Pittsburgh 56816 Cast Iron Barrel Pump Owner's Manual

AUTOMOTIVE

Owner’s Manual & Safety Instructions

Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance, and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if the product has no number). Keep this manual and the receipt in a safe and dry place for future reference.

Cast Iron barrel Pump

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]

When unpacking, make sure that the product is intact and undamaged. If any parts are missing or broken, please call 1-888-866-5797 as soon as possible.
© Copyright 2011 by Harbor Freight Tools ®
All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, the actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.

WARNING

Read this material before using this product. Failure to do so can result in serious injury save THIS MANUAL.

Specifications

Important Safety Information

1. This product is not a toy. Do not allow children to play with or near this item.
2.  Do not use water or corrosive liquids.
3. Do not pump used, dirty oil, or fluids in this pump.
4. Keep the work area clean. Cluttered areas invite injuries.
5. Keep Barrel Pump and fluids away from all ignition sources and flammable materials.
6. Observe work area conditions.
   Do not use the Pump in damp or wet locations. Don’t expose yourself to rain. Keep work area well lighted.
7. Assemble and use only according to these instructions.
8. Wear ANSI-approved safety goggles during assembly and use.
9. Do not assemble or use when tired or when under the influence of drugs or medication.
10. Use as intended only.
11.  Inspect before every use; do not use if parts are loose or damaged.
12.  Maintain product labels and nameplates. These carry important safety information. If unreadable or missing, contact Harbor Freight Tools for a replacement.

Assembly & Operation Instructions

Assembly

1.  Slide Barrel Bracket onto Suction Pipe with the threaded side down.
2.  Insert Suction Pipe into the barrel.
3. Screw Barrel Bracket into the barrel.
4.  Tighten Butterfly Screw.
5. Screw Pump Body onto the top of Suction Pipe.
6. Slide Handle onto Pump Body shaft.
7.  Tighten bolt.
8. Screw Delivery Spout to Pump Body.

Operation

1. Assemble Barrel Pump as described.
2. Turn Discharge Spout upwards and pour in a few drops of applicable liquid.
3.  Attach Hose to end of Delivery Spout (if needed).
4. Place container under Delivery Spout or hose end.
5. Submerge the lower half of the Suction Pipe into the applicable fluid to transfer.
6.  Rotate Handle clockwise.
7. Remove Pump and wipe dry.

Note: Avoid pumping water or dirty residue through the Barrel Pump. Raise the bottom of the Suction Pipe above the dirty residue.

Maintenance Instructions

Procedures not specifically explained in this manual must be performed only by a qualified technician.

WARN ING

TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Do not use damaged equipment. If abnormal noise or operation occurs, have the problem corrected before further use.

1. Before each use, inspect the condition of the Pump. Check for broken or bent parts, loose or missing parts, and any condition that may affect the proper operation of the product. If a problem occurs, correct it before further use.
2. Periodically, use a light lubricant on Handle’s pivot parts.
3.  Keep suction and delivery ports free of dirt and debris.
4. After each use, wipe off the unit. Store in a clean dry place out of reach of children.

Record Serial Number Here:

Note: If the product has no serial number, record the month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Specify UPC 792363568166 when ordering parts.

26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
