REDLINE SW16 1000Mbps Ethernet Switch
Introduction
Our high-Performance switch was designed for a network environment where traffic and the number of Users increases continuously, The switch is ideal for shared bandwidth 10Mbps or 1000Mbps workgroups with multiple high-speed servers, with the highest bandwidth at 2000Mbps(1000Mbps full-duplex mode), each port can provide a workstation with congestion-free data-pipe for simultaneous access to the server, The switch is a perfect choice for 10/100Mbps network site that could be upgraded to Fast Ethernet in the future, Ethernet workgroups can connect to the switch now, and change adapters and hubs anytime later without changing the switch or reconfiguring the Network, The Switch has several models 16/24p switch , each has a different port number, Other key features of every model are as followed:
Features
Common features
- Support IEEE802.3X for full duplex mode operation
- 10Base-T , 100Base-T, and 1000Base FX Operation
- Support Flow control for Full duplex mode operation and backpressure for half duplex mode operation
- LED Status of Power on, Link and speed
- Full line speed capability of 1488000(148800) packets/sec for 1000M(10m)
- Automatic MDI/MDI-X Configuration
- Communication distance: Not less than 100M
- Interface: 16/24 RJ45 Port
MAC Address and Bandwidth
| Product models | ports | Mac Address | Switching Capacity |
| 16/24p Gigabit switch | 16/24 | 8K | 32 G/48G |
Contents
- 16/24port Switch FIXED: Internal power supply, User Guide, power cable
LED Indicator
LED indicator Include: Power, link/act, 1000Mbps
| Indicator | Color | Status | Description |
| Power | RED | on | Switch Power on |
| off | Switch Power off | ||
| Link/Act | Green | On | Any Network device connected to corresponding port |
| Flash | Data transmitting between switch and network device | ||
| 1000M | Green | on | The Device connected to 100Mbps |
| off | The device connected to 10Mbps |
Physical and Environment
| Standards | IEEE 802.3 100BASE-T Ethernet IEEE802.3u 1000BASE-TX Fast Ethernet ANSI/IEEE 802.3 Nway Auto-Negotiation IEEE 802.3x Flow control |
| Protocol | CSMA/CD |
| Data transfer Rate | Ethernet: 100Mbps(Half duplex), 200Mbps(Full Duplex), Fast Ethernet: 1000Mbps(Half duplex),2000Mbps(Full Duplex) |
| Network cables | 100 BASE-T:2-Pair UTP Cat.3,4,5; EIA/TIA-568 100 Ohm STP 1000BASE-TX: 2-Pair UTP Cat.5; EIA/TIA-568 1000 Ohm STP 1000 BASE-FX:62.5/125 Micron multimode Fiber optic |
| Power supply | Internal power supply 100~240V AC 50/60Hz |
| Temperature &Humidity | Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing |
