SW5/8P 10/100/1000Mbps
Network SWITCH
USER MANUAL
Introduction
our high Performance switch was designed for a network environment where traffic and the number of Users increase continuously, The switch is ideal for shared bandwidth 100Mbps or 1000Mbps workgroups with multiple high-speed servers, with the highest bandwidth at 2000Mbps(1000Mbps full-duplex mode), each port can provide workstation with congestion-free data-pipe for simultaneous access to the server,
The switch is a perfect choice for 1000Mbps network site ,Ethernet workgroups can connect to the switch now, and change adapters and hubs anytime later without changing the switch or reconfiguring the Network,
The Switch has several models 5/8p switch , each has different port number, Other key features of every model are as followed:
Features:
- Common features
—Support IEEE802.3X for full duplex mode operation
—10Base-T , 100Base-T, and 1000Base FX Operation
—Support Flow control for Full duplex mode operation and backpressure for half duplex mode operation
—LED Status of Power on, Link and speed
—Full line speed capability of 1488000(148800) packets/sec for 1000M(100m)
—Automatic MDI/MDI-X Configuration
—Communication distance: Not less than 100M
—Interface: 5/8 RJ45 Port - MAC Address and Bandwidth
| Product models | ports | Mac Address | Switching Capacity | Bandwidth |
| 5/8p Gigabit switch | 5/8 | 4K | 16Gbps | 1.6G |
LED Indicator
LED indicator Include: Power, link/act, Speed
| Indicator | Color | Status | Description |
| Power | Blue | on | Switch Power on |
| off | Switch Power off | ||
| Link/Act/1000Mbps | Blue | On | Any Network device connected to corresponding port |
| Flash | Data transmitting between switch and network device |
Physical and Environment:
| Standards | IEEE 802.3 10BASE-T Ethernet IEEE802.3u 100BASE-TX Fast Ethernet ANSI/IEEE 802.3 Nway Auto-Negotiation IEEE 802.3x Flow control |
| Protocol | CSMA/CD |
| Data transfer Rate | Fast Ethernet: 100Mbps(Half duplex), 200Mbps(Full Duplex), Ethernet: 1000Mbps(Half duplex),2000Mbps(Full Duplex) |
| Network cables | 100 BASE-T:2-Pair UTP Cat.3,4,5; EIA/TIA-568 1000 Ohm STP 1000BASE-TX: 2-Pair UTP Cat.5; EIA/TIA-568 100 0Ohm STP 1000 BASE-FX:62.5/125 Micron multimode Fiber optic |
| Power supply | EXTERNAL Power supply 5VDC/1A |
| Temperature &Humidity | Operation: 0~60 , Storage: -10~70 Humidity: 10%~90%, Storage: 5%~90% |
