Lekolar E-motion 2 Legs For Angeled Tabletops. 90+70 Legs Instruction Manual

E-Motion 2 Legs For Angeled Tabletops. 90+70 Legs

Product Information:

The E-Motion 2-legs is a product designed for angled tabletops.
It consists of two legs with lengths of 90cm and 70cm respectively.
The product includes screws and cables for assembly, as well as a
crossbar, an adjusting panel, an adapter, and cable clips.

• Legs: The product comes with two legs. One leg
  has a length of 90cm, and the other leg has a length of 70cm.
• Screws: The screws provided for assembly are
  as follows:
  • 5x20mm screws: These screws are used to attach the crossbar to
    the desktop.
  • M6x16mm screws: There are a total of 8 pcs of M6x16mm screws.
    Two of these screws are used for the upper part of the legs, and
    the remaining six screws are used for other assembly purposes.
  • M6x20mm screws: There are a total of 8 pcs of M6x20mm screws.
    Four of these screws are used for the bottom part of the legs.
• Crossbar: The product includes a crossbar that
  consists of three parts.
• Cables: The product includes the following
  cables:
  • 2-meter cable: This cable is included with the crossbar.
  • 180 cm cable: This cable is included with the adapter, which is
    used for connecting the product to a 220V power source.
• Adjusting Panel: The product includes an
  adjusting panel that requires two 3.5×20 screws for
  installation.
• Cable Clips: Three cable clips are provided to
  help organize and secure the cables.

Product Usage Instructions:

1. Start by assembling the legs. Attach the 90cm leg and the 70cm
   leg to the tabletop using the appropriate screws.
2. Use the 5x20mm screws to secure the crossbar to the
   desktop.
3. Attach the adjusting panel to the product using two 3.5×20
   screws.
4. Connect the cables as follows:
   • Attach the 2-meter cable to the crossbar.
   • Connect the 180 cm cable to the adapter.
5. Use the cable clips to organize and secure the cables.
6. Finally, connect the adapter with the 220V power source to
   power the product.

ASSEMBLING INSTRUCTION E-Motion 2-legs for angeled tabletops. 90+70 legs

Screw for wood, 5x20mm screws up from crossbar to the desktop

M6x16mm 2 pcs (upper)

M6 x16mm 2 pcs

M6 x16mm 2 pcs

Length legs:90cm

M6x20mm 4 pcs (leg bottom)

– Crossbar containing 3 parts – 1 pcs. 2-meter cabel – 1 pcs. adjusting panel (2 pcs 3,5×20 screws) – 1 pcs adapter w/180 cm cable for 220 V 3 pcs cabel clips

M6x20mm 4 pcs (leg bottom)
M6 x 16, total 8 pcs M6 x 20, total 8 pcs

M6 x16mm 2 pcs (upper)
Length legs:70cm
