HEX-FLAT6
User Manual
Safety
Important Safety Information
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT OVEREXPOSE THIS FIXTURE TO RAIN OR MOISTURE.
WARNING: CONNECT ONLY TO MAINS POWER SUPPLY WITH A PROTECTIVE EARTHING CONNECTION.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE THE REAR COVER OR ATTEMPT TO OPEN THE LIGHTING FIXTURE. THERE ARE NO USER-SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL.
- Read this manual
- Keep this manual safe for future
- Follow all warnings and
- Do not operate or store near
- Do not expose the fixture to dripping or splashing liquid, and ensure that no objects containing liquid are placed on this fixture.
- Clean only with a dry
- Do not install or operate near any heat sources such as radiators, gas heaters, stoves, or other heating
- Only use attachments and accessories specified by the
- Do not block any ventilation openings, including sound
- Install in accordance with the manufacturer’s
- Do not obstruct or remove the ground plug from the fixture, doing so may cause electric shock resulting in serious injury or
- Protect the power cord from being walked on, pinched, or rolled
- Unplug the fixture during electrical storms and power
- Refer all servicing to a qualified service technician. Servicing is required when the fixture no longer operates, fails to power on, or emits an electrical smell or sound.
- To completely disconnect AC power from this fixture, the power supply cord must be
Precautions
If an AVE lighting fixture is used outdoors on a sunny day, ensure that it is in a shaded area and is well ventilated to help prevent overheating.
Do not use AVE lighting fixtures in environments that are below 0°C OR exceed +40°C.
Suspension
Suspending any object is potentially dangerous and should only be attempted by qualified individuals with thorough knowledge of the techniques and regulations for suspending objects. It is the responsibility of the installer to ensure all fixtures and effects are installed correctly. AVE strongly recommends inspecting installed systems every 6 months for signs of weakness or damage. If any damage or weakness is detected then remedial action should be taken immediately. The user is responsible for making sure the wall, ceiling, or structure is capable of supporting all objects suspended overhead. Any hardware used to suspend the fixture not associated with AVE is the responsibility of others.
Features
- High-output 6x 12W LEDs
- Hex Colour diodes (RGBAW+UV) for great colour spectrum mixing
- Lightweight ABS housing
- 3-Pin XLR connections for DMX control
- Built-in Auto programs; Fade / Flash / Sound
- Static colour settings
- Master / Slave operation
- Fitted with a Dual Yoke
Setup
To set up your AVE Hex-Flat 6 follow the below steps;
- Mount the item on your lighting stand or on the floor
- Connect the AC power cord from a grounded mains 240v power
- Power the fixture/s on from the mains socket
- Select the desired operation mode and press enter
Power Linking
The Hex-Flat is fitted with a Mains IEC input and output that allows you to power multiple fixtures from one (1) mains power connection.
To power link your fixtures;
- Ensure the mains power is off and unplugged from the wall
- Connect your IEC extension cable to the output connector from the first fixture and connect to the power input of the second unit ensuring that the connector are firmly in place
- Repeat step 2 for each additional fixture up to 7 fixtures
Mounting
The Hex-Flat 6 is fitted with a Dual yoke that can be separated and used as a floor stand for use on flat & sturdy surfaces.
For hanging the fixture to a lighting stand or trussing, simply attach a lighting clamp to the outer yoke, ensuring that the clamp is tightened to prevent unwanted movement.
Next, attach a safety wire* through the eyelets located on the rear panel of the fixture. Secure the safety cable to the stand or trussing.
*This is a secondary fall arrest; in the event, the yoke or clamp fail, the fixture is safe from causing serious injury or damage
Operation
To access the menus and functions of the Hex-Flat 6, use the four (4) buttons located under the main control screen.
| Button Label | Function |
| Menu | Press to access the main menu, or change function once the fixture is on |
| Up | Cycles upwards through the menu and options |
| Down | Cycles downwards through the menu and options |
| Enter | Press to select a menu option or save a setting |
| Main Level | Program Level | Description |
| Address | 1 — 512 | DMX Address Value |
| Chad | 6Ch | 3 Channel DMX Mode |
| 10Ch | 7 Channel DMX Mode | |
| SLnd | Nast | Master |
| SL1 | Slave Mode 1 | |
| SL2 | Slave Model | |
| 513 | Slave Mode3 | |
| SL4 | Slave Mode4 | |
| Send | sound | Sound Active Mode |
| FAde | Colour Fade with 8-speed settings | |
| CoLo | Colour Presets 1— 24 + Strobe speed | |
| Auto | Auto Mode | |
| LED | On/Off | LED backlight Display |
| Disp | Invert Display | |
| Bala | red | Manual Red Colour 0 – 255 |
| Gree | Manual Green Colour 0 – 255 | |
| bLue | Manual Blue Colour 0 – 255 | |
| The | Manual White Colour 0 – 255 | |
| Bala | red | Manual Red Colour 0 – 255 |
| Gree | Manual Green Colour 0 – 255 | |
| bLue | Manual Blue Colour 0 – 255 | |
| The | Manual White Colour 0 – 255 | |
| Anne | Manual Amber Colour 0 – 255 | |
| uU | Manual UV Colour 0 – 255 | |
| teSt | – | Test all colors + All on |
| FhrS | – | Displays hours of operation |
| rF | On/off | RC control on/off (remote not included) |
| tenP | – | Displays the fixture temperature |
DMX Channels
6 CH Control
| 1 CH | 0 – 255 | Red |
| 2 CH | 0 – 255 | Green |
| 3 CH | 0 – 255 | Blue |
| 4 CH | 0 – 255 | White |
| 5 CH | 0 – 255 | Amber |
| 6 CH | 0 – 255 | UV |
10 CH Control
| 1 CH | 0 – 255 | Red |
| 2 CH | 0 – 255 | Green |
| 3 CH | 0 – 255 | Blue |
| 4 CH | 0 – 255 | White |
| 5 CH | 0 – 255 | Amber |
| 6 CH | 0 – 255 | UV |
| 7 CH | 0 – 255 | Dimmer |
| 8 CH | 0 – 255 150 – 199 200 – 245 246 – 255 | Strobe (slow > fast) Strobe Effect 1 Strobe Effect 2 Strobe (max speed) |
| 9 CH | 0 – 7 8 – 255 | No Function Stepping Colour |
| 10 CH | 0 – 7 8 – 199 200 – 255 | No Function Stepping Colour Speed Sound Active |
Specifications
| Light Source: | 6 x 12W Hex-Colour LED Diodes |
| Diode Colour: | Red, Green, Blue, White, Amber, UV |
| Beam Angle: | 33° |
| DMX Channels: | 6CH / 10CH |
| DMX Connectors: | 3-Pin XLR |
| Enclosure: | ABS Plastic |
| Power Consumption: | 160W |
| Power Supply: | 240V AC / 50Hz |
| Power Connectors: | IEC Mains |
| Dimensions: | 191 x 208 x 75 mm |
| Weight: | 1.0 kg |
