JB444-1.5H-4R8 Junction Boxes
Product Information:
The Junction Boxes are designed to seal electrical connections
from moisture and other elements. They provide a convenient
location to connect all wiring required for a typical pumping
station, on-site system, or other electrical installation.
The Junction Boxes are available in different models and
sizes:
- Model: JB444-1.5H-4R8
- Size: 4 x 4 x 4
- Type: Simplex
- Connector Type: 1 1/2 HUB
- Part Number: 1008547
- Model: JB664-1.5H-4R8
- Size: 6 x 6 x 4
- Type: Simplex
- Connector Type: 1 1/2 HUB
- Part Number: 1008549
- Model: JB664-2H-5R8
- Size: 6 x 6 x 4
- Type: Duplex
- Connector Type: 2 HUB
- Part Number: 1008550
Specifications:
- Lid and Box: UL Listed and CSA Certified, made from high
impact, corrosion resistant, weatherproof thermoplastic - Gasket: Flexible PVC or neoprene
- Screws: Brass or stainless steel
Other Information:
Custom connector placement is available upon request. Please
contact your customer service representative for more information
and pricing.
Product Usage Instructions:
To use the Junction Box, follow these steps:
- Choose the appropriate model and size of the Junction Box based
on your requirements. - Ensure that the lid and box are securely fastened
together. - If necessary, install custom connectors as per your specific
needs (contact customer service for assistance). - Place the wiring connections inside the Junction Box.
- Make sure the connections are secure and protected from
moisture and other elements. - Close the lid of the Junction Box and fasten it using the
provided brass or stainless steel screws.
For any further assistance or inquiries, refer to the user
manual or contact customer service.
JUNCTION BOXES
Seals Electrical Connections from Moisture and Other Elements
Junction boxes provide a convenient location to connect all wiring required for a typical pumping station, on-site system or other electrical installation.
FEATURES
· NEMA 4X, UL Listed, CSA Certified enclosure · External mounting feet included · Flexible PVC or neoprene Gasket · UL Listed and CSA Certified Hub for incoming power/control
wires through conduit · 1″ hub available · 1.5″ standard with simplex version · 2″ standard with duplex version · UL Listed, CSA Certified cable connectors provide strain relief and a liquid tight seal (RCC8, RCC12, RCC16, UFCC8, UFCC12)
OPTIONS
Junction Boxes are available with:
· 1/2″ (1.27 cm), 3/4″ (1.90 cm) or 1″ (2.54 cm) UL Listed, CSA Certified round cable liquid-tight strain relief connectors (installed)
· 1/2″ (1.27 cm) or 3/4″ (1.90 cm) UL Listed, CSA Certified flat UF cable liquid-tight strain relief connectors (installed)
· 1″ (2.54 cm), 1 1/2″ (3.81 cm), or 2″ (5.08 cm) terminal adapter hub (installed)
· Custom connector configurations available
SIDE VIEW
TOP VIEW
TOP VIEW
4 x 4 x 4 Simplex
1 1/2″
P/N 1008547
MODEL:
JB444-1.5H-4R8
6 x 6 x 4 Simplex
1 1/2″
P/N 1008549
MODEL:
JB664-1.5H-4R8
6 x 6 x 4 Duplex
2″
P/N 1008550
MODEL:
JB664-2H-5R8
Control Panel Accessories
9500121H-WEB Rev 02/23 © 2020 SJE, Inc. All Rights Reserved. SJE Rhombus is a trademark of SJE, Inc.
www.sjerhombus.com · Toll Free 888-342-5753
H.1
JUNCTION BOXES – Seals electrical connections from moisture and other elements.
Part # 1008546 1008872 1008547 1008548 1008549 1008550 1008551 1008552 1008553
Description JB444 (no connectors or hub installed) JB444-1.5H-3R8 Simplex JB444-1.5H-4R8 Simplex JB664 (no connectors or hub installed) JB664-1.5H-4R8 Simplex (small HP pump) JB664-2H-5R8 Duplex (small HP pump) JB664-1.5H-3R8-1R12 Simplex (large HP pump) JB664-2H-3R8-2R12 Duplex (large HP pump) JB884 (no connectors or hub installed)
Shipping Weight 2 lbs. 3 lbs. 3 lbs. 3 lbs. 4 lbs. 4 lbs. 4 lbs. 5 lbs. 5 lbs.
List Price $80.00 $142.00 $154.00 $95.00 $168.00 $183.00 $176.00 $198.00 $169.00
NOTE: Descriptions grouped by enclosure size. 444 = 4 x 4 x 4, 664 = 6 x 6 x 4, 884 = 8 x 8 x 4. All enclosure dimensions are in inches. Number before R8 or R12 equals the number of connectors of that size installed.
1.5H = 1 1/2″ HUB, 2H = 2″ HUB. R8 = RCC8, R12 = RCC12.
Small HP pump = Pump cable 18/2 to 14/3 gauge. Large HP pump = Pump cable 14/4 to 10/3 gauge.
SPECIFICATIONS
LID AND BOX: UL Listed and CSA Certified made from high impact, corrosion resistant, weatherproof thermoplastic
GASKET: flexible PVC or neoprene
INTERNAL VOLUME: · 4 x 4 x 4 inches is 50.65 cubic inches (830 cubic cm) · 6 x 6 x 4 inches is 125 cubic inches (2048 cubic cm) · 8 x 8 x 4 inches is 261.14 cubic inches (4,280 cubic cm)
SCREWS: brass or stainless steel
EXTERNAL ENCLOSURE SIZE: · 4 x 4 x 4 inches (10.16 x 10.16 x 10.16 cm) · 6 x 6 x 4 inches (15.24 x 15.24 x 10.16 cm) · 8 x 8 x 4 inches (20.32 x 20.32 x 10.16 cm)
OTHER INFORMATION
CUSTOM CONNECTOR PLACEMENT Contact your customer service representative for custom connector placement and pricing.
