345-030-520-201 Radiomag RKS Components
Product Information:
- Product Name: 345/395 Series Card Edge Connector
- Part Number: 345-030-520-201
- Contact Dimensions: 520-P.C. Tail .030x.018(0.76×0.46) –
Tail LG=.175(4.45) .100 (2.54) Contact Spacing x .200 (5.08) Row
Spacing - Contact Description: 559-90 Degree Bend (Code 541
Contacts) - Insulator Material: Thermoplastic PBT Black, UL
94V-0 - Contact Material: Copper Tin Alloy
- Contact Plating: Gold on the mating area, tin plating on
the contact tails
Product Usage Instructions:
- Ensure that the product is compatible with the intended
application. - Handle the connector with care to avoid any damage.
- Connect the appropriate wires or cables to the connector
according to the contact dimensions provided. - Ensure that the contacts are aligned properly and securely
inserted into the connector. - Make sure that the contact tails are properly positioned and
connected to the corresponding terminals or slots. - Verify that the contact plating is in good condition before
use. - Follow any additional instructions or guidelines provided by
the manufacturer for optimal usage.
Please refer to the user manual or contact the manufacturer for
further assistance or specific usage instructions.
Contact Dimensions: 520-P.C. Tail .030x.018(0.76×0.46) – Tail LG=.175(4.45) .100 (2.54) Contact Spacing x .200 (5.08) Row Spacing
1.600 40.64 1.760 44.7
THIS IS A C.A.D. GENERATED DRAWING DO NOT MAKE MANUAL REVISIONS TO MASTER.
ISSUE NUMBER
ORIGINAL
1
.600 15.24 .330 8.38 CARD SLOT .160 4.06 POINT OF CONTACT
A
.175 4.45
SECTION A-A A
345/395 SERIES CARD EDGE CONNECTOR PART NUMBER: 345-030-520-201
ACAD REFERENCE NO. 345-ENG-MASTER
DRAWN: R.STA.MONICA DATE:MAY.16/2017
CHECKED:
DATE:
·
INSULATOR MATERIAL: THERMOPLASTIC PBT BLACK, UL 94V-0
·
CONTACT MATERIAL; COPPER TIN ALLOY
·
CONTACT PLATING: GOLD ON THE MATING AREA, TIN PLATING
EDAC INC
TORONTO, ONTARIO
THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF EDAC INC.,AND SHALL NOT BE REPRODUCED,OR COPIED
SCALE: DRAWING
1:1 NUMBER
SHEET 1 OF 2 ISSUE
ON THE CONTACT TAILS, NICKEL UNDERPLATE
CANADA
OR USED AS THE BASIS FOR THE
MANUFACTURE OR SALE OF APPARATUS
YOUR CONNECTION TO QUALITY & SERVICE WITHOUT WRITTEN PERMISSION.
345-ENG-MASTER
1
Downloaded from Arrow.com.
Contact Description: 559-90 Degree Bend (Code 541 Contacts)
THIS IS A C.A.D. GENERATED DRAWING DO NOT MAKE MANUAL REVISIONS TO MASTER.
ISSUE NUMBER
ORIGINAL
1
.107 2.72
.082 2.08
.232 5.89
.157 4
.125(3.18) to .210(5.33) Outside Tails
.125(3.18) to .210(5.33) Outside Tails
.045(1.14) to .060(1.52) Between Tails
Contact Code 555
.045(1.14) to .060(1.52) Between Tails
Contact Code 556
.060
.060
.152 3.86
.235 5.97 .635 16.13
Contact Code 558
.200
.150
.362 9.19
.285 7.24 .635 16.13
.125(3.18) to .210(5.33) Outside Tails
.045(1.14) to .060(1.52) Between Tails
Contact Code 559
Contact Code 560
· · ·
INSULATOR MATERIAL: THERMOPLASTIC POLYESTER, UL 94V-0 DAP MATERIAL AVAILABLE UPON REQUEST CONTACT MATERIAL; COPPER ALLOY CONTACT PLATING: GOLD ON THE MATING AREA, TIN PLATING
345/395 SERIES CARD EDGE CONNECTOR CONTACT CODE 555,556,558,559,560 DIMENSIONS
ACAD REFERENCE NO. 345-ENG-MASTER
DRAWN: R.STA.MONICA DATE:MAY.16/2017
CHECKED:
DATE:
ON THE CONTACT TAILS, NICKEL UNDERPLATE
EDAC INC
THESE DRAWINGS AND SPECIFICATIONS
SCALE:
1:1
SHEET 2 OF 2
TORONTO, ONTARIO
ARE THE PROPERTY OF EDAC INC.,AND
SHALL NOT BE REPRODUCED,OR COPIED DRAWING NUMBER
ISSUE
CANADA
OR USED AS THE BASIS FOR THE
MANUFACTURE OR SALE OF APPARATUS
YOUR CONNECTION TO QUALITY & SERVICE WITHOUT WRITTEN PERMISSION.
345-ENG-MASTER
1
Downloaded from Arrow.com.
