ET90000 Double Pole Relay Upgrade
User Manual
ET90000 Double Pole Relay Upgrade
http://waterheatertimer.org/Intermatic-ET-series-timers-and-manuals.html#ET90215
ET90000 Double Pole Relay Upgrade
Now Standard on 4, 8, 12 & 16 Circuit Models
Update on ET90000 Series (4 Circuits and Above
Now your controls can be configured to work as Double Pole relays for enhanced flexibility and peace of mind. If you currently use the ET90000 PC App, be sure to download the latest version of the PC App which has been optimized to support Double Pole configurations from Intermatic.com!
Configuration options that will now be available are as follows:
(New options in blue)
- 4xSPST
- 4xSPDT
- 2xDPST
- 2xDPDT
- 1xDPST and 2xSPST
- 1xDPST and 2xSPDT
- 1xDPDT and 2xSPST
- 1xDPDT and 2xSPDT
Jumper Pin Configurations
