HDV-MB02 iTrans AD02 HDMI 18Gbps Audio Extractor
Product Information: iTrans AD02 HDMI 18Gbps Audio Extractor
with Audio Downmix
The iTrans AD02 is a high-performance HDMI audio extractor that
allows you to extract HDMI audio to multi-channel optical (SPDIF)
or L/R analog audio. It is HDMI 2.0b, HDCP 2.2, and DVI compliant,
and supports video resolutions up to 4K2K@50/60Hz (YUV444). The
AD02 also supports bitstream audio down-mix to L/R analog output
and optical audio formats including LPCM 2CH, Dobly Digital
2/5.1CH, and DTS 2/5.1CH.
Features:
- HDMI 2.0b (18Gbps), HDCP 2.2 and DVI compliant
- Video resolutions up to 4K2K@50/60Hz (YUV444)
- Extract HDMI audio to multi-channel optical (SPDIF) or L/R
analog audio - HDMI Pass-through audio input to HDMI and optical audio
output - Support bitstream audio down-mix to L/R analog output
- Optical audio supports LPCM 2CH, Dobly Digital 2/5.1CH, DTS
2/5.1CH - Support HDMI High Bit Rate(HBR) audio pass through
- Audio sample rates up to 96kHz
- 10bits HDR (High Dynamic Range) pass through
- Support CEC pass-through
Package Contents:
- 1x iTrans AD02 HDMI 18Gbps Audio Extractor with Audio
Downmix - 1x AC Power Adapter
- 1x User Manual
Specifications:
The iTrans AD02 HDMI 18Gbps Audio Extractor with Audio Downmix
has the following specifications:
- HDMI Compliance: HDMI 2.0b
- HDCP Compliance: HDCP 2.2 and HDCP 1.4
- Video Bandwidth: 18Gbps
- Video Resolutions: Up to 4K2K@50/60Hz(YUV4:4:4),
4K2K@30Hz,1080P@120Hz, and 1080P 3D@60Hz - Color Space: RGB, YCbCr 4:4:4, YCbCr 4:2:2
- Color Depth: 10-bit, 12-bit
- HDMI Audio Formats: LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1,
Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos,
DTS:X (Pass-through) - Optical Audio Formats: LPCM 2CH, Dobly Digital 2/5.1 CH, DTS
2/5.1CH - L/R Audio Formats: Analog Stereo 2CH
- ESD Protection (contact discharge)
Operation Controls and Functions:
The iTrans AD02 HDMI 18Gbps Audio Extractor with Audio Downmix
has the following operation controls and functions:
5.1 Front Panel:
- DC 5V: Connect 5V/1A adapter to AC wall outlet for power
supply. - Power LED: System power indicator.
5.2 Rear Panel:
- HDMI IN: Connect HDMI input source device.
- HDMI OUT: Connect HDMI output display device.
- OPTICAL OUT: Connect optical audio output device.
- L/R AUDIO OUT: Connect analog audio output device.
Application Example:
The iTrans AD02 HDMI 18Gbps Audio Extractor with Audio Downmix
can be used in the following application example:
- Connect HDMI input source device to HDMI IN port of iTrans
AD02. - Connect HDMI output display device to HDMI OUT port of iTrans
AD02. - Connect optical audio output device to OPTICAL OUT port of
iTrans AD02. - Connect analog audio output device to L/R AUDIO OUT port of
iTrans AD02. - Connect 5V/1A adapter to AC wall outlet for power supply.
- Switch on the power button to start the operation.
Note: Surge protection device is recommended to protect and
extend the life of your equipment.
iTrans AD02
HDMI 18Gbps Audio Extractor with Audio Downmix
VER 1.1
www.infobitav.com
Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment.
Table of Contents 1. Introduction…………………………………………………… 1 2. Features………………………………………………………….2 3. Package Contents…………………………………………. 3 4. Specifications………………………………………………… 3 5. Operation Controls and Functions………………….. 5
5.1. Front Panel…………………………………………….. 5 5.2. Rear Panel………………………………………………6 6. Application Example………………………………………7
1. Introduction The HDMI 18Gbps Audio Extractor could extract audio signals from any HDMI compliant source to digital optical or analog stereo L/R audio outputs. For maximum flexibility, this audio extractor also supports bitstream audio down-mix to analog stereo output and keeps optical and HDMI out audio passthrough. Further, both input and output HDMI support video resolution up to 4K2K@50/60Hz (YUV444). It supports 10bits HDR (High Dynamic Range) pass through and HDMI high resolution digital audio formats bypass, LPCM 2CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and DTS-HD Master Audio, audio sampling rate up to 192 kHz. HDCP 2.2 and CEC bypass are supported.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
1/7
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, DTS and the Symbol together, and Digital Surround are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries. © DTS, Inc. All Rights Reserved.
2. Features
HDMI 2.0b (18Gbps), HDCP 2.2 and DVI compliant Video resolutions up to 4K2K@50/60Hz (YUV444) Extract HDMI audio to multi-channel optical
(SPDIF) or L/R analog audio HDMI Pass-through audio input to HDMI and
optical audio output Support bitstream audio down-mix to L/R analog
output Optical audio supports LPCM 2CH, Dobly Digital
2/5.1CH, DTS 2/5.1CH Support HDMI High Bit Rate(HBR) audio pass
through Audio sample rates up to 96kHz 10bits HDR (High Dynamic Range) pass through Support CEC pass-through
2/7
3. Package Contents
1× HDMI 18Gbps Audio Extractor 1× 5V/1A Power Adapter 1× User Manual
4. Specifications
Technical
HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 and HDCP 1.4
Video Bandwidth 18Gbps
Up to 4K2K@50/60Hz(YUV4:4:4),
Video Resolutions 4K2K@30Hz,1080P@120Hz,
and 1080P 3D@60Hz
Color Space
RGB, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth
10-bit, 12-bit
LPCM 2/5.1/7.1CH, Dolby Digital, HDMI Audio Formats DTS 5.1, Dolby Digital+, Dolby (Pass-through) TrueHD, DTS-HD Master Audio,
Dolby Atmos, DTS:X
Optical Audio Formats
LPCM 2CH, Dolby Digital 2/5.1 CH, DTS 2/5.1CH
L/R Audio Formats Analog Stereo 2CH
ESD Protection
Human body model — ±8kV (air-gap discharge) & ±4kV
(contact discharge)
3/7
Connections Inputs
1x HDMI Type A [19-pin female]
Outputs
1x HDMI Type A [19-pin female] 1x L/R Audio Out [RCA] 1x Optical Out [S/PDIF]
Mechanical
Housing Color
Dimensions
Metal Enclosure Black 73.5mm[W] x 60.7mm[D] x 20mm[H]
Weight
135g
Input: AC100 – 240V 50/60Hz
Power Supply
Output: DC 5V/1A (US/EU
standards, CE/FCC/UL certified) Power Consumption 1.25W (Max)
Operation Temperature
32 – 104°F / 0 – 40°C
Storage temperature -4 – 140°F / -20 – 60°C
Relative Humidity 20 – 90% RH (no condensation)
4/7
5. Operation Controls and Functions 5.1 Front Panel
Bitstream
DC 5V
TV 2CH
HDMI IN
12 3
4
5
Number Name
Function Description
1 DC 5V
Connect 5V/1A adapter to AC wall outlet for power supply.
2 Power LED System power indicator.
The user allows to select audio
format according to Copy TV,
Bitstream or 2CH.
3
TV/Bitstream /2CH
TV: Copy EDID from TV. Bitstream: Multi channel up to six channels.
audio
2CH: 2 channel Stereo PCM.
4 HDMI IN HDMI video input.
Red illuminate: PCM decoder
5
Status LED
or No signal Red blinking: Dolby decoder
Green blinking: DTS decoder
5/7
5.2 Rear Panel
HDMI OUT OPTICAL OUT R OUT L
1
2
3
Number Name
1 HDMI OUT
2
OPTICAL Out
3 R/L OUT
Function Description
HDMI output for display connectivity.
Toslink digital audio output (mirrors HDMI).
Stereo RCA analog audio output.
6/7
6. Application Example
AV Receiver
UHDTV
HDMI OUT OPTICAL OUT R OUT L
Power Supply
DC 5V
Bitstream TV 2CH
HDMI IN
Active Speakers
DVD or Blu-ray Player
7/7
