ECO.100S-CT Magnetic Drilling Machine
Product Information
The product is a motorized tool with various parts and
components. The tool has a control unit, motor, carbon brush holder
assembly, torque switch housing, spindle gear, gear box, rear
panel, and other parts. The product comes in two variants –
ECO.100S+ and ECO.100T.
Product Usage Instructions
- Before using the tool, ensure that all parts are properly
assembled and tightened. Refer to the exploded views and spare
parts list provided in the user manual. - Connect the motor to a power source. Use the appropriate motor
based on the voltage required – 220V for ECO.100S+ and 110V for
ECO.100T. - Turn on the tool using the control unit on top of the
tool. - The tool can be used for various applications such as drilling,
cutting, grinding, and polishing. Use the appropriate accessory and
attachment based on the application. - Be careful while using the tool and follow all safety
precautions mentioned in the user manual. - After use, turn off the tool and disconnect it from the power
source. Clean and store the tool in a safe place.
8. Exploded views & spare parts list
8.1 Exploded views
32
33
34
8.2 Sparepart lists ECO.100S+/T
No. Part no.
Description
Qty
1
100S.1001
Motor 220V ECO.100S+
1
100S.1001A
Motor 110V ECO.100S+
2
050.0106
Screw 4.8 x 45
4
3
100.0322Z
End cover
1
3A
P020.0278 P020.0278A
LED red alarm 220V LED red alarm 110V
1
4
032.0116
Screw M4 x 16
2
5
100.4006
Control unit top ECO.100 110V/220V
1
6
7
9 10 100.0372 11
Carbon brush holder assembly
2
12
13
8(A)
Carbon.100+ Carbon.100A+
Carbon brush set 220V Carbon brush set 110V
1
14 100.4388
Housing
1
14A CS100.0342/2 Cable set 1608 ->
1
15 100.4576
Torque switch housing 1
16 100.4574
Wheel red
1
17 100.4573
Torque poteniometer 1 K 1
18 100.0611
T/S switch cap V1 – V3
1
19 100.0617
Screw PKVZ 6 x 45
4
20
100.1004-CK-1 Field 220V 100.1004A-CK-1 Field 110V
1
21 100.0391
Baffle
1
22 100.0346
Rubber fitting ring
1
23 100.0348
Armature speed disk 1800W/1900W
1
24 080.0351
Bearing 6000
1
25A
100S.1011 100S.1012
Armature set 220V Armature set 110V
1
26 032.0166
Circlip 472/28/1.2
1
27 050.9070
Bearing 6001V V
1
27A 100S.0064
Bearing 15 x 23 x 3
1
28 100S.0401X
Inner gear plate
1
28A 100S.0071
O-ring 106 x 1.8
1
29 100.0571
Circlip 471 11 x 1
1
30 100.0458
Gasket big
1
31 130.0065
Ring metal
1
32 100S.1006
Clutch shaft
1
33 100.0426
Circlip 471 24 x 1.2
1
34 080.4324
Spindle gear 38T
1
35 080.4411
Adapter ring
6
36 100.0446
Bearing 6005
2
37 040.0161
Needle bearing HK0810 3
No. Part no.
38 100.4312 38A 080.4321 38B 100.4350 38C 100.4351 38D 100.4338 38E 100.4340 38F 100.4344
Description
Qty
Friction clutch complete
assembly(7T)
1
Axle 1 (ECO.80 -> 1412)
1
Nut M10
1
Washer 12 x 18 x 1
1
Friction lock disk 1
1
Brass disk 1
1
First gear 36T
1
38G 100.4349
Brass disk 2
1
38H 100.4353
Friction lock disk 2
1
38I 100.4352
Tension shell 28
6
39 080.0506
Bearing
2
40 100.4321
Axle 1 28+13T
1
41 040.0301
Key
1
42 100.4491
Double gear 1 25T+39T
1
43 100.4320
Double gear 2 36T+41T
1
44 100.4334
Axle 3 (13T)
1
45 080.0526
Key 3
1
46 080.4486
Washer 14 x 22 x 1
1
47 080.0481
Needle bearing
1
48 100S.1007
Clutch shaft
1
49 100.0549
Casing pin
1
50 100S.1017
Gear box
1
51 100S.1014
Gear switch
2
52 100.0459
Screw BK 5.5 x 45
4
53 050.0078
Ring 41.5 x 36.5 x 1.5
2
54 020.0329
Screw M4 x 16
2
55 050.0082
Screw holder
2
56 080.0431
Key spindle 6 x 6 x 20
1
57 100.0901
Spindle drive shaft
1
58 100S.0076
Rack 1.5 x 58T
1
59 020.0003
Pin
2
60 020.0106
Screw M6 x 14
8
60A 360.1025
Bolt M6 x 14
2
61 020.0111
Washer M6 DIN7980
12
62
100S.0462X
Slide
1
63 020.0146B
Screw M6 x 35
1
64 020.0146
Screw M6 x 25
1
65 100S.0067
Wool felt ring
1
66 100S.0066
Bearing NKX-45
1
67 100S.0065
Bearing 35 x 42 x 8
1
68 KSP.MS
Screw M5 x 10
1
69 020.0298
Motor cable clamp
1
70 KSP.MS
Screw M5 x 10
2
71 KSP.M/3
Tank holder
1
72
080.0016BX.5A Rear panel 220V 080.0016AX.2A Rear panel 110V
1
35
No. Part no. 73 020.0101 78A 100.1028
100.1028A 80 100.0022
81 100.0193A
82 100.0193B
83
100.4002
58 100.0003
84 020.0081 85 020.0077H 86 100SCT.1002 87 020.0516 87A 020.0386 88 100.4610 88A CS100.0341/2 89 020.0032 89A 020.0033 90 100.0101H 91 020.0314X
100.1016 020.0036/AU 020.0036/UK 020.0036/UK 92 110-32A
100.1016A
020.0031
93
93A 020.0182
94
95 100SCT.0008X
96 100.0152
030E.0091/Y
97
030E.0092/Y
98 020.0017 99 020.0016
100 020.0206
101
102
93
103 104 105 105A
020.0011/1 100.1009
020.0037
100SCT.0001 020.0139
Description
Qty
Panel screw BKVZ M4 x 8 8
Speed control unit 220V 1
Speed control unit 110V
Bolt M5 x 20
12
Aluminium rail (L) 22 x 18.5 x 442.5
1
Aluminium rail (R) 22 x 18.5 x 442.5
1
Control unit 2 ECO.100
220V 1501>
1
Control unit 110V 1800W
1
End screw BKVZ M6x16 1
End plate black
1
Frame
1
Screw M5 x 10
6
Stop screw
2
Motor cable completeV6 1
Cable set 1608 ->
1
Adapter PG9 – PG11
2
Coupling nut PG11
2
Capstan hub black
1
Arm for capstan
3
Main cable 220V EU
Main cable 220V AU
Main cable 220V UK
Main cable 110V UK 32A 1
Main cable 110V USA
Coupling nut PG11 (main cable)
1
Grounding screw/washer/nut
1
Front panel
1
R/L switch(push)
1
Motor switch 220V (5-
pin) YELLOW
Motor switch 110V (5- 1
pin) YELLOW
Fuse 5 x 20 F2A
1
Fuse holder
1
LED indicator set
1
Magnet switch
1
Potentiometer
1
Cable clamp complete 1
No. 105B 105C 106
106A
Part no. B60.0030 B60.0042 100SCT.1004 100SCT.1004A
020.0123
106B 020.0122
106C 020.0129
106D
106E 106F 106G 106H 106I 107 108A 108B 108C 200 201 202
203
020.0124
020.0074 030.0021 020.0046 020.0041 020.0261 100.1010 100A.0014 020.0305 100A.0015 100SCT.1005 100S.2019 IBO.0.2L PRM.61 PRM.62
PRM.63
204 SAF.400
205 SAF.100 206 SAF.200 207 KSP.P 208 IMB.US2.5 209 IMB.US4 210 IMB.US5 211 IMB.US6
212 IMB.US8
213 100S.0002 214 DRIFT3
215 080.2009
216 IBK.3219 217 IBK.MC3-L121 218 MC3-ER32
Description
Qty
Washer M10
4
Washer M10
4
Magnet complete 220v Magnet complete 110v
1
Magnet
1
Screw M3 x 8
6
Magnet cover
1
Adapter
1
Screw M5 x 12
2
Coupling nut PG9(elbow) 1
Coupling nut PG9
1
Bellows AD13
1
Reed switch
1
Filter
1
Screw M8x25
4
Washer M8
4
Washer M8
Case
1
Coolant tank
1
Bottle 0.2LTR
1
EUROBOOR gloves M
EUROBOOR gloves L
1
EUROBOOR gloves XL
Safety chain (1 mtr) with lock
1
Safety goggles
1
Ear plugs
1
Pin and knob for cooling tank
1
Allen key 2.5 mm
1
Allen key 4.0 mm
1 1
Allen key 5.0 mm
Allen key 6.0 mm
1
Allen key 8.0 mm
1
Side handle M12
1
Drift MT3
1
Spindle MT3 31.75 mm Weldon (1 1/4″)
1
Reducing ring Weldon 31.75mm 19.05mm
1
Extension MT3
1
MT3 Milling chuck(optional)
1
Cross slide table Screw
1 4
