1486 4 Way LED Trailer Light Tester
Product Information
The 4-Way Light Tester is a device used for testing the
functionality of the lights on a vehicle’s 4-way flat connector.
This device is manufactured by Winston Products Company and can be
found online at www.towsmart.com.
The device features LED lights that illuminate to confirm that
all functions are working properly. The device must be grounded
properly for it to function correctly.
It is important to read and observe all warnings, instructions,
and capacity limitations before using this product to avoid any
serious personal injury and/or significant property damage.
If you experience any problems with your TOWSMART product, do
not return it to the retailer from which it was purchased. Instead,
call 1-844-295-9216 for assistance with any problems. Warranty
information is available upon request and can be found online at
www.towsmart.com.
Product Usage Instructions
- Locate the 4-Way Flat connector from the vehicle and disconnect
it. - Connect the 4-Way Light Tester to the vehicle’s 4-Way Flat
connector. - Turn on the ignition to engage the lights on the vehicle.
- Check if the LED lights on the tester illuminate. If they do,
it confirms that all functions are working properly. - Ensure that a proper ground connection has been achieved for
the device to function correctly.
1486
4-WAY LIGHT TESTER
INSTALLATION INSTRUCTIONS
WARNING: Read and observe all warnings, instructions, and capacity limitations before using this product. Failure to comply with this warning and the associated instructions and capacity limitations may result in serious personal injury and/or significant property damage.
1. Locate 4-Way Flat connector from the vehicle and disconnect. 2. Connect 4-Way Light Tester. 3. Turn on the ignition to engage lights. 4. LED lights on the tester will illuminate to ensure all functions are working properly. 5. For proper light function a ground connection must be achieved.
a. Green Wire Right turn and brake light b. Yellow Wire Left turn and brake light c. Brown Wire Taillight d. White Wire Ground 6. Remove 4-Way Light Tester. 7. Test lights.
IF YOU EXPERIENCE ANY PROBLEMS WITH YOUR TOWSMART PRODUCT DO NOT RETURN THE UNIT TO THE RETAILER FROM WHICH IT WAS PURCHASED. INSTEAD, PLEASE CALL 1-844-295-9216 FOR ASSISTANCE WITH ANY PROBLEMS. WARRANTY INFORMATION IS AVAILABLE UPON REQUEST AND CAN BE FOUND ONLINE AT WWW.TOWSMART.COM.
©06/2022
Winston Products Company TOWSMART.COM
WINSTON PRODUCTS, LLC. 30339 Diamond Parkway Cleveland, OH 44139
