56057 Sephara 52 Inch Ceiling Fan

Product Information: Sephara 52-Inch Ceiling Fan

• Item Number: xxxx xxx xxx
• Model Number: 56057
• UL Model Number: XX-XXXX

The Sephara 52-Inch Ceiling Fan is a high-quality product
designed to enhance your home. It comes with a comprehensive use
and care guide to help ensure that you get the most out of your
purchase. If you have any questions or problems, or if any parts
are missing, please contact Home Decorators Collection Customer
Service at 1-800-986-3460 before returning the product to the
store.

To view an instructional video on how to install this
product:

1. Go to www.homedepot.com
2. Enter either the Item or Model number (found in the top right
   corner of the cover of this instruction manual) in the search
   field.
3. Click on your product from the list of search results and click
   on the video link in the Product Overview section.

Thank you for choosing Home Decorators Collection!

Table of Contents

• Safety Information
• Warranty
• Pre-Installation
• Installation
• Assembly
• Operation
• Care and Cleaning
• Troubleshooting

Safety Information

Please read and save these instructions before using the Sephara
52-Inch Ceiling Fan. The following safety information is provided
to help reduce the risk of personal injury or damage to the
product:

1. Before you begin, ensure that the electricity has been turned
   off at the circuit breaker or fuse box to reduce the risk of
   electric shock.
2. All wiring must be in accordance with the National Electrical
   Code ANSI/NFPA 70 and local electrical codes. Electrical
   installation should be performed by a qualified licensed
   electrician.
3. The outlet box and support structure must be securely mounted
   and capable of reliably supporting a minimum of 35 lbs (15.9 kg).
   Use only UL-listed outlet boxes marked Acceptable for Fan Support
   of 35 lbs (15.9 kg) or less.
4. The fan must be mounted with a minimum of 7 ft (2.1 m) of
   clearance from the trailing edge of the blades to the floor.
5. Do not place objects in the path of the blades.
6. To avoid personal injury or damage to the fan and other items,
   use caution when working around or cleaning the fan.
7. After making electrical connections, spliced conductors should
   be turned upward and pushed carefully up into the outlet box. The
   wires should be spread apart with the grounded conductor and the
   equipment-grounding conductor on one side of the outlet box.
8. All set screws must be checked and retightened where necessary
   before installation.

WARNING: To reduce the risk of personal injury,
do not bend the blade brackets (also referred to as flanges) during
assembly or after installation. Do not insert objects in the path
of the blades.

Usage Instructions

Pre-Installation

1. Ensure that the electricity has been turned off at the circuit
   breaker or fuse box.
2. Check that all parts are included in the package and that they
   are in good condition.
3. Make sure that the outlet box and support structure are
   securely mounted and capable of reliably supporting a minimum of 35
   lbs (15.9 kg).

Installation

1. Follow the instructions provided carefully.
2. Use only UL-listed outlet boxes marked Acceptable for Fan
   Support of 35 lbs (15.9 kg) or less.
3. Mount the fan with a minimum of 7 ft (2.1 m) of clearance from
   the trailing edge of the blades to the floor.
4. Check all set screws and retighten where necessary before
   installation.

Assembly

The Sephara 52-Inch Ceiling Fan comes with all the necessary
components for assembly. Follow the instructions provided
carefully.

Operation

The Sephara 52-Inch Ceiling Fan is easy to operate. Simply turn
on the switch and adjust the speed using the pull chain or remote
control (if included).

Care and Cleaning

To keep your Sephara 52-Inch Ceiling Fan in good condition,
follow these care and cleaning instructions:

1. Turn off the electricity at the circuit breaker or fuse box
   before cleaning.
2. Use a soft, damp cloth to clean the fan blades and motor
   housing.
3. Do not use water or other liquids to clean the motor housing or
   any electrical components.
4. Do not use abrasive cleaners or solvents on any part of the
   fan.

Troubleshooting

If you experience any problems with your Sephara 52-Inch Ceiling
Fan, please refer to the Troubleshooting section of the use and
care guide. If you are unable to resolve the issue, please contact
Home Decorators Collection Customer Service at 1-800-986-3460.

Item #xxxx xxx xxx Model #56057
UL Model #XX-XXXX
USE AND CARE GUIDE
SEPHARA 52-INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service
8 a.m. – 7 p.m., EST, Monday-Friday, 9 a.m. – 6 p.m., EST, Saturday.
1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS
To view an instructional video on how to install this product: 1. Go to www.homedepot.com and enter either the Item or Model number, found in the top
right corner of the cover of this instruction manual, in the search field. 2. Click on your product from the list of search results and click on the video link in the
“Product Overview” section. THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!

Table of Contents

Table of Contents ………………………………………………………. 2 Safety Information ……………………………………………………… 2 Warranty ……………………………………………………………………. 3 Pre-Installation ………………………………………………………….. 3 Installation…………………………………………………………………. 6

Assembly…………………………………………………………………… 7 Operation ………………………………………………………………… 13 Care and Cleaning……………………………………………………. 15 Troubleshooting……………………………………………………….. 15

Safety Information
READ AND SAVE THESE INSTRUCTIONS.
1. To reduce the risk of electric shock, ensure the electricity has been turned off at the circuit breaker or fuse box before you begin.
2. All wiring must be in accordance with the National Electrical Code ANSI/NFPA 70 and local electrical codes. Electrical installation should be performed by a qualified licensed electrician.
3. The outlet box and support structure must be securely mounted and capable of reliably supporting a minimum of 35 lbs (15.9 kg). Use only UL-listed outlet boxes marked “Acceptable for Fan Support of 35 lbs (15.9 kg) or less.”
4. CAUTION: The fan must be mounted with a minimum of 7 ft (2.1 m) of clearance from the trailing edge of the blades to the floor.
5. Do not place objects in the path of the blades.
6. To avoid personal injury or damage to the fan and other items, use caution when working around or cleaning the fan.
7. After making electrical connections, spliced conductors should be turned upward and pushed carefully up into the outlet box. The wires should be spread apart with the grounded conductor and the equipment-grounding conductor on one side of the outlet box.
8. All set screws must be checked and retightened where necessary before installation.

WARNING: To reduce the risk of personal injury, do not bend the blade brackets (also referred to as flanges) during assembly or after installation. Do not insert objects in the path of the blades.
WARNING: To avoid possible electrical shock, turn the electricity off at the main fuse box before wiring. If you feel you do not have enough electrical wiring knowledge or experience, contact a licensed electrician.
WARNING: To reduce the risk of fire, electric shock or personal injury, mount to outlet box marked “Acceptable for fan support of 35 lbs (15.9 kg) or less”, and use screws provided with the outlet box.
WARNING: Electrical diagrams are for reference only. If you are using a light kit, refer to the light kit instructions manual to make the electrical connections. Optional use of any light kit shall be UL-listed and marked suitable for use with this fan.
WARNING: To reduce the risk of fire or electric shock, this fan should only be used with fan speed control part no. XX-XXXX, manufactured by DawnSun Electronic Technology Co., Ltd. Zhongshan.
WARNING: To reduce the risk of electric shock, this fan must be installed with an isolating wall switch.
CAUTION: To reduce the risk of personal injury, use only the screws provided with the outlet box.
CAUTION: Do NOT use this fan with a dimmer switch or wall control. Using a dimmer switch or wall control will damage the fan.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

2

Warranty

The supplier warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a lifetime after the date of purchase by the original purchaser. The supplier warrants that the light kit, excluding any glass, to be free from defects in workmanship and material at the time of shipment from the factory for a period of five years after the date of purchase by the original purchaser. The supplier also warrants that other fan parts, excluding any glass or acrylic blades, to be free from defects in workmanship and material at the time of shipment from the factory for a period of two years after the date of purchase by the original purchaser. We agree to correct such defects without charge or at our option replace with a comparable or superior model if the product is returned. To obtain warranty service, you must present a copy of the receipt as proof of purchase. All costs of removing and reinstalling the product are your responsibility. Damage to any part, such as by accident, misuse, improper installation, or by affixing any accessories, is not covered by this warranty. Because of varying climatic conditions this warranty does not cover any changes in brass finish, including rusting, pitting, corroding, tarnishing, or peeling. Brass finishes of this type give their longest useful life when protected from varying weather conditions. A certain amount of “wobble” is normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. Home Decorators Collection hereby disclaims any and all warranties, including but not limited to those of merchantability and fitness for a particular purpose to the extent permitted by law. The duration of any implied warranty, which cannot be disclaimed, is limited to the time period as specified in the express warranty. Some states do not allow a limitation on how long an implied warranty lasts, so the above limitation may not apply to you. The retailer shall not be liable for incidental, consequential, or special damages arising out of or in connection with product use or performance except as may otherwise be accorded by law. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion or limitation may not apply to you. This warranty gives specific legal rights, and you may also have other rights that vary from state to state. This warranty supersedes all prior warranties. Shipping costs for any return of product as part of a claim on the warranty must be paid by the customer.
Contact the Customer Service Team at 1-800-986-3460 or visit www.HomeDepot.com/homedecorators.

Pre-Installation

SPECIFICATIONS

Size 52 in.

Speed Volts
Low Medium 120
High

Fan Power Consumption (without lights)
WATT
XX XX XX

Airflow CFM
XXXX XXXX XXXX

NOTE: These are approximate measures. They do not include the Amps and Wattage used by the light kit.

Airflow Efficiency (Higher Is Better)
CFM/WATT

Net Weight

Gross Weight

XXX

XXX

XX.XX lbs XX.XX lbs (X.X kg) (XX kg)

XXX

Cubic Feet X.XX cu. ft.

TOOLS REQUIRED

Phillips screwdriver

Flat blade screwdriver

Adjustable wrench

Electrical tape

Wire cutter / Stripper

Step ladder

3

HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Pre-Installation (continued)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.

AA

BB

CC

DD

EE

Part Description AA Blade screws BB Wire connecting nuts CC Blade bracket screws DD Hanger pin EE Locking pin

Quantity 16 3 1 1 1

4

Pre-Installation (continued)
PACKAGE CONTENTS
A I
B J
C
D K

E

L

M F

N G

H

O

Part

Description

A

Slide-on mounting bracket (inside canopy)

B

Ball/downrod assembly

C

Canopy

D

Decorative motor collar cover

Quantity
1
1 1 1

E

Fan-motor assembly

1

F

Blade arm

5

G

Blade

5

H

Light kit pan

1

IMPORTANT: This product and/or components are governed by one or more of the following U.S. Patents: 5,947,436; 5,988,580; 6,010,110; 6,046,416; 6,210,117 and other patents pending.

Part

Description

I

Light kit fitter assembly

J

Shatter resistant plastic shade

K

Outer glass shade

L

Receiver

M

Remote control

N

Extension lead wire

O

Battery

Quantity 1 1 1 1 1 1 1

5

HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Installation
MOUNTING OPTIONS
WARNING: To reduce the risk of fire, electric shock or personal injury, mount to outlet box marked “Acceptable for fan support of 35 lbs (15.9 kg) or less”, and use screws provided with the outlet box. An outlet box commonly used for the support of lighting fixtures may not be acceptable for fan support and may need to be replaced. If in doubt, consult a qualified electrician.
If your ceiling fan does not have an existing UL-listed mounting box, then install one using the following instructions:
Disconnect the power by removing the fuses or turning off
the circuit breakers.
Secure the outlet box directly to the building structure. Use
the appropriate fasteners and materials. The outlet box and support structure must be securely mounted and capable of reliably supporting a minimum of 35 lbs (15.9 kg). Use only UL-listed outlet boxes marked “Acceptable for fan support of 35 lbs (15.9 kg) or less” Do not use a plastic outlet box. The illustrations below show three different ways to mount the outlet box.

NOTE: You may need a longer downrod to maintain proper blade clearance when installing on a steep, sloped ceiling. The maximum angle allowable is 20° away from horizontal.
Hanger Bar
Outlet Box
If the canopy touches the downrod, then remove the decorative canopy bottom cover, and turn the canopy 180° before attaching the canopy to the mounting plate. To hang your fan where there is an existing fixture but no ceiling joist, you may need an installation hanger bar as shown above (available at any Home Depot store).

Outlet Box

Outlet Box

Provide Strong Support

Recessed Outlet Box

Ceiling Mounting Plate

6

Assembly – Standard Ceiling Mount

1 Preparing for mounting Remove the canopy bottom cover (FF) from the canopy (C) by turning the bottom cover counterclockwise until it
unlocks.
Loosen the two canopy screws (SS) located in the bottom
of the mounting bracket (A).
Turn the mounting bracket (A) counterclockwise and lift it
up to remove the mounting bracket from the canopy (C).

2 Routing the wires Route the wires exiting the top of the fan motor assembly (E) through the decorative motor collar cover (D) and then the center of the magnetic canopy bottom cover (FF).
Make sure the opening of the canopy (C) is on top and insert the ball/downrod (B) through the canopy (C).
Route the wires exiting the top of the fan motor assembly (E) through the downrod as shown.

C

A

B

FF

SS D

C E

FF

3 Assembling the fan
CAUTION: To ensure wobble-free operation and to avoid damage to the fan, the downrod (B) and the setscrew (HH) must be completely tightened.
WARNING: Failure to properly install the locking pin (EE) could result in the fan becoming loose and possibly falling.
Loosen, but do not remove, the setscrew (HH) on the collar (GG) on
top of the fan-motor assembly (E).
Install the downrod (B) by inserting it into the motor collar (GG),
and turning it clockwise until the holes at the bottom of the ball/ downrod assembly (B) align with the holes in the collar on top of the fan-motor assembly (E).
Carefully insert the hanger pin (AA) through the holes in the collar
and ball/downrod assembly (B). Be careful not to jam the hanger pin (DD) against the wiring inside the ball/downrod assembly (B).
Insert the locking pin (EE ) through the hole near the end of the
hanger pin (DD) until it snaps into its locked position.
Re-tighten the setscrew (HH) on the collar (GG) on top of the fan-
motor assembly (E).
7

B HH
DD

C
FF D EE GG
E

HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.

Assembly – Hanging the Fan
1 Attaching the fan to the electrical box
WARNING: To reduce the risk of fire, electric shock or personal injury, mount to outlet box marked “Acceptable for fan support of 35 lbs 15.9 kg) or less”, and use screws provided with the outlet box.
NOTE: The mounting bracket (A) is designed to slide into place on an outlet box with the outlet box screws (JJ) installed.
Loosen the two outlet box screws (JJ) in the outlet box. Pass the 120-Volt supply wires through the center hole in the
mounting bracket (A).
Slide the mounting bracket (A) on to the mounting screws (JJ)
and center the mounting bracket (A) in relation to the outlet box. If necessary, use leveling washers (not included) between the slide-on mounting bracket (A) and the outlet box. The flat side of the slide-on mounting bracket (A) should face toward the outlet box, as shown.
Securely tighten the two outlet box screws (JJ).

2 Hanging the fan Carefully lift the fan-motor assembly (E) up to the slide-on mounting bracket (A). Insert the ball portion of the ball/downrod assembly into the socket of the slide-on mounting bracket (A). Turn the ball/downrod (B) assembly clockwise until it is seated with the tab of the slide-on mounting bracket (A) aligned with the slot in the ball.
A

C

FF

JJ

JJ

B

D

A

E

8

Assembly – Hanging the Fan (continued)

3 Setting the code on the remote control and receiver
NOTE: The remote control has already been paired to the ceiling fan for your convenience. If you have two of the same model fans in your home, please follow the steps below to control each fan independently.
NOTE: The remote control battery will weaken with age and should be replaced before leaking takes place, as this will damage the remote control. Dispose of used battery properly and keep the battery out of the reach of children.

4 Installing the receiver
WARNING: To reduce the risk of fire or electric shock, remember to disconnect power. The electrical wiring must meet all local and national electrical code requirements. The electrical source and fan must be 110/120 volt, 60Hz. Do not use this product in conjunction with any variable wall control. Incorrect wire connection can damage this receiver.
CAUTION: If other fan wires are a different color, have this unit installed by a licensed electrician.

Remove the battery cover by pressing firmly on the arrow and
sliding the cover off.
Install the 23A batteries (O). Confirm that the power to the fan is off at either the wall
switch or breaker box.
Return power to the fan at the wall switch or breaker box. Press and release the “Learn” button for 1-2 seconds, located
in the remote’s battery compartment within 30 seconds of
turning on the power.
If pairing is successful, the fan’s light kit will flash and the
blades will begin to spin.
Replace the battery cover on the remote control.

Position the house supply wires (AAA) to one side of the
slide-on mounting bracket (A); position the fan wires (BBB) to the opposite side.
Insert the narrow end of the receiver (L) (as shown, flat side
towards the ceiling) into the slide-on mounting bracket until it rests on top of the ball/downrod assembly.
L

1 to 3 mode
To use more than one remote control for your fan, press the
“Learn” button for 10 seconds and release. Once pairing is successful, the fan’s light kit will flash and the blades will begin to spin.
Repeat the above process for the remote controls you want to
work with this fan.
The fan can be only controlled by 3 remote controls maximum
at the same time after “Learning”. If you use a forth remote control to handle the fan, the first remote control will be replaced.
1 to 1 mode
To use only one remote control for your fan, press and release
the “Learn” button for 1-2 seconds. The “1 to 3” mode will be cleared and returned back to “1 to 1” mode.

A AAA

BBB B C

9

HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Assembly – Hanging the Fan (continued)

5 Wiring the receiver to the household wiring
WARNING: To avoid possible electrical shock, turn the electricity off at the main fuse box before wiring. If you feel you do not have enough electrical wiring knowledge or experience, contact a licensed electrician.
WARNING: Each wire nut supplied with this fan is designed to accept up to one 12-gauge house wire and two wires from the fan. If you have larger than 12-gauge house wiring or more than one house wire to connect to the fan wiring, consult an electrician for the proper size wire nuts to use.
IMPORTANT: Use the wire connecting nuts (BB) supplied with your fan. Secure the connectors with electrical tape and ensure there are no loose strands or connections.

6 Wiring the fan to the receiver
NOTE: The fan comes with 12 in. lead wires for use with the provided 4.5 in. ball downrod assembly (B). If you wish to use longer downrod, you can use the extension lead wire (42 in.) (N) provided.
If using the 4.5 in. ball downrod assembly (B) provided,
wire the receiver to the fan wires by connecting the molded adaptor plug from the receiver (L) with the molded adaptor of the fan motor assembly (E) together.
If you wish to use longer downrod, you can use the
extension lead wire (42 in.) (N) provided by connecting the molded adaptor together.

Spread the wires apart so that the green and white wires

are on one side of the outlet box and the black wire is on the

other side.

Connect the green fan wires to the household ground wire

(this may be a green or bare wire) using a wire connecting

nut (BB).

Connect the receiver (L) black or red wire to the household

black (hot) wire using a wire connecting nut (BB).

L

Connect the receiver (L) white wire to the household white

wire (neutral) using a wire connecting nut (BB).

Secure each wire connecting nut using electrical tape.

ON DIP 1234

Outlet box in the ceiling (QQ)
Green

Outlet Box

BB (x3)

Black

Green (or Bare)

N

White Green Red

Receiver Antenna

ON DIP 1234

Receiver (L)

10

Assembly – Hanging the Fan (continued)

7 Mounting the fan-motor assembly (standard mount)

Align the locking slots of the canopy (C) with the two

screws (SS) and alignment post (QQ) in the mounting

QQ

bracket (A).

Push up the canopy (C) and turn clockwise until the

A

alignment post (QQ) engages to the round hole and the

screws (SS) engage to the key slots.

SS

Firmly tighten the two mounting screws (SS). Align the oval shape on the canopy (C) with canopy bottom

C

cover (FF). Push up the canopy bottom cover (FF) until the

FF

screw (SS) heads engage to the slots on the canopy bottom

B

cover (FF) so that the magnetic canopy bottom cover (FF)

can be attached to the bottom of the canopy (C) properly.

E

Assembly – Attaching the Fan Blades

1 Attaching the blades to the blade arms

G

NOTE: Your fan blades are reversible. Select the blade side finish which best accentuates your decor.

Attach a blade (G) to blade bracket (F) by inserting the screws
(AA) into the holes in the blade (G) and through the blade
bracket (F).
Tighten each screw securely. Repeat this step for each blade and blade bracket.

2 Fastening the blade assemblies to the motor
Fasten the blade/blade bracket assembly to the fan motor
assembly (E) by inserting the alignment posts into the slot on the bottom of the motor and tightening the pre-installed blade bracket screws (CC).
Repeat this steps for the remaining blades.

F E

CC

F

G

11

HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Assembly – Attaching the Light Kit
1 Installing the light kit pan
Remove one screw (MM) from the black bracket below the fan
motor assembly (E), and loosen but do not remove the other two screws.
Push the light kit pan (H) up to the fan motor assembly (E) so
that the two loosened screw heads fit into the keyhole slots. Turn the light kit pan (H) clockwise.
Re-install the screw (MM) that was removed in the first step. Make sure all the screws are firmly tightened.
MM
2 Attaching the light kit fitter assembly
Remove one screw (NN) from the light kit pan, and loosen, but
do not remove the other two screws.
Connect the wires from the light kit fitter assembly (I) to the
wires from the fan motor assembly (E) by connecting the molded adaptor plugs together. Carefully tuck all wires and splices into the switch cup.
Push the light kit fitter assembly (I) up to the light kit pan so
that the two loosened screw heads fit into the keyhole slots. Turn the light kit fitter assembly (I) clockwise to secure.
Re-install the screw (NN) that was removed in the first step. Make sure all the screws are firmly tightened.
3 Installing the glass bowl and interior shatter resistant shade
WARNING: Allow the glass bowl and interior shatter resistant shade to cool completely before removing.
WARNING: To prevent breaking of the glass and to avoid personal injury, hand tighten all parts in order. Do not use any tools to tighten the nut or finial.
CAUTION: Make sure the power is off before attaching or removing the glass bowl and interior shatter resistant shade.
Remove the finial nut (II) and the hex nuts (TT), (KK) and washer
(HH) from the threaded nipple of the light kit fitter assembly (I).
Position the interior shatter resistant shade (J) over the threaded
nipple.
Re-install the hex nut (KK) to the threaded nipple to secure the
interior shatter resistant shade (J) properly.
Next position the glass bowl (K) over the threaded nipple. Re-install the washer (HH) and hex nut (KK) to the threaded
nipple to secure the glass bowl (K) properly.
Re-install and tighten the finial nut (II).
12

E H
H I NN
H J TT K HH KK II

Operating Your Fan and Remote Control

Remote Control – Your fan is equipped with a remote control to operate the speed and lights of your new ceiling fan.

A. Warm weather

Speed setting for warm or cool weather depends on factors such as

the room size, ceiling height, number of fans and so on.

YY The fan is shipped from the factory with the reversing switch (YY)

positioned to circulate air downward. If airflow is desired in the

opposite direction, turn your fan off and wait for the blades to stop

turning, then slide the reversing switch (located on the top of the

motor housing) to the opposite position, and turn the fan on again. The fan blades will turn in the opposite direction and reverse airflow.

B. Cool weather

Warm weather – (Forward) A downward airflow creates a cooling effect. This allows you to set your air conditioner on a higher setting without affecting your comfort.
Cool weather – (Reverse) An upward airflow moves warm air off of the ceiling. This allows you to set your heating unit on a lower setting without affecting your comfort.

Operating Your Fan and Remote Control

Power ON/OFF: Press and release the power button to turn the fan and light on or off. Fan speed: LEDs on the fan speed button will illuminate to the corresponding speed. Press and release 1 time: turns the fan on high speed. Press and release 2 times: turns the fan on medium speed. Press and release 3 times: turns the fan on low speed. Press and release 4 times: turns the fan off.
Light ON/OFF
Press and release the button to turn the light on or off. Press and hold the button to activate the dimmer function.
Correlated Color Temperature (CCT) changing
NOTE: The default temperature of the ceiling fan light is 3000K (Soft White).
Push and release the button to cycle through the six color temperature options. Option 1: 2700K (Warm White). Option 2: 3000K (Soft White). Option 3: 3500K (Neutral White). Option 4: 4000/4100K (Cool White). Option 5: 5000K (Daylight). Option 6: 6500K (Cool Daylight).
13

HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.

Assembly – Attaching the Accessories

Mounting the remote control holder
NOTE: Screw wall anchors are included for extra support. The included screws are designed to screw easily into the wall. If you would like a more permanent or secure hold, install the wall anchors prior to attaching the wall cradle to the wall.
Slide the screw cover plate up to remove it from the wall
cradle.
Position the wall cradle in the desired position and attach it to
the wall using the included wall cradle screws.
Slide the screw cover plate back onto the wall cradle to
conceal the screws.

Screw cover plate

14

Care and Cleaning
WARNING: Make sure the power is off before cleaning your fan.
Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade
attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling.
Clean your fan periodically to help maintain its new appearance over the years. Do not use water when cleaning, as this could damage
the motor, or the wood, or possibly cause an electrical shock. Use only a soft brush or lint-free cloth to avoid scratching the finish.
You can apply a light coat of furniture polish to the wood for additional protection and enhanced beauty. Cover small scratches with a
light application of shoe polish.
You do not need to oil your fan. The motor has permanently-lubricated sealed ball bearings.

Troubleshooting

Problem The fan will not start.
The fan is noisy.

Solution
Check the main and branch circuit fuses or breakers. Check the line wire connections to the fan and switch wire connections in the switch housing. Check the battery in the remote control. Ensure you are in the normal range of 10-20 feet. Remember to turn off the power supply before checking the dip switch settings.
Ensure all motor housing screws are snug. Ensure the screws that attach the fan blade bracket to the motor hub are tight. Ensure the wire nut connections are not rattling against each other or the interior wall of the switch housing. Allow a 24-hour “breaking in” period. Most noises associated with a new fan disappear during this time. If you are using the Ceiling Fan light kit, ensure the screws securing the glassware are tight. Check that the light
bulbs are also secure. Ensure the canopy is a short distance from the ceiling. It should not touch the ceiling. Ensure your outlet box is secure and rubber isolator pads were used between the mounting plate and outlet box.

The fan wobbles.

Check that all blade and blade arm screws are secure. Most fan wobble problems are caused when blade levels are unequal. Check this level by selecting a point on
the ceiling above the tip of one of the blades. Measure from a point on the center of the blade to the point on the ceiling. Rotate the fan until the next blade is positioned for measurement, and measure from the same point on each blade to the ceiling. Repeat for each blade. Any measurement deviation should be within 1/8 in. Run the fan for ten minutes. If the fan continues to wobble please contact Customer Service and a balancing kit will be sent to you at no charge.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: –Reorient or relocate the receiving antenna. –Increase the separation between the equipment and receiver. –Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. –Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

15

HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Questions, problems, missing parts? Before returning to the store, call Home Depot Customer Service
8 a.m. – 7 p.m., EST, Monday-Friday, 9 a.m. – 6 p.m., EST, Saturday.
1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS
Retain this manual for future use.

References

• Home Decorators Collection - Home Decor - The Home Depot
• The Home Depot
• Home Decorators Collection - Home Decor - The Home Depot
