Product Information: Manufacturer: Robert Bosch
(Australia) Pty. Ltd. Address: 1555 Centre Road Clayton VIC 3168
Contact Information: – Email: [email protected] –
Australia: 1300 307 040 – Website: www.boschaftermarket.com.au
– New Zealand: 0800 452 896 – Website: www.boschaftermarket.co.nz
Product Name: Bosch Cabin Filters Part Number: AP-A01 0986 AF7 023
Recommended Replacement Time: 1 year or 10,000km Installation Time:
5-10 minutes Accuracy of Installation Guide: May 2022
Product Usage Instructions: 1. Removing the glove
box: a. Open the glove box and remove the pins from the inside (2
places). b. Remove the glove box. 2. Removing the cabin filter
cover: a. Slide the filter cover in the direction of the removal
arrow. 3. Removing the old cabin filter: a. Ensure the AIR FLOW
arrow on the old cabin filter is pointing down. b. Remove the claws
of the cabin filter cover (2 places). c. Take out the old cabin
filter. 4. Installing the new Bosch Cabin Filter: a. Place the new
Bosch Cabin Filter in the filter cover. b. Ensure the AIR FLOW
arrow on the new cabin filter is pointing down. c. Reattach the
claws of the cabin filter cover (2 places). 5. Reinstalling the
glove box: a. Restore the removed vehicle parts to their original
positions. b. Place the glove box back in its position. Please
refer to the installation guide for more detailed instructions and
safety precautions to ensure safe and correct installation of the
Bosch Cabin Filters.
Robert Bosch (Australia) Pty. Ltd. 1555 Centre Road Clayton VIC 3168
For Further information please contact Bosch on: Email: [email protected] Australia: 1300 307 040 www.boschaftermarket.com.au New Zealand 0800 452 896 www.boschaftermarket.co.nz
Bosch
Installation Guidelines for Cabin Filters
Part Number: AP-A01 0986 AF7 023
please be sure to read this book to ensure safe and correct installation. Estimated Installation Time: 5-10 minutes
time.
Recommended replacement time
1 year or 10,000km
soon as possible when driving in heavily soiled areas. The contents of this installation guide are accurate as of May 2022
Precautions for installation and use
· Be sure to park your vehicle in a safe place with the engine and air conditioner turned off before commencing the replacement process.
· · This guide is just an example and may differ from the actual vehicle. · Please refrain from unreasonable work. It may result in damaging the vehicle or
personal injury. · · Check the direction of the arrow so that you do not mistake the front and back ·
A01 Cabin Installation Guide
1. Removing the glove box
Pin
Pin
1. Open the glove box, remove the pins ( 2 places) from the inside
2. Remove the glove box
Glove Box
Removal direction
Filter cover
1. Slide the filter cover by pulling in the direction of the removal arrow
Cabin Filter Cover 1. Remove the claws (2 places) of the cabin 2.
Old Cabin Filter
1. “AIR FLOW” arrow pointing down
2. Restore the removed vehicle parts to their original positions
Bosch Cabin Filter
Cabin Filter Cover
Attention
· This work procedure is an example and may vary across different vehicles. ·
arrow may indicate “TOP” on other genuine or IAM products. · Please read the “Precautions for installation and use” on the installation guide cover be-
fore commencing. ·
