ST-1362FH All In One LED Display
Product Information
The ST-1362FH is an all-in-one LED display designed for indoor
applications. It features a 1.5625 mm pixel pitch with SMD LEDs,
providing high-quality visuals. The display is equipped with smooth
anodized dual columns and an adjustable flat-panel TV height for
optimal viewing experience. It also includes an exclusive patent
technology hanging back frame for easy installation.
The stand is made of high tensile strength steel and rigid
aluminum alloy materials, ensuring durability and stability. It has
integrated cable management through the columns, allowing for a
clean and organized setup. The ST-1362FH can carry a maximum load
of 441lbs (200kgs) and supports screens up to 140 flat panel
TVs.
Caution: This stand is specifically designed for use with the
LAEC015-GN screen. Using it with other equipment may result in
instability and potential injury.
Product Usage Instructions
- Step 1: Install the main body to the stand
base.
- Use 8pcs M8X40 hexagon socket head cap screws (item 7) to
attach the stand base to the main body.
- Put the left (item 3) and right (item 4) halves together.
- Insert the beam reinforce plate (item 5) to fix the screw hole
position. - Tighten the beam reinforce plate with 32-M4x15 screws (item
8).
the main body.
- Hang the assembled back frame to the corresponding buckle
points of the stand. - Attach the panel mounting plate to the main body using 16pcs
M6x20 screws (item 9).
- Plug the power supply in after installing the panel.
- Control the lift using the “Control up” and “Control down”
buttons. - If you wish to hide the lifting cable, install the cable cover
(item 6) as shown in Pic 1 and Pic 2.
Note: The packaging may vary from the schematic diagram
shown.
1.5625 mm Pixel Pitch with SMD LEDs
ST-1362FH
All-in-one LED Display A modular system for Indoor applications
Page 1 of 11
Installation Manual
2022.08 Document version 1.01
Technical Data
Type Material Surface Finish Recommended Screen Size Rated Weight Capacity Max Hole Pattern Lift range Voltage Certification Stand dimension(with frame) Woodencase Dimension Weight (Net/Gross)
ST-1362FH Aluminum profile,Steel Coating matte black 80″ 140″ 441lbs/ 200kg (Overall) 750x750x750mm-1062mm 490mm 100~240v CB,CE,FCC,ETL,RoHS2.0,REACH 255.6 x 72.3 x 192cm 182 x 141 x 71 cm
77.8kg/184.5
PRODUCT HIGHLIGHTS
– Smooth anodized dual columns with adjustable flat-panel TV height. – With exclusive patent technology hanging back frame. – The safe and quiet remote control lifting function can make your TV lift 490MM at will – High tensile strength steel and rigid aluminum alloy materials. – Integrated cable management through columns. – Carry maximum load 441lbs(200kgs) and up to 140″ flat panel TV – Flexible and installer-friendly.
Caution
-This stand is designed for LAEC015-GN screen. Use with other equipment may result in instability causing injury
-Manufacturer’s name: Lighthouse Technologies (HuiZhou) Limited -Model number: ST-1362FH -Equipment name: Motor stand
Page 2 of 11
Page 3 of 11
CHECKLIST
Item Photo 1
Qty Description
1
Stand base
Item 2
Qty Description
1
The main
body
3
1
Left panel
mounting
assembly
4
1
Right panel
mounting
assembly
Page 4 of 11
5
2
Beam
6
reinforce
plate
10 Cable cover
7
8
Socket head
8
cap screw –
M8X40
32 Screw-M4x15
9
16 Hexagon
10
1
Hex key -#6
socket head
screw M6X20
Page 5 of 11
Step1. Install the main body to the stand base.
Front View
main body ( Item 2 )
Stand base ( Item 1 )
Use 8pcs M8X40 hexagon socket head cap screws (item 7) to install the stand base .
Page 6 of 11
Step2. Install the panel mounting plate.
Front View
Put the left (item 3) and right (item 4) halves
Insert the beam reinforce plate(item 5) to fixing the screw hole position.
Page 7 of 11
Tighten the beam reinforce plate with 32-M4x15 screw (item 8) as the red circle marked.
Step3. Install the panel mounting plate to the main body.
Front View
Side View
Side View
Hang the assembled back frame to the corresponding buckle points of the stand.
Page 8 of 11
Install the panel mounting plate to the main body ,Use 16pcs M6x20 screw ( Item9)
Step4. Lifting cable routing.
Plug the power supply in after installing the Panel as below
Control up
Control down
Page 9 of 11
Pic 1
If you would like to hide the lifting cable. Please install the cover as Pic 1 and 2.
Cable cover (Item 6)
Pic 2
The cable can be hidden under this cover.
Page 10 of 11
Packaging
NOTE: The picture is schematic diagram. Everything is subject to the infact products.
