6CUwheelbarrow v6 CU FT Poly Dual Wheel Flat Free Wheelbarrow

Product Information

Item #: 1006456732

Model: 6CUwheelbarrow

Product Name: 6 CU FT POLY DUAL-WHEEL FLAT-FREE WHEELBARROW

Manufacturer: Husky

Max Load Capacity: 250 lb (120 kg)

Safety Information

• Please read, understand and follow all instructions before
  using this product.
• Do not exceed the total maximum load capacity of 250 lb (120
  kg).
• The rated weight is based on a uniformly distributed load.
• This wheelbarrow is not suitable for use on highways or
  high-speed use.
• Distribute the load evenly on the surface of the tray.
• Do not place items on the top edge of the tray.
• If any parts are damaged, cracked or misplaced, please do not
  use the cart before replacing the parts.
• Do not use the wheelbarrow on a surface that will damage the
  tires.
• It is recommended to check each usage of the wheelbarrow.
• Do not allow children to use the wheelbarrow without
  supervision.
• Do not use this wheelbarrow to transport passengers.
• Tire changing and/or inflation can be dangerous and should be
  done by trained personnel using proper tools.

Tools Required

• Slotted screwdriver
• Wrench

Hardware Included

Package Contents

Assembly Instructions

1. Attach the wedges (E) to the tray (A) using bolts (AA &
   BB).
2. Place the handles (B) over the bolts and lower onto wedges
   (E).
3. Attach the legs (C) to the handle using bolts, washers, and
   nuts (AA & BB).
4. Attach the leg brace (D) across the back of leg (C) using
   bolts, washers, and nuts (DD).
5. Attach the nose guard (F) to front of handles (B) using bolts,
   washers, and nuts (CC).
6. Attach the axle bracket (H) to the bottom of handle (B) using a
   bolt (CC) pushed through the hole closest to tray.

Remember to read and follow all safety rules and operating
instructions before using this product. Keep this manual for future
reference. If you have any questions or need further assistance,
please contact 1-888-43-HUSKY.

Item #1006456732 Model #6CUwheelbarrow
USE AND CARE GUIDE
6 CU FT POLY DUAL-WHEEL FLAT-FREE WHEELBARROW
Questions, problems, missing parts? Before returning to the store, call Husky Customer Service 8 a.m. ­ 7 p.m., EST, Monday-Friday 9 a.m. ­ 6 p.m., EST, Saturday 1-888-43-HUSKY HUSKYTOOLS.COM
THANK YOU
ly create quality products designed to enhance your home. Visit us online to see our full line of products available for your
home improvement needs. Thank you for choosing Husky!

Table of Contents

Table of Contents

2

Safety Information

2

Pre-installation

2

Planning Installation

2

Safety Information

Before using this product, please read, understand and follow all instructions.
Do not exceed the total maximum load capacity of 250 lb
(120 kg). The rated weight is based on a uniformly
distributed load. This wheelbarrow is not suitable for use on highways or
high-speed use.
Distribute the load evenly on the surface of the tray. Do not place items on the top edge of the tray. If any parts are damaged, cracked or misplaced, please do
not use the cart before replacing the parts. Do not use the wheelbarrow on a surface that will damage
the tires. It is recommended to check each usage of the wheelbar-
row. Keep this manual for future reference.

Tools required

2

HARDWARE INCLUDED

3

Package Contents

3

Assembly

4

DANGER: Do not allow children to use the wheelbarrow without supervision.
WARNING: Do not use this wheelbarrow to transport passengers.
WARNING: Tire is not for highway service.
WARNING: Tire changing and/or inflation can be dangerous and should be done by trained personnel using proper tools.

Pre-Installation
PLANNING INSTALLATION
Read and follow all safety rules and operating Instructions before using this product
TOOLS REQUIRED (Not included)

slotted screwdriver

Wrench

2

Pre-installation (continued)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.

AA

BB

DD

EE

Part

Description

Quantity

AA

M8x130 mm bolt, washer, and nut

2

BB

M8x70 mm bolt, washer, and nut

2

CC

M8x58 mm bolt, washer, and nut

6

DD

M8x23 mm bolt, washer, and nut

6

EE

Cotter pin

2

FF

Washer

2

PACKAGE CONTENTS

CC FF

A

B

C

D

Part Description

A Tray

B Handle

C Leg

D Leg brace

F

G

E Wedge

H

F Nose guard

G Wheel

H Axle bracket

I Axle

I

J

J Tray Brace

E
Quantity 1 2 2 1 2 1 2 2 1 2

3

HUSKYTOOLS.COM

Please contact 1-888-43-HUSKY for further assistance.

Assembly
1 Attaching Wedges to Tray
Push bolts (AA & BB) through bottom of tray (A) and through wedge (E).
Repeat for second wedge.

2 Placing Handles on Wedges
Turn tray (A) over, so the tray is at an angle of 45 degrees to the ground.
Place handles (B) over bolts and lower onto wedges (E).
B E

A

E

BB

AA

3 Attaching the Legs
Make sure the holes in leg (C) are facing the back of the tray.
Place leg over bolts (AA & BB) and loosely attach to handle with washers and nuts.
Repeat for other leg.
C
AA BB

A

4 Attaching the Leg Brace
Place leg brace (D) across the back of leg (C) and loosely attach using bolts, washers, and nuts (DD).
Repeat to attach the other end of the leg brace to the other leg.

C

D

DD

4

Assembly (continued)
5 Attaching the Nose Guard
Use bolts, washers, and nuts (CC) to attach nose guard (F) to front of handles (B).
B
CC

6 Attaching the Axle Bracket and Tray
Braces
Attach axle bracket (H) to bottom of handle (B) using a bolt (CC) pushed through the hole closest to tray.
Push second bolt (CC) through hole with tray brace (J) then through handle (B).
Attach the tray braces (J) on to the tray, align the holes and secure with bolts, washers, and nuts (DD).
H

F CC

CC J

DD
7 Attaching the Axle and Wheels
Slide axle (I) into attached axle bracket (H). Attach wheels (G) on to both ends of the axle (I). Secure the wheels (G) with washers (FF) and cotter pins (EE). Fully tighten all nuts.

I G
H

EE FF

5

HUSKYTOOLS.COM

Please contact 1-888-43-HUSKY for further assistance.

Questions, problems, missing parts? Before returning to the store, call Husky Customer Service
8 a.m. ­ 7 p.m., EST, Monday-Friday, 9 a.m. ­ 6 p.m., EST, Saturday
1-888-43-HUSKY HUSKYTOOLS.COM
Retain this manual for future use.
