WT-0240 Water Storage Tank
Product Information: Water Storage Tank
This is the user manual for the Water Storage Tank. The tank is
available in three models: WT-0240, WT-0330, and WT-0540. The tank
is made of PVC material and is available in black color. It has a
capacity of 240L, 330L, and 540L respectively. The tank can
withstand an ambient temperature range of -30 to +70 degrees
Celsius.
Components:
| No. | PART NAME | QTY |
|---|---|---|
| 1 | Rain bag | 1 |
| 2 | Drain valve | 1 |
| 3 | Patch | 2 |
| 4 | User manual | 1 |
Structure Diagram:
The tank consists of the following components:
- Top intake (1.5)
- Hanging ring (It’s actually at four corners)
- Bag body
- Scale
- Drain valve (1.5)
Product Usage Instructions:
- After getting the product, unroll the rain bag. The water inlet
is at the top. - Install the water outlet valve by turning it clockwise. The
outlet valve is larger and needs to be installed forcefully until
the valve is centered in the off position. - Fill in the liquid from the inlet valve on the top, keeping the
outlet valve closed. The diameter of the water injection tube
should be less than 1.5 so that the air in the tank can be
discharged. - Ensure all accessories are firmly tightened by hand. Improper
tightening of accessories can lead to leakage. - If you install and remove the connector yourself and the switch
is not vertical, try increasing the number of winding laps of
waterproof tape.
Please note that the appearance of the product shall be subject
to the product you received. Verify carefully when placing an order
with us if you are saving half in comparison with the top major
brands. For any product questions or technical support, please
contact us at [email protected].
Support and E-Warranty Certificate https://www.vevor.com/support
WATER STORAGE TANK USER MANUAL
We continue to be committed to offering tools at competitive prices. “Save Half”, “Half Price”, or any other similar expressions used by us only represent an estimate of savings you might
benefit from buying certain tools with us compared to the major top brands and do not necessarily mean to cover all categories of tools offered by us. You are kindly reminded to verify carefully when placing an order with us if you are saving half in comparison with the top
major brands.
WATER STORAGE TANK
MODEL:WT-0240/WT-0330/WT-0540
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to
contact us:
This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won’t inform you again if there are any technology or software updates on our product.
1
NOTES 1. Keeping the outlet valve closed, fill in the liquid from the inlet valve on the top. 2. The diameter of the water injection tube should be less than 1.5″ so that the air in the tank can be discharged. 3. Ensure all accessories are firmly tightened by hand. Improper tightening of accessories can lead to leakage.
Model
MODEL AND PARAMETERS
WT-0240
WT-0330
WT-0540
Capacity
240L
330L
540L
Material
PVC
PVC
PVC
Ambient
-30+70 -30+70 -30+70
temperature
Color
Black
Black
Black
Product Size
100x70x35cm 120x80x35cm 150x90x40cm
TRUCTURE DIAGRAM
1.Top intake(1.5″) 3.Bag body
2.Hanging ring(It’s actually at four corners) 4.Scale
2
5.Drain valve(1.5″)
No. 1 2 3 4
COMPONENTS
PART
NAME
Rain bag
Drain valve
Patch
User manual
QTY 1 1 2 1
USE AND CLEAN 1. After getting the product, unroll the rain bag.The water inlet is at the top.
2. Install water outlet valve(Clockwise tightening). The outlet valve is larger and needs to be installed more forcefully until the valve is centered.
The status is off. 3
MAINTAIN AND STORAGE 1. Please use mild detergent and water for cleaning. 2. Don’t scrub with hard objects like brushes. 3. Dry before storage.Do not store in a dark, damp place. 4. Clean the debris at the filter port in time to avoid clogging. 5. If the barrel body is damaged, it can be repaired with the attached patch (Please bring your own glue). 6. If the joint is leaking, tighten the joint or wrap waterproof tape(Provide for yourself) on the thread of the joint before installing it(As shown below).
Note: If you install and remove the connector yourself and the switch is not vertical, try increasing the number of winding laps of waterproof tape.
4
Manufacturer: Haining Tak Techtextil Industries Co., Ltd. ADD: No. 2, Qingyuan Road, Xieqiao Town, Haining City, Jiaxing City, Zhejiang Province, China Importer: WAITCHX Address: 250 bis boulevard Saint-Germain 75007 Paris Importer: FREE MOOD LTD Address: 2 Holywell Lane, London, England, EC2A 3ET
Made in China
