Fixed Work Rest
Product Information:
The Fixed Work Rest Assembly is a component of the Brodbeck
Ironworks LLC equipment. It is designed to provide support and
stability for the workpiece during operation. The assembly consists
of various parts, including a 2 X 72 workrest bracket, work rest
spacer, 1/2 bolt, 1.5 sq tool arm, gray adjustable handle, 3/8 flat
washer, and a 2 X 72 work rest.
Product Usage Instructions:
- Ensure you have received all the necessary parts mentioned in
the product information section. - Begin by attaching the 2 X 72 workrest bracket to the
appropriate location on the equipment using the provided 1/2 bolts.
Tighten the bolts securely. - Place the work rest spacer on top of the workrest bracket and
secure it in place. - Attach the 1.5 sq tool arm to the assembly, ensuring it is
aligned properly with the work rest spacer. - Insert the gray adjustable handle into the designated slot on
the assembly. Tighten it securely using the provided external
thread. - Place the 3/8 flat washer on top of the assembly.
- Finally, attach the 2 X 72 work rest to complete the fixed work
rest assembly.
If you encounter any issues during assembly or find any missing
parts, please contact Brodbeck Ironworks LLC immediately. You can
reach out to Ben Secrist at 513-532-7062 or
[email protected], or Vince Molina at 301-221-9321 or
[email protected] for assistance.
FIXED WORK REST ASSEMBLY
INSTRUCTIONS
BRODBECK IRONWORKS LLC
REVISION B
FIXED WORK REST ASSEMBLY INSTRUCTIONS
ITEM
DESCRIPTION
QTY
1
2 X 72 WORKREST BRACKET
1
2 WORK REST SPACER 2
3
1/2″ BOLT 2.5″LG
2
4
½” SPLIT LOCK WASHER
2
5
1.5″ SQ TOOL ARM 20″ LG
1
GRAY ADJUSTABLE
6
HANDLE 3/8″-16
1
EXTERNAL THREAD
7 3/8″ FLAT WASHER 1
8 2 X 72 WORK REST 1
2 REV. A
FIXED WORK REST ASSEMBLY INSTRUCTIONS
Contact Brodbeck Ironworks LLC for any questions or concerns before operating this equipment IF YOU HAVE ANY ISSUES WITH ASSEMBLY OR MISSING PARTS PLEASE CONTACT US IMMEDIATELY Ben Secrist 513-532-7062, [email protected] Vince Molina 301-221-9321, [email protected] TOOL LIST
– ¾” Combo Wrench Or Socket
3 REV. A
FIXED WORK REST ASSEMBLY INSTRUCTIONS
Fixed Work Rest Assembly
Install work rest spacers and work rest bracket using ½-13 x 2-1/2″ hex bolts and split lock washers on the arm. Attach 3/8″ threaded handle with one flat washer and slide into slot on work rest bracket.
4 REV. A
