CART-WB48A 48 Inch x 32 Inch Mobile Double Sided Whiteboard
Product Information
The 48 x 32 Mobile Double Sided Whiteboard (SKU: CART-WB48A) is
a versatile and portable whiteboard that can be used for
presentations, meetings, brainstorming sessions, and more. The
whiteboard comes with casters for easy mobility, a mid support,
vertical supports, a base support, a marker tray, and a rotation
lock. The board is double-sided, providing ample writing space and
can be rotated using the rotation lock for easy access to both
sides. The whiteboard is designed for adult use and should be kept
away from children under three years of age due to small parts that
can pose a choking hazard.
Product Usage Instructions
- Begin by assembling the casters (H) to the feet (C) using the
wrench (J). - Attach the feet to the vertical supports (B) using the M6x30mm
bolts (M) and tighten with the 5mm Allen Wrench (I). - Fasten the mid support (E) and base support (D) to the vertical
supports using M6x30mm bolts (M). Tighten with the 5mm Allen Wrench
(I). Cover the bolts with bolt caps (L). - Assemble the marker tray (F) to the mid support using a M4x16
screw (N) at each end. Attach the rotation lock (G) to the marker
tray and mid support using M4x16 screws. Tighten all screws with
5mm Allen Wrench (I). - Slide the board (A) into the frame and cover the open ends of
the vertical supports with pole caps (K). - To rotate the board, push down on the rotation lock (G) and
rotate the board to the desired position. - To clean the surface of the whiteboard, use a mild dish washing
liquid and a soft cloth.
If any parts are received damaged or defective, please contact
the VIVO support team for immediate assistance.
48″ x 32″ Mobile Double Sided Whiteboard
Instruction Manual
SKU: CART-WB48A
Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/cart-wb48a
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
www.vivo-us.com Chat live with an agent!
309-278-5303
WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or inappropriate use.
TIPOVER WARNING
SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER: · NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF CART. · USE TIPOVER RESTRAINT OR ANCHOR CART TO WALL USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIPOVER.
WARNING: CHOKING HAZARD
SMALL PARTS – NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
PACKAGE CONTENTS
A (x1) Board
E (x1) Mid Supprt
B (x2) Vertical Support
F (x1) Marker Tray
C (x2) Feet
D (x1) Base Support
G (x1) Rotation Lock
H (x4) Caster
I (x1)
J (x1)
5mm Allen Wrench Wrench
K (x2) Pole Cap
L (x8) Bolt Cap
M (x12)
N (x4)
M6x30mm Bolt M4x16mm Screw
NOTE: NOT ALL HARDWARE INCLUDED WILL BE USED
ASSEMBLY STEPS
STEP 1
Fasten casters (H) to feet (C) using the wrench (J). Install feet to vertical supports (B) using M6x30mm bolts (M) and tighten with the 5mm Allen Wrench (I).
2
STEP 2
Fasten mid support (E) and base support (D) to vertical supports using M6x30mm bolts (M). Tighten with the 5mm Allen Wrench (I). Press the bolt caps (L) into holes to cover bolts. Assemble marker tray (F) to mid support using a M4x16 screw (N) at each end. Attach rotation lock (G) to marker tray and mid support using M4x16 screws. Tighten all screws with 5mm Allen Wrench (I).
STEP 3
Slide board (A) into frame. Cover open ends of vertical supports using pole caps (K).
STEP 4
Push the rotation lock down to release and rotate board.
CLEANING TIP: A mild dish washing liquid can be used with a soft cloth to clean the surface.
3
Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us
LAST UPDATED: 03/21/2022 REV1
Open Monday – Friday 7:00am – 7:00pm CST, our dedicated support team can offer immediate assistance with rapid response times. If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
309-278-5303
AVG. RESOLUTION TIME (within office hrs): 5M 4S
www.vivo-us.com
Chat live with an agent!
AVG. RESOLUTION TIME (within office hrs): < 15 M
AVG. RESPONSE TIME (within office hrs): 1HR 8M – 23% within < 15m – 38% within < 30m – 61% within < 1hr – 83% within < 2hr – 92% within < 3hr
FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com
