EC2832 Short Term Confidential
User Manual

KAGA FEI EC2832 Short Term Confidential(for EC2832)
FCC ID: 2A6NFEC2832
IC: 28568-EC2832

EC2832 Short Term Confidential

This module should be installed in the host device according to the interface specification.

  1. Japan Regulatory Information
    a) This module is approved with the specific antenna on this module.
    b) Please ensure that your product can bear a label with the following information. If the product is so small that it is not practicable to place the label, please place it in the instruction manual and package.
    This product installs a radio system which has been approved as a radio station in a low power data communication system based on the Radio Law.
    EC2832 : 005-103090
  2. Canada Regulatory Information
    The following information must be indicated on the host device of this module;
    a) This device complies with Innovation, Science and Economic Development Canada’s applicable license-exempt RSSs. Operation is subject to the following two conditions:
    (1) This device may not cause interference; and
    (2) This device must accept any interference, including interference that may cause undesired operation of the device.
    b) This product is certified as type of the portable device with Science and Economic Development Canada Rules. To maintain compliance with RF Exposure requirement, please use within specification of this product.
    c) Please notify certified ID by either one of the following method on your product.
    -Contains IC : 28568-EC2832
  3. FCC Regulatory Information
    a) This device complies with part 15 of the FCC Rules.
    -Part 15 Subpart C
    b) The following statement shall be indicated on the host device or the user manual of the host device; Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference
    received, including interference that may cause undesired operation.
    c) Please notify certified ID by either one of the following method on your product.
    -Contains Transmitter Module FCC ID: 2A6NFEC2832
    -Contains FCC ID: 2A6NFEC2832
    d) The following statement shall be indicated in the user manual of the host device;
    CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the use’s authority to operate the equipment.
    e) The modular transmitter is only FCC authorized for the specific rule parts (Part 15 Subpart C) listed on the grant, and the host product manufacturer is responsible for compliance to any other FCC rules that apply to the host not covered by the modular
    transmitter grant of certification. The final host product still requires Part 15 Subpart B compliance testing with the modular transmitter installed.
    f) This product is certified as type of the portable device with FCC Rules. To maintain compliance with RF Exposure requirement, please use within specification of this product.
    g) The following statement shall be indicated in the user manual of the host device; The antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
    h) This module can change the output power depending on the circumstances by the application software which is developed by module installer. Any end user cannot change the output power.
    i) Antenna List
    No.1
    Antenna Category Antenna TypeMonopole
    Antenna TypePCB antenna
    Dimensions9.0mm x 2.7mm
    No.2
    Antenna Category Antenna TypeMonopole
    Antenna TypeChip antenna
    Dimensions2.0mm x 1.25mm
  4. CE Regulatory Information
    a) When your end product installs this module, it is required to proceed additional certification processes before placing on the market in EU member states to make your products fully comply with relative EU standards.
    b) KAGA FEI can provide you the test reports of conducted measurement portion for the radio module. You can utilize the test reports for the certification processes of your end product as it requires radio testing.

Pin Descriptions

PinPin namePin functionDescription
1DCCPowerDC/DC converter output pin (built-in LC for DC/DC).
2DEC4Power1V3 regulator supply decoupling. Input from DC/DC converter. Output from 1.3 V LDO.
3GNDGroundGround pin. (0 V)
4VCC_NRFPowerPower supply pin.
5GNDGroundGround pin. (0 V)
6P0.04 AIN2Digital I/O Analog inputGeneral purpose I/O pin. SAADC/COMP/LPCOMP input.
7P0.05 AIN3Digital I/O Analog inputGeneral purpose I/O pin. SAADC/COMP/LPCOMP input.
8P0.06Digital I/OGeneral purpose I/O pin.
9P0.07Digital I/OGeneral purpose I/O pin.
10P0.08Digital I/OGeneral purpose I/O pin.
11NFC1

P0.09

NFC input

Digital I/O

NFC antenna connection.

General purpose I/O pin.

12NFC2

P0.10

NFC input

Digital I/O

NFC antenna connection.

General purpose I/O pin.

13GNDGroundGround pin. (0 V)
14SWDIODigital I/OSerial Wire Debug I/O for debug and programming
15SWDCLKDigital inputSerial    Wire    Debug    clock   input    for   debug    and programming
16P0.13Digital I/OGeneral purpose I/O pin.
17P0.14

TRACEDATA[3]

Digital I/OGeneral purpose I/O pin.

Trace port output.

18P0.17Digital I/OGeneral purpose I/O pin
19P0.18 TRACEDATA[0]Digital I/OGeneral purpose I/O pin Trace port output.
20P0.21 RESETDigital I/OGeneral purpose I/O pin Configurable as system RESET pin. (Factory default : GPIO)
21GNDGroundGround pin. (0 V)
22OUT_MODRF In/OutRF I/O pin. It should be connected to Pin 23 OUT_ANT for normal operation.
PinPin namePin functionDescription
23OUT_ANTAntenna In/OutInternal antenna. It should be connected to Pin 22 OUT_MOD for normal operation.
24P0.22Digital I/OGeneral purpose I/O pin.
25P0.23Digital I/OGeneral purpose I/O pin.
26P0.24Digital I/OGeneral purpose I/O pin.
27P0.25Digital I/OGeneral purpose I/O pin.
28P0.26Digital I/OGeneral purpose I/O pin.
29P0.27Digital I/OGeneral purpose I/O pin.
30P0.28
AIN4
Digital I/O
Analog input
General purpose I/O pin.
SAADC/COMP/LPCOMP input.
31P0.29
AIN5
Digital I/O
Analog input
General purpose I/O pin.
SAADC/COMP/LPCOMP input.
32P0.30 AIN6Digital I/O
Analog input
General purpose I/O pin.
SAADC/COMP/LPCOMP input.
33P0.31
AIN7
Digital I/O
Analog input
General purpose I/O pin.
SAADC/COMP/LPCOMP input.
34P0.02

AIN0

Digital I/O
Analog input
General purpose I/O pin.
SAADC/COMP/LPCOMP input.
35P0.03

AIN1

Digital I/O
Analog input
General purpose I/O pin.
SAADC/COMP/LPCOMP input.
36P0.11Digital I/OGeneral purpose I/O pin.
37P0.12Digital I/OGeneral purpose I/O pin.
38P0.15

TRACEDATA[2]

Digital I/OGeneral purpose I/O pin.

Trace port output.

39P0.16
TRACEDATA[1]
Digital I/OGeneral purpose I/O pin.
Trace port output.
40P0.19Digital I/OGeneral purpose I/O pin.
41P0.20
TRACECLK
Digital I/OGeneral purpose I/O pin.
Trace port clock output.
42 to 47GNDGroundGround pin. (0 V)
