugged steel construction
- Easy to see indicator lights
- Overheat protection
SPECIFICATIONS
| SPEED | VOLTS | WATTS | AMPS | BTU/HR |
| Hight | 120 | 1500 | 12.5 | 5120 |
| Low | 120 | 1200 | 10.0 | 4095 |
| MODEL | PACKAGE QTY | SHIPPING WEIGHT |
| 6201 | 6 – Pack | 32 lbs. |
| 6201MD | 24 -pack | 129 lbs. |
* (MD) = Merchandise Display
TYPICAL SPECIFICATION
The heater shall be Broan Model 6201.
Unit shall have steel housing, grille, and integrated carrying handle.
Heater to have built-in thermostat control with 1500 / 1200 watt settings, power-on and caution lights, and fan-only setting.
Heater shall be U.L. listed.
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
| REFERENCE | QTY. | REMARKS | Project |
| Location | |||
| Architect | |||
| Engineer | |||
| Contractor | |||
| Submitted by Date |
