SETMUBDGRKG4A Marquis Series 4 Piece Bedroom Set
Product Assembly Instructions
Item # LCMUBDGRKGB
Product Information:
- Headboard x 1
- Footboard x 1
- Side Panel x 2
- Middle bar x 2
- Slats x 16
- Leg x 2
- Support Leg x 4
- Bolt / M6*20 x 18
- Allen wrench x 1
- Bolt M6*35 x 4
- Nuts M8 x 4
- Washer Semicircle x 4
- Bolt M8*90 x 2
- Threaded Rod M8*70 x 2
- Screw M4*30 x 8
- Wrench x 1
Product Usage Instructions:
- Turn the Footboard (B) over and place it on the ground where
the exterior finish will not be scratched. Align the screw holes on
the Footboard(B) with the screw holes of Legs (F). Insert flat
washers (I), lock washer (J), and bolt (H) into each hole. Once the
screws are in place, tighten them firmly with the allen-wrench (K)
provided. - Insert Threaded Rod(P) into the middle hole of Footboard (B),
tighten the screw until firmly attached. - Align the screw holes on the Side panel(C) with the screw holes
of Headboard(A) and Footboard(B). Insert flat washers (I), lock
washer (J), and bolt (H) into each hole. Once the screws are in
place, tighten them firmly with the allen-wrench (K) provided. - Under footboard(B), insert flat washers (I), lock washer (J),
and bolt (H) into each hole. Tighten the screws until firmly
attached with the allen-wrench(K) provided. - Under position connect Footboard(B) with Side Panel(C). Insert
Semicircle Washer(N), Flat Washer(I), Lock Washer(J), Nut(M) with
Threaded Rod(P). Tighten the screws until firmly attached with the
wrench(R) provided. - Under position connect Headboard(A) with Side Panel(C). Insert
Semicircle Washer(N), Flat Washer(I), Lock Washer(J), Nut(M) with
Flat Washer(I), Lock Washer(J), and Bolt(O). Tighten the screws
until firmly attached with the allen-wrench(K) provided. - Align and fix the connect bracket of Middle Bar(D) with connect
bracket on Headboard(A) and Footboard(B) follow direction arrow.
Align the screw holes on the Support Leg(G) with the screw holes of
Middle Bar(D). Insert bolt(L) into each hole and tighten the screws
until firmly attached with the allen-wrench(K) provided. - Put on slats into the frame. Insert the screws (Q) into each
hole. Once the screws are in place, tighten them firmly with the
screwdriver.
Product Information:
- Chest x 1
- Leg x 2
- Bolt / M8*20 x 8
- Insert nut x 4
- Screw M4*20 x 4
- Screw M4*40 x 4
- Allenkey V4 x 1
- Bolt / M6*15 x 4
- Anti-flip A x 4
- Anti-flip B x 2
Product Usage Instructions:
- Turn the chest over (A) and place it on the ground where the
exterior finish will not be scratched. Align the screw holes of the
legs (B) with the screw holes of the crossbar. Insert bolt (G) into
each hole, Once the screws are in place, tighten them firmly with
the allen-wrench (F) provided. - Align the screw holes of the legs (B) with the screw holes of
the bottom Chest(A). Insert flat washers (D), lock washer (E), and
bolt (C) into each hole, Once the screws are in place, tighten them
firmly with the allen-wrench (F) provided.
Product Assembly Instructions Item # LCMUBDGRKGB
NOT PROVIDED
1/5
A: Headboard x 1
B: Footboard x 1
C: Side Panel x 2
D: Middle bar x 2
E: Slats x 16
F: Leg x 2
G: Support Leg x 4
H: Bolt / M6*20
x 18
I: Flat Washer / Ø19 x 24
J: Lock Washer / Ø12 x 24
K: Allen wrench
x 1
L: Bolt M6*35
x 4
M: Nuts M8
x 4
N: Washer Semicircle x 4
O: Bolt M8*90
x 2
P: Threaded Rod M8*70 x 2
Q: Screw M4*30
x 8
R: Wrench
x 1
2/5
K
H J I
B
K
H
J
F
I
P
Step 1 : Turn the Footboard (B) over and place it on the ground where the exterior finish will not be scratched. Align the screw holes on the Footboard(B) with the screw holes of Legs (F). Insert flat washers (I) lock washer (J) and bolt (H) into each hole. Once the screws are in place,tighten the screw until firmly attached with the allen-wrench (K) provided. Step 2: Insert Threaded Rod(P) into the middle hole of footboard(B), tighten the screw until firmly attached.
A
K H JI
C
C
B
K H J I
UNDER
Step 3 : Align the screw holes on the Side panel(C) with the screw holes of Headboard(A) and Footboard(B). Insert flat washers (I) lock washer (J) and bolt (H) into each hole. Once the screws are in place, tighten the screw until firmly attached with the allen-wrench (K) provided. Step 4: Under footboard(B), insert flat washers (I) lock washer (J) and bolt (H) into each hole and tighten the screw until firmly attached with the allen-wrench(K) provided.
3/5
HEAD
K
O
A
J I
IN RM J
FOOT
R M J NI P C
R M JI N
K IJ O
C
HEAD
B
FOOT
UNDER
R I JM N
Step 5 : Under position connect Footboard(B) with Side Panel(C). Insert Semicircle Washer(N), Flat Washer(I), Lock Washer(J), Nut(M) with Threaded Rod(P). Tighten the screw until firmly attached with the wrench(R) provided. Step 6 : Under position connect Headboard(A) with Side Panel(C). Insert Semicircle Washer(N), Flat Washer(I), Lock Washer(J), Nut(M) with Flat Washer(I), Lock Washer(J) and Bolt(O). Tighten the screw until firmly attached with the allen-wrench(K) provided.
K L
D G
D D
G G
Step 7 : Align and fix the connect bracket of Middle Bar(D) with connect bracket on Headboard(A) and Footboard(B) follow direction arrow. Align the screw holes on the Support Leg(G) with the screw holes of Middle Bar(D). Insert bolt(L) into each hole and tighten the screw until firmly attached with the allen-wrench(K) provided
4/5
Q E
Step 8 : Put on slats into the frame. Insert the screws (Q) into each hole. Once the screws are in place,tighten the screw until firmly attached with the screwdriver.
Finished
5/5
A: Chest x 1
Product Assembly Instructions
Item # LCMUDRGR
NOT PROVIDED
B: Leg x 2
C: Bolt / M8*20
x 8
D: Flat Washer / Ø19 x 8 E: Lock Washer / Ø12 x 8
H: Insert nut
x 4
I: Screw M4*20
x 4
J: Screw M4*40
x 4
F: Allenkey V4
x 1
G: Bolt / M6*15
x 4
K: Anti – flip A
x 4
L: Anti – flip B
x 2
Step 1 : Turn the chest over (A) and place it on the ground where the exterior finish will not be scratched. Align the screw holes of the legs (B) with the screw holes of the cross bar. Insert bolt (G) into each hole, Once the screws are in place, tighten the screw until firmly attached with the allen-wrench (F) provided.
A B
G F
D E CF
Step 2 : Align the screw holes of the legs (B) with the screw holes of the bottom Chest(A). Insert flat washers (D) lock washer (E) and bolt (C) into each hole, Once the screws are in place,tighten the screw until firmly attached with the allen-wrench (F) provided.
Step 3: Align the screw holes of handle with holes on face of drawer, insert bolt are in place, tighten the screw until firmly attached with the screwdriver.
1/2
H: Plastic anchor x 4
Step 3 : Making drill holes on the wall and insert plastic anchor (H) at this hole.
I: Screw M4*20 x 4
Fixing anti – flip A (K) by 2 screw M4*40 (J) with screwdriver. Once the screws are in place,tighten the screw until firmly attached.
J: Screw M4*40 x 4
Fixing anti – flip A (K) on back chest (A) by 2 screw M4*20 (I) with screwdriver.
K: Anti – flip A
x 4
Wall
H
L: Anti – flip B
x 2
K J I
K
Wall
Step 4 : Align the anti – flip A (K) on the wall with the anti – flip A (K) on the chest
Use the anti – flip B (L) through 2 anti – flip A to fix.
1
2
3
L
Wall Finished
2/2
A: Chest x 1
Product Assembly Instructions Item # LCMULAGR
D: Bolt / M8*20
x 18
E: Flat Washer / Ø19
x 18
F: Lock Washer / Ø12 x 18
B: Leg x 2
C: Shelf x 1
G: Allenkey V4
x 1
A B
Step 1 B
EFD G
C
Step 2
EFD G
Step 1: Turn the chest over (A) and place it on the ground where the exterior finish will not be scratched. Align the screw holes of the legs (B) with the screw holes of bottom Chest (A). Insert flat washers (E) lock washer (F) and bolt (D) into each hole, Once the screws are in place, tighten the screw until firmly attached with the allen-wrench (G) provided.
Step 2: Align the screw holes of the legs (B) with the screw holes of Shelf (C). Insert flat washers (E) lock washer (F) and bolt (D) into each hole, Once the screws are in place, tighten the screw until firmly attached with the allen-wrench (G) provided.
Step 3: Align the screw holes of handle with holes on face of drawer, insert bolt are in place, tighten the screw until firmly attached with the screwdriver.
Step 3
1/1
