P3 Pro Wireless Pen Machine
Product Information: – Product Name: Wireless Pen Machine –
Manufacturer: EZ Tattoo – Origin: China – Website: www.eztattoosupply.com – Power
Pack Stroke Adjustment Knob: Allows users to adjust the stroke
length of the machine – Motor: Equipped with a customized Swiss
motor made of aircraft aluminum – OLED Digital Display: Shows
battery capacity, Bluetooth indicator, hertz voltage, and timer –
Type-C Port: Used for charging the device – Battery Capacity: 1600
mAh – Recharging Time: 2 hours – Approx. Working Time: 4.5 hours –
Voltage Range: 5-12V DC – Adjustable Stroke: 2.0mm to 4.2mm –
Weight (with power pack-Bigger Grip): 8.7oz (247g) Usage
Instructions: 1. Power ON/OFF: Press and hold the power
button for two seconds to turn the P3 Pro On or Off. – Note: The P3
Pro has an Auto Power Off function that automatically turns off the
machine if it hasn’t been used for 5 minutes. 2. Power
START/STOP: Click the power button to start or stop the P3 Pro.
3. Adjust Voltage: Press the “+” or “-” buttons to adjust
the voltage in 0.1V increments. Press and hold these buttons to
quickly adjust the voltage. 4. Start/Stop Built-in Timer:
Press the timer button to activate the machine and start the timing
mode. – Note: The timer records in minutes, with a maximum
recording time of 999 minutes. The timer only counts when the
machine is running. It will reset when the P3 Pro is restarted. 5.
Push Mode: Press and hold both the “+” and “-” buttons
simultaneously to activate the push mode. The screen will solidify,
indicating that the machine is in push mode. – Note: In push mode,
the initial voltage output is 10V for 1 second and then returns to
the normal voltage. 6. Bluetooth and App Function: The P3
Pro has Bluetooth and App functions that will be released in the
future. These functions will allow users to control the machine and
perform various operations. Warranty Information: – Motor:
1-year warranty – Battery Pack: 6-month warranty – Spare Parts:
3-month warranty – Warranties do not cover damage caused by human
factors, external electrical failure, or accidents. Warranty
Card: Please send a copy of this card to: EZTATTOO-AFTER-SALES
DEPARTMENT 4/F BUILDING 7(7DONG)NO.289 FAHUA NORTH ROAD JINYI NEW
DISTRICT JINHUA 321036 ZHEJIANG CHINA TEL: +86-153-9755-3908 EMAIL:
[email protected]
WIRELESS PEN MACHINE
Thank you for reading! www.eztattoosupply.com
@EZTATOO OFFICAL Created and Manufactured in China by EZ
OVERVIEW
Type-C Port
Power Pack Stroke Adjustment Knob
Motor
37 mm
39 mm
OVERVIEW
OLED Digital Display Battery Capacity
Bluetooth Indicator
Hertz Voltage Timer
Voltage + Power Button Voltage –
POWER PACK
SPECIFICATIONS
1600 mAh
Battery Capacity
2
hrs
Recharging Time
4.5 hrs
Approx. Working Time
Unlocked In Future
@EZTATTOO OFFICAL
BASIC OPERATION
Power ON/ OFF
Press and Hold the power button for two seconds to turn P3 Pro On or Off.
Note: P3 Pro with a function (Auto Power Off) to turn off the power automatically if the machine has not been used for 5 mins.
Power START/ STOP
Click power button to power the P3 Pro Start or Stop.
Adjust Voltage
Press or to adjust in 0.1V increments. Press and Hold or to quickly adjust the voltage in 0.1V increments.
Start/ Stop Built-in Timer
Press button to active your machine ON, the timing mode start.
Note: timer mode record in minutes, the maximum recording time is 999 minutes. The time is counting only when machine is running. The timer will reset the count when the P3 Pro is being restarted.
Push Mode
Press and button at the same time, Screen solid, the machine active the push mode.
Note: In push mode the initial voltage output is 10V lasts for 1 second and then returns to normal voltage after.
And More…
Bluetooth and App function will release in future to control your P3 Pro Wireless Tattoo Pen Machine to perform various operations.
@EZTATTOO OFFICAL
SPECIFICATIONS
Motor Material Stroken Length Operating Voltage Six Options Adjustable Stroke
Rpm Switch Frequency Needle Protrusion Dimensions(X L)
Weight
EZ Customized Swiss Motor Aircraft Aluminum 2.0mm to 4.2mm 5- 12V DC
2.0, 2.4, 2.8, 3.3, 3.7, 4.2mm 12V/10000rpm ± 10% 60 – 170Hz 0 – 4.5 mm 32-39 mm x 135 mm
8.7oz(247g) with power pack-Bigger Grip
INCLUEDS
P3 Pro X1 User Guide Battery Type-C Charging
@EZTATTOO OFFICAL
WARRANTY INFORMATION
lf you find that the product is malfunctioning during the warranty period, EZ provides a
Motor–ONE Year Battery Pack–Six Months Spare Parts–Three Months warranty for the P3 Pro wireless pen machine purchased in our online store or authorized distributors worldwide form the date of purchase. Warranties do not cover: Damage to the product due to a human factor. Product damage due to axterrnal electrical failure or any accident.
WARRANTY CARD
PRODUCT NAME:_______________________________________________________ DATE OF PURCHASE:___________________________________________________ WHERE PURCHASED:___________________________________________________ ADDRESS:_____________________________________________________________ ______________________________________________________________________ EMALL:_______________________________________________________________ MY SIGNATURE BELOW ACKNOWLEDGES THAT I HAVE READ, FULLY UNDERSTAND, AND ACCEPT THIS LIMITED WARRANTY AGREEMENT. SIGNATURE:____________________ DATE:_________________________________
SENT THIS COPY TO:
EZTATTOO-AFTER-SALES DEPARTMENT
4/F BUILDING 7(7DONG)NO.289 FAHUA NORTH ROAD JINYI NEW DISTRICT
JINHUA 321036 ZHEJIANG CHINA
TEL: +86-153-9755-3908
EMAIL: [email protected]
NOTICE to reduce the risk of injury, the user must read and understand the User manual before using this product, Save these instructions for future reference. This device don’t support fast charging/super fast charging, fast charging may getdamage the battery. The battery circuitry protects the battery pack from extreme temperature, overdischarge, and over-charge. To protect the battery from damage and prolong its life, The battery packcircuitry will tum off the battery padk if it becomes overloaded or if the temperature becomestoo high during use. This may happen in extremely high torque, binding, and salling situations. The battery pack wil shut down for 105 when its operating temperature exceeds 158*F(70*C), and will begin normal operation when it returns to 152*F(67C).
