RB-0200 Collapsible Rain Barrel Water Storage Tank
Product Information: WATER STORAGE TANK
The WATER STORAGE TANK is available in two models: RB-0200 and
RB-0380. The RB-0200 model has a capacity of 53 gallons and the
RB-0380 model has a capacity of 100 gallons. Both models are made
of PVC material and can be used in ambient temperatures ranging
from -30 to +70 degrees Celsius. The product comes in black color
and the dimensions of the RB-0200 model are 60*74cm while the
dimensions of the RB-0380 model are 70*103cm.
Structure Diagram:
The product has the following components:
- Top zipper
- Bottom outlet (3/4)
- Top filter hole
- Overfall gap
- Scale
- Central outlet
- Supporting foot (6)
Manufacturer Information:
The WATER STORAGE TANK is manufactured by Haining Tak Techtextil
Industries Co., Ltd. in China.
Product Usage Instructions:
- After receiving the product, unroll the rain barrel with the
zipper/filter hole side facing upwards. - Install all six supporting foot strips.
- Keeping the outlet valve closed, fill the tank with liquid from
the top.
Note: If you install and remove the connector yourself and the
switch is not vertical, try increasing the number of winding laps
of waterproof tape.
For any product questions or technical support, customers can
contact VEVOR at [email protected]. Please read the user
manual carefully before operating the product.
Support and Warranty:
Customers can visit https://www.vevor.com/support for support
and to obtain an e-warranty certificate.
Support and E-Warranty Certificate https://www.vevor.com/support
WATER STORAGE TANK USER MANUAL
We continue to be committed to offering tools at competitive prices. “Save Half”, “Half Price”, or any other similar expressions used by us only represent an estimate of savings you might
benefit from buying certain tools with us compared to the major top brands and do not necessarily mean to cover all categories of tools offered by us. You are kindly reminded to verify carefully when placing an order with us if you are saving half in comparison with the top
major brands.
WATER STORAGE TANK
MODEL:RB-0200/RB-0380
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to
contact us:
This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won’t inform you again if there are any technology or software updates on our product.
1
NOTES 1. Place the fully installed barrel under the desired water source, such as a downspout. Water intake is through the filtered hole on the top of the barrel. The top of the barrel can also be unzipped for water intake or removal in bulk. 2. The water barrel may not take form and be fully stable until some water is filled into the container. It is recommended to place the barrel in your desired location after installation and prefill some water into the container. 3. All joints have been installed in advance. If there is water leakage, please check and tighten the joints.
Model Capacity Material Ambient temperature
Color Product Size
MODEL AND PARAMETERS RB-0200
RB-0380
53Gallons
100Gallons
PVC
PVC
-30+70
-30+70
Black 60*74cm
Black 70*103cm
2
TRUCTURE DIAGRAM
1.Top zipper 3.Top filter hole 5.Scale 7.Supporting foot
2.Bottom outlet(3/4″) 4.Overfall gap 6.Central outlet
COMPONENTS
No.
PART
NAME
1
Rain barrel
2
Lotus base
QTY 1 6
3
Pillar
6
4
Patch
2
5
Planting label
25
6
User manual
1
3
USE 1. After getting the product, unroll the rain barrel (Zipper/filter hole side is the top). Keeping the outlet valve closed, fill in the liquid from the top. 2. Install 6 supporting foot strips and start to use.
MAINTAIN AND STORAGE 1. Please use mild detergent and water for cleaning. 2. Don’t scrub with hard objects like brushes. 3. Dry before storage.Do not store in a dark, damp place. 4. Clean the debris at the filter port in time to avoid clogging. 5. If the barrel body is damaged, it can be repaired with the attached patch (Please bring your own glue). 6. If the joint is leaking, tighten the joint or wrap waterproof tape(Provide for yourself) on the thread of the joint before installing it(As shown below).
Note: If you install and remove the connector yourself and the switch is not vertical, try increasing the number of winding laps of waterproof tape.
4
Manufacturer: Haining Tak Techtextil Industries Co., Ltd. ADD: No. 2, Qingyuan Road, Xieqiao Town, Haining City, Jiaxing City, Zhejiang Province, China Importer: WAITCHX Address: 250 bis boulevard Saint-Germain 75007 Paris Importer: FREE MOOD LTD Address: 2 Holywell Lane, London, England, EC2A 3ET
Made in China
5
