FXi-10 Standard-Level Precision Balances
Product Information
The FXi-10 / FXi-WP-10 Small Breeze Break is a product designed
to protect the balance from the effects of a breeze, ensuring more
accurate weighing results. It has been treated with an anti-static
treatment to prevent weighing errors caused by static electricity.
The FXi-10 and FXi-WP-10 models have different colors but share the
same external design and functions. This product is compatible with
various models including FX / FZ, FX-i / FZ-i, FX-WP / FZ-WP, and
FX-i WP / FZ-i WP.
Features:
- Protects the balance from the effects of a breeze
- Provides more accurate weighing results
- Anti-static treatment to prevent weighing errors caused by
static electricity - Compatible with various balance models
Materials Used:
The breeze break is made of Acrylic (PMMA) and Antistatic ABS.
Each part has the type of material used printed on it for easy
identification.
Product Usage Instructions
Unpacking:
When unpacking the product, you will find the following
parts:
- Base – 1 piece
- Pillars – 4 pieces
- Plates – 4 pieces
- Cover – 1 piece
The colors of the parts differ depending on the model:
| Part | FXi-10 Color | FXi-WP-10 Color |
|---|---|---|
| Base | White | Gray |
| Pillars | White | Gray |
| Plates | White | Transparent |
| Cover | White | Gray |
Assembling:
- Insert the pillars into the holes in the base.
- Rotate the pillars 90 degrees and ensure that the position of
the channels on the pillars aligns with the base. - Insert the plates into the channels between the pillars,
aligning them with the base. - Confirm that both side projections of the base and both side
channels on the balance fit together correctly. - Install the breeze break on the balance.
- Place the cover on the breeze break.
Note: When cleaning the balance, remove the small breeze break
if you are using the FX-i WP / FZ-i WP / FX-WP / FZ-WP series.
Please refer to the provided manual for any additional
information or troubleshooting steps.
FXi-10 / FXi-WP-10 Small Breeze Break
A&D Company, Limited
1. Features
The FXi-10/FXi-WP-10 protects the balance from the effects of a breeze and will provide more accurate weighing results. An anti-static treatment has been applied to the breeze break components, therefore the weighing error of static electricity should not be a problem. * The colors of the FXi-10 and the FXi-WP-10 are different, however the externals and the
functions are common. (Refer to “2. Unpacking”) Models : FX / FZ, FX-i, / FZ-i, FX-WP / FZ-WP, FX- i WP / FZ- i WP
2. Unpacking
Base 1pcs Pillars 4pcs
Plates 4pcs
Cover 1pcs
-Base -Pillars -Cover
-Plates
* Parts colors FXi-10 FXi-WP-10
White
Gray
Transparent
3. Assembling
1. Insert the pillars into the holes in the base. 2. Rotate the pillars 90 degrees, and confirm that the
position of the channels on the pillars and the base match up. 3. Insert the plates in the channels between the pillars and aligned with the base. 4. Confirm that both side projection of the base and both side channels on the balance fit together correctly. Install the breeze break on the balance. 5. Place the cover on the breeze break.
Plate Channel
Note (FX-i WP / FZ-i WP / FX-WP / FZ-WP series)
When cleaning the balance, remove the small
breeze break.
5
Pillar
2
Channel 1
3
Base Cover
Projection
4
Channel
Balance
Completion
Materials used (Material of the breeze break) Acrylic (PMMA), Antistatic ABS * Each part has the type of material used printed on it.
1WMPD4001388B
Projection Channel
