XS-L153P5B 15 Inch Single 4 ohm Subwoofer
Product Information:
The XS-L153P5B, XS-L123P5B, and XS-L103P5B are speakers with net
enclosure volumes of 62.0 Lit. (2.18 cu.ft), 32.7 Lit. (1.15
cu.ft), and 26.6 Lit. (0.93 cu.ft) respectively. They have a
frequency response range of 20Hz to 2kHz and a power handling
capacity of up to 320 watts.
Product Usage Instructions:
- Select an appropriate location to install the speakers based on
the size and volume of the enclosure. - Connect the speaker wires from the amplifier or receiver to the
speaker terminals. Ensure that the polarity of the wires is
correct. - Mount the speakers securely in the chosen location using the
provided mounting hardware. - Adjust the position and angle of the speakers as necessary to
optimize sound quality and direction. - Test the speakers by playing audio through them at low volumes
and gradually increasing the volume to ensure proper
functioning.
Note: It is important to follow the manufacturer’s instructions
regarding speaker placement and installation to ensure optimal
performance and prevent damage to the speakers or other
equipment.
XS-L153P5B/XS-L123P5B/XS-L103P5B
Thiele/Small parameters Paramètres de Thiele-Small Parámetros “Thiele/Small”
Impedance , Impédance , Impedancia d (mm) d (inch) Rdc () Fs (Hz) Qts Qes Qms Vas (Lit.) Vas (Cu.ft) Mms (g) Lvc (mH) Xmax (mm) Xmax (inch) BL (Tm) Enclosure vol. (Net) Vol. du boîtier (net) Vol. (neto) del alojamiento
XS-L153P5B
4
320 12.6 3.3 20.2 0.46 0.49 7.25 175.2 6.19 325.2 1.1 5.7 0.2 16.1
62 Lit. ( 2.18 cu.ft)
Recommended Enclosure : Sealed type Boîtier recommandé : de type scellé Alojamiento recomendado: Sellado
XS-L123P5B
4
250 9.8 3.3 24.8 0.37 0.39 7.02 86.7 3.06 162.1 1.1 5.7 0.2 14.1
32.7 Lit. ( 1.15 cu.ft)
XS-L103P5B
4
217 8.5 3.3 26.6 0.41 0.43 8.40 52.5 1.85 132.3 1.1 6.2 0.2 12.7
26.6 Lit. ( 0.93 cu.ft)
© 2006 Sony Corporation Printed in Thailand
Downloaded from: https://www.usersmanualguide.com/
2-663-681-11 (1)
Enclosure design information/Informations de conception sur les enceintes/ Información sobre el diseño del receptáculo
Sealed Type/Type scellé/Tipo sellado C
B
D
A
XS-L153P5B XS-L123P5B XS-L103P5B
A 699 (27 5/8) 572 (22 5/8) 521 (20 5/8)
B 445 (17 5/8) 368 (14 5/8) 343 (13 5/8)
C 286 (11 3/8) 236 (9 5/8) 229 (9 1/8)
D 19 (3/4) 19 (3/4) 19 (3/4)
XS-L153P5B XS-L123P5B XS-L103P5B
Enclosure Volume (Net)* 62.0 (2.18) Lit. (Cu.ft) 32.7 (1.15) Lit. (Cu.ft) 26.6 (0.93) Lit. (Cu.ft)
* Net volumes do not include the air volume displaced by the speaker. * Le volume net ne tient pas compte du volume d’air déplacé par les haut-parleurs. * Los volúmenes netos no incluyen el volumen de aire que ocupa el altavoz.
Ported Type/Type à évent/Tipo abierto F E
C
Unit: mm (in) Unité : mm (po) Unidad: mm
B
D A
Unit: mm (in) Unité : mm (po) Unidad: mm
XS-L153P5B XS-L123P5B XS-L103P5B
A 648 (25 5/8) 521 (20 5/8) 495 (19 5/8)
B 437 (17 3/8) 355 (14 1/8) 318 (12 5/8)
C 257 (10 1/4) 208 (8 1/4) 231 (9 1/8)
D 19 (3/4) 19 (3/4) 19 (3/4)
E ø76 (3) ø76 (3) ø76 (3)
F 192 (7 5/8) 303 (12) 384 (15 1/4)
XS-L153P5B XS-L123P5B XS-L103P5B
Enclosure Volume (Net)* 44.3 (1.55) Lit. (Cu.ft) 23.5 (0.82) Lit. (Cu.ft) 22.2 (0.78) Lit. (Cu.ft)
* Net volumes do not include the air volume displaced by the speaker and port. This port should be a solid, not a hollow object.
* Les volumes nets ne comprennent pas le volume d’air déplacé par le haut-parleur et l’évent. Cet évent doit être plein et non un objet creux.
* Los volúmenes netos no incluyen el volumen de aire que ocupan el altavoz y el puerto. Dicho puerto debe ser un objeto sólido, no uno hueco.
