COMELIT 48FPI000 Red Flush Mount Remote Indicator User Manual
Introduction
MYCOMELIT: THE APP FOR PROFESSIONALS
FREE DOWNLOAD
Scan Me
Red flush mount remote indicator -Art. 48FPI000
Dimensions
48FPI000 is designed to be used as a high visibility optical repeater for sheltered interiors or exteriors, fixed signaling and terminal connection.
Power supply 2Vdc with low consumption 3mA.
Specification
| WIRING | + : +2Vcc/Vdc |
| MOUNTING | Flush mount in a 20 mm diameter hole |
| TECHNICAL SPECIFICATIONS | |
| Power supply | 2Vcc/Vdc +/- 5% |
| Wiring | 2 pin terminals |
| Dimensions | 24 mm x 38,5 mm |
| LED Colour | red |
| Compatible detectors | Addressable and Conventional Camelot detectors |
| [CHECK FOR UPDATES] | CERTIFIED | MANAGEMENT | SYSTEMS |
 |  |  |  |
