7310 Adhesive 50ml Cartridge
Product Information
The Partite 7310 Adhesive is a high-performance adhesive
designed for use on a wide variety of metal and plastic surfaces.
It is specifically formulated for small cracks, scrapes, and gouges
that do not penetrate completely through the hull of Polyethylene
and Royalex boats.
Caution: This adhesive should only be applied in a
well-ventilated area as fumes may be harmful. It is recommended to
wear rubber gloves and eye protection when using or mixing this
material.
Product Usage Instructions
- Prepare the area on your boat by cleaning it with warm water
and mild dish soap. Lightly sand the area with a 220 or 230 grit
sandpaper. Clean up any sanding residue with a rag soaked in
denatured alcohol. - If your boat is made of polyethylene, polarize the repair area
by lightly swiping a blow torch flame across the area for 2-3
seconds. The goal is to heat the area to the point where it is warm
to the touch, not to melt the canoe. This step burns off any
release agents in the powder and allows the adhesive to adhere
better. - Remove the end cap from the adhesive tube by turning it so the
long end is between the posts (see Fig# 1). - Using a piece of cardboard as a mixing tray, push on the
plunger until the desired amount of adhesive is on the tray (see
Fig# 3). It is recommended to mix a little more than needed to
ensure there is enough for the project. - Use a popsicle stick or a similar object as a stirrer to mix
the two parts of the adhesive together for about thirty seconds or
until they become one solid color (see Fig# 4). - Apply the adhesive to the desired area that needs to be
adhered. Let the adhesive set up for about five minutes, although
additional time may be required for full hardening depending on
conditions. - When finished with the Partite 7310 Adhesive, reapply the end
cap to the end of the tube for storage (see Fig# 5).
Partite 7310 Adhesive Instruction
Please read kit instructions carefully prior to installation.
125 Gilman Falls Road Building B Old Town, ME 04468 USA 800-8-KAYAKS
KIT CONTENTS
Ref. Letter
Part Number
Description
Quantity
A
01.1332.2300
Partite 7310 Adhesive
1 EA
Caution: Apply only in a well-ventilated area, fumes may be harmful. Wear rubber gloves and eye protection when using or mixing this material.
***DIRECTIONS***
Application: High performance with excellent adhesion to a wide variety of metal and plastic surfaces.
Working Time: 15 18 mins
Less on hot days more on cold days.
Fixture Time: 30 35 mins
Less on hot days more on cold days.
This adhesive is to be used for small cracks, scrapes, and gouges that do not penetrate completely through the hull on your Polyethylene and Royalex boats.
You will need to prep the area on your boat by cleaning it with warm water and mild dish soap and then lightly sanding with a 220 or 230 grit sandpaper. Clean up sanding residue with a rag soaked in denatured alcohol.
Caution: If your boat is made of polyethylene, you will need to polarize the repair area by taking a blow torch with a 1″ flame, and lightly swipe the flame across the area for 2-3 seconds. You are NOT trying to melt the canoe, just heating to the point where it is warm to the touch. This will burn off any release that is in the powder and allow the adhesive to adhere much better.
1. First remove the end cap by turning it so the long end is between the post as shown in Fig# 1, Remove cap. Using a piece of card board for a mixing tray, push on the plunger until the desired amount of adhesive is on the cardboard mixing tray. Always mix a little more than you may need to insure you have enough for your project as shown in Fig# 3.
Stop
Turn end cap so long ends are out of the stops
Fig # 1
End Cap Removed
Fig # 2
Plunger
Fig# 3
2. Use a popsicle stick or a similar object for a stirrer to stir the two parts together for about thirty seconds or until they become one solid color as shown in Fig# 4, Now the adhesive is ready to apply to the desired area that needs to be adhered. After applying let the adhesive set up for about five minuets it may take some additional time to fully harden depending on conditions.
Stir
End Cap
Fig# 4
Fig# 5
3. When you’re finished with the Partite 7310 Adhesive (A) reapply the end cap to the end of the tube for storage as shown in Fig# 5.
Rev. C Issue Date: 06/21/2013 Doc. # K- 01.1332.2300 Page 1 of 1
