GHO 6500 Electric Planer

Product Information

The GHO 6500 is a professional power tool manufactured by Bosch
Power Tools. It is designed for shaping and smoothing wooden
surfaces. The tool comes with various attachments including HSS
blades, TC blades, and a dust bag. The tool has a maximum cutting
depth of 2.6 mm and a maximum cutting width of 82 mm. The tool
weighs 2.8 kg and runs on a 220-240V power supply.

Product Usage Instructions

Before using the GHO 6500, please read all safety warnings,
instructions, illustrations, and specifications provided with the
power tool. Failure to follow all instructions may result in
electric shock, fire, and/or serious injury.

Work Area Safety

Keep the work area clean and well-lit.
Do not operate the power tool in explosive atmospheres.
Keep children and bystanders away while operating the power
tool.

Electrical Safety

Ensure that the power tool plugs match the outlet.
Avoid body contact with earthed or grounded surfaces.
Do not expose the power tool to rain or wet conditions.
Do not abuse the cord.
When operating the power tool outdoors, use an extension cord
suitable for outdoor use.
If operating the power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply.

Personal Safety

Stay alert and use common sense when operating the power
tool.
Use personal protective equipment such as eye protection, dust
mask, non-skid safety shoes, hard hat, or hearing protection.

Usage Instructions

Ensure that the power tool is switched off and unplugged before
attaching or removing any accessories.
Select the appropriate accessory for the task at hand and
securely attach it to the tool.
Adjust the cutting depth and width using the adjustment knobs
on the tool.
Turn on the power tool and wait for it to reach full speed
before using it on the workpiece.
Move the power tool over the workpiece, following the direction
of the grain.
When finished, turn off the power tool and wait for it to come
to a complete stop before unplugging it and removing any
accessories.

View Fullscreen

GHO 6500 Professional
en Original instructions fr Notice originale pt Manual original zh zh th
id Petunjuk-Petunjuk untuk Penggun-
aan Orisinal vi Bn gc hng dn s dng ar fa

| 3

(3) (2) (1)
(9)
GHO 6500
Bosch Power Tools

(4) (5)

(8)

(7) (6)

(33) (2)

1 609 92A 4E6 | (14.09.2018)

4 |

(10)

HSS B

HSS

(8) (11)
(12)

(13) (14) (15) (16)

HSS D 6 mm max.

HSS

23 mm min.
(18)

(17)

(16)

(15)

E (10)

(17) (16)

HSS F

(15)

(11)

HSS

(19)
1 609 92A 4E6 | (14.09.2018)

Bosch Power Tools

(10)

TC H

(8)

(11) (12)

| 5
TC

(13)

(20)

TC K

(21)

J
(11)
Bosch Power Tools

(22) (24)

(23)

(22) (23)

(26)

(24)

(25)

1 609 92A 4E6 | (14.09.2018)

6 |
L
(27) (28)

M
9 mm max
m8a2xmm

(8) (29)

(9) 45°

(30)

(7)

1 609 92A 4E6 | (14.09.2018)

(32)

(6)

(30)

(31)

Bosch Power Tools

| 7

(10)

(17) (16)
(34)

(19)
(34) (20)

Bosch Power Tools

1 609 92A 4E6 | (14.09.2018)

8 | English

English

Safety instructions

General Power Tool Safety Warnings

WARNING

Read all safety warnings, instructions, illustrations and specifica-

tions provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/

or serious injury.

Save all warnings and instructions for future reference.

The term “power tool” in the warnings refers to your mains-

operated (corded) power tool or battery-operated (cordless) power tool.

Work area safety
u Keep work area clean and well lit. Cluttered or dark areas invite accidents.
u Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
u Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety
u Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
u Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
u Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
u Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
u When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
u If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

Personal safety
u Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.
u Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate conditions will reduce personal injuries.
u Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
u Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
u Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
u Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
u If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
u Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.
Power tool use and care
u Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
u Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
u Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
u Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
u Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

1 609 92A 4E6 | (14.09.2018)

Bosch Power Tools

u Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
u Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
u Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
Service
u Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
Safety instructions for planers
u Wait for the cutter to stop before setting the tool down. An exposed rotating cutter may engage the surface leading to possible loss of control and serious injury.
u Hold the power tool by insulated gripping surfaces, because the cutter may contact its own cord. Cutting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock.
u Use clamps or another practical way to secure and support the workpiece to a stable platform. Holding the workpiece by your hand or against the body leaves it unstable and may lead to loss of control.
u Only bring the power tool into contact with the workpiece when switched on. Otherwise there is danger of kickback if the cutting tool jams in the workpiece.
u Do not allow the chip ejector to come into contact with your hands. You may be injured by rotating parts.
u Never plane over metal objects, nails or screws. Cutters and cutter shafts could become damaged and cause increased vibration.
u Use suitable detectors to determine if utility lines are hidden in the work area or call the local utility company for assistance. Contact with electric lines can lead to fire and electric shock. Damaging a gas line can lead to explosion. Penetrating a water line causes property damage or may cause an electric shock.
u While working, always hold the planer in such a way that the planer base plate lies flat against the workpiece. Otherwise the planer could slip and cause injury.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be cut off and an appropriate plug fitted in its place by an authorised customer service agent. The replacement plug should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible shock hazard and should never be inserted into a mains socket elsewhere.
Bosch Power Tools

English | 9
u Hold the power tool firmly with both hands and make sure you have a stable footing. The power tool can be more securely guided with both hands.
Product Description and Specifications
Read all the safety and general instructions. Failure to observe the safety and general instructions may result in electric shock, fire and/or serious injury. Please observe the illustrations at the beginning of this operating manual.
Intended use
The power tool is intended for planing wood-based materials such as beams and boards while resting firmly on the workpiece. It is also suitable for chamfering edges and for rebating.
Product features
The numbering of the product features refers to the diagram of the power tool on the graphics page. (1) Cutting depth scale (2) Knob for setting the cutting depth (insulated gripping
surface) (3) Chip ejector (4) Lock-on button for on/off switch (5) On/off switch (6) Screw for belt cover (7) Belt cover (8) Planer base plate (9) V-grooves (10) Torx key (11) Fastening screw for clamping jaw (12) Clamping jaw (13) Blade head (14) Guide groove for planer blade (15) HSS planer blade (16) HSS planer blade retaining clip (17) Fastening screw for HSS planer blade retaining clip (18) Sharpening aid for HSS planer blades (19) Setting gauge for HSS planer blades (20) HM/TC planer bladeA) (21) Parallel guide (22) Scale for rebate width (23) Locking nut for rebate width setting (24) Fastening screw for parallel/angle guide (25) Angle guideA) (26) Locking nut for angle settingA) (27) Fastening screw for rebate depth guideA)
1 609 92A 4E6 | (14.09.2018)

10 | English

(28) Rebate depth guideA)
(29) Parking rest
(30) Drive belt
(31) Large belt wheel
(32) Small belt wheel
(33) Handle (insulated gripping surface) (34) Adapter for changing from HSS to TC planer bladesA) A) Accessories shown or described are not included with the
product as standard. You can find the complete selection of accessories in our accessories range.

Technical data

Planer

GHO 6500

Article number

0 601 596 0..

Rated power input

650

No-load speed

rpm

16,500

Cutting depth

02.6

Rebate depth

Max. planing width

Weight according to EPTA Pro-

2.8

cedure 01:2014

Protection class

/II

The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.

Fitting
u Pull the plug out of the socket before carrying out any work on the power tool.
Choosing the Planer Blade
The power tool can be fitted with different planer blades. Fitting the adapter (34) (accessory) allows the power tool to be changed from HSS planer blades (15) to HM/TC planer blades (20). Always change both planer blades replacing just one blade will create an imbalance that could cause vibrations and shorten the service life of the power tool.
Changing the HSS Planer Blades
u Take care when changing the planer blade. Do not pick up the planer blade by the cutting edges. You may be injured by the sharp cutting edges.
Removing the Planer Blades (see figures AC) To replace the planer blades, turn the blade head (13)
until the clamping jaw (12) is parallel with the planer base plate (8). Undo the three fastening screws (11) using the Torx key (10) and remove the clamping jaw (12). Push the retaining clip (16) together with the planer blade (15) out of the blade head (13) and/or the guide groove (14).

Turn the blade head 180° and remove the second planer blade.
Note: Before changing or resharpening the planer blades, remove the retaining clip (16) by undoing the fastening screw (17).
Resharpening HSS Planer Blades (see figure D) Worn or blunt HSS planer blades can be resharpened using the sharpening aid (18) (accessory) and a commercially available grinding stone.
Place both planer blades in the sharpening aid and clamp them firmly with the wing bolt. Make sure that both planer blades are pushed in fully.
Move the planer blades placed in the sharpening aid steadily across the grinding stone, applying light pressure.
Note: The planer blades must not be resharpened by more than 6 mm (i.e. to a minimum width of 23 mm). Both planer blades must be replaced when they reach this size.
Fitting the Planer Blades (see figures EF) Before putting the new or resharpened planer blades (back) in, clean the blade head (13) and, if necessary, the planer blade (15) and the retaining clip (16). If the planer blades are very gummy, clean them with ethanol or petroleum.
Note: New and resharpened planer blades must always be set to the correct height before fitting.
The setting gauge (19) is used to set the height of the planer blades. Place the planer blade (15) and the retaining clip (16) on the setting gauge. Make sure that the retaining clip (16) slots into the groove provided. Push the planer blade (15) against the guide and hold the retaining clip (16) in this position with the fastening screw (17). This will apply the correct height setting automatically.
The planer blade must be fitted and aligned with the centre of the planer base plate (8). Then tighten the three fastening screws (11) using the Torx key (10), following the tightening sequence () specified on the clamping jaw (12).
Note: Check that the fastening screws (11) are firmly tightened before start-up. Turn the blade head (13) by hand and ensure that the planer blades are not brushing against anything.
Changing the HM/TC Planer Blades
u Take care when changing the planer blade. Do not pick up the planer blade by the cutting edges. You may be injured by the sharp cutting edges.
Use only original Bosch HM/TC planer blades.
Hard metal (HM/TC) planer blades have two cutting edges and can be turned. If both cutting edges become blunt, the planer blades (20) need to be changed. HM/TC planer blades must not be resharpened.
Removing the Planer Blades (see figures GH) To turn or replace the planer blades, turn the blade head
(13) until the clamping jaw (12) is parallel with the planer base plate (8).

1 609 92A 4E6 | (14.09.2018)

Bosch Power Tools

Undo the three fastening screws (11) using the Torx key (10) (approx. 12 turns). The clamping jaw (12) does not need to be removed.
Turn the blade head slightly and use a piece of wood to push the planer blade (20) to the side and out of the blade head (13).
Turn the blade head 180° and remove the second planer blade.
Fitting the Planer Blades (see figures IJ) The guide groove on the planer blade ensures a constant, even height setting when changing or turning the blade.
If necessary, clean the blade seat in the blade head (13) and the planer blade (20).
When fitting the planer blade, ensure that it is correctly seated in the mounting guide of the blade head (13).
The planer blade must be fitted and aligned with the centre of the planer base plate (8). Then tighten the three fastening screws (11) using the Torx key (10), following the tightening sequence () specified on the clamping jaw (12).
Note: Check that the fastening screws (11) are firmly tightened before start-up. Turn the blade head (13) by hand and ensure that the planer blades are not brushing against anything.
Using the HM/TC Adapter
Changing from HSS to HM/TC The HM/TC adapter enables a planer fitted with HSS planer blades to be changed over to HM/TC planer blades.
Unscrew the three fastening screws (11) using the Torx key (10) and remove the clamping jaw (12).
Push the retaining clip (16) together with the planer blade (15) out of the blade head (13) and/or the guide groove (14).
Remove the screws (17).
Place the retaining clip (16) and the adapter (34) in the setting gauge (19). The retaining clip (16) must slot into the groove on the setting gauge (see figure R).
Push the HM/TC planer blade (20) into the adapter (34) from the side. The ridge on the adapter (34) must slot into the groove on the HM/TC planer blade (see figure R).
Tighten the screws (17).
Insert the retaining clip (16) together with the adapter (34) and the planer blade (15) into the blade head (13) and/or the guide groove (14).
Put the clamping jaw (12) on and insert the fastening screws (11), which do not yet need to be screwed in tightly.
The planer blade must be fitted and aligned with the centre of the planer base plate (8). Then tighten the three fastening screws (11) using the Torx key (10), following the tightening sequence () specified on the clamping jaw (12).

English | 11
Changing from HM/TC to HSS Planers fitted with HM/TC planer blades can be changed over to HSS planer blades. Unscrew the three fastening screws (11) using the Torx
key (10) and remove the clamping jaw (12). Push the retaining clip (16) together with the planer
blade (15) and/or the HM/TC adapter (34) out of the blade head (13). Remove the screws (17). Fit the assembled HSS planer blade (see “Fitting the Planer Blades (see figures EF)”, page 10) and align it with the centre of the planer base plate (8). Put the clamping jaw (12) on and tighten the three fastening screws (11) using the Torx key (10), following the tightening sequence () specified on the clamping jaw (12).
Dust/chip extraction
The dust from materials such as lead paint, some types of wood, minerals and metal can be harmful to human health. Touching or breathing in this dust can trigger allergic reactions and/or cause respiratory illnesses in the user or in people in the near vicinity. Certain dusts, such as oak or beech dust, are classified as carcinogenic, especially in conjunction with wood treatment additives (chromate, wood preservative). Materials containing asbestos may only be machined by specialists. Use a dust extraction system that is suitable for the ma-
terial wherever possible. Provide good ventilation at the workplace. It is advisable to wear a P2 filter class breathing mask. The regulations on the material being machined that apply in the country of use must be observed. u Avoid dust accumulation at the workplace. Dust can
easily ignite. Clean the chip ejector (3) regularly. Clean a clogged chip ejector using a suitable tool, e.g. a piece of wood, compressed air, etc. u Do not allow the chip ejector to come into contact with
your hands. You may be injured by rotating parts. Always use an external dust extraction device or chip/dust bag to guarantee optimum suction.
Operation
Operating modes
Setting the Cutting Depth Using the knob (2), the cutting depth can be continuously adjusted between 02.6 mm with the aid of the cutting depth scale (1) (scale division = 0.1 mm).
Parking Rest (see figure N) The parking rest (29) makes it possible to put down the power tool directly after working, without any danger of damaging the workpiece or the planer blades. During the

Bosch Power Tools

1 609 92A 4E6 | (14.09.2018)

12 | English
work process, the parking rest (29) is raised and the rear section of the planer base plate (8) is uncovered.
Start-up
u Pay attention to the mains voltage. The voltage of the power source must match the voltage specified on the rating plate of the power tool. Power tools marked with 230 V can also be operated with 220 V.
u Products that are only sold in AUS and NZ: Use a residual current device (RCD) with a nominal residual current of 30 mA or less.
Switching on/off u Make sure that you are able to press the On/Off switch
without releasing the handle. To start the power tool, press and hold the on/off switch (5). Press the lock-on button (4) to lock the on/off switch (5) in this position. To switch off the power tool, release the on/off switch (5); or, if the switch is locked with the lock-on button (4), briefly press the on/off switch (5) and then release it.
Practical advice
u Pull the plug out of the socket before carrying out any work on the power tool.
Planing Procedure (see figure N) Set the required cutting depth and position the power tool with the front section of the planer base plate (8) on the workpiece. u Only bring the power tool into contact with the work-
piece when switched on. Otherwise there is danger of kickback if the cutting tool jams in the workpiece. Switch on the power tool and guide it over the surface of the workpiece, applying uniform feed. To achieve high-quality surfaces, apply only a low feed rate and exert pressure on the middle of the planer base plate. For the processing of hard materials, such as hardwood, and also when utilising the maximum planing width, set only a low cutting depth and reduce the planer feed as appropriate. Excessive feed reduces the quality of the surface finish and can lead to the chip ejector quickly becoming blocked. Only sharp planer blades achieve good cutting performance and make the power tool last longer. The integrated parking rest (29) also enables a continuation of the planing procedure following interruption at any point on the workpiece: Place the power tool with parking rest folded down onto the area of the workpiece that you will continue to work on. Switch the power tool on. Shift the contact pressure onto the front of the planer base plate and slowly slide the power tool forward (). In doing so, the parking rest will swivel upwards and out of the way (), meaning that the rear section of the planer base plate is in contact with the workpiece again.

Guide the power tool over the surface of the workpiece, applying uniform feed ().

Chamfering Edges (see figure O)
The V-grooves in the front of the planer base plate enable quick and easy chamfering of workpiece edges. Select the Vgroove that corresponds to your chamfering width. Then position the planer with the V-groove onto the edge of the workpiece and guide it along.

Groove used None

Dimension a (mm)
04

Small

Medium

Large

610

Planing with the Parallel/Angle Guide (see figures KM)
Attach the parallel guide (21) or the angle guide (25) to the power tool with the fastening screw (24). Depending on the application, attach the rebate depth guide (28) to the power tool with the fastening screw (27).
Loosen the locking nut (23) and set the desired rebate width on the scale (22). Retighten the locking nut (23).
Set the desired rebate depth accordingly using the rebate depth guide (28).
Carry out the planing procedure several times until the desired rebate depth has been achieved. Guide the planer with sideways contact pressure.

Chamfering with angle guide
Use the angle setting (26) to set the necessary helix angle when chamfering grooves and surfaces.

and Servicing

Maintenance

Maintenance and cleaning
u Pull the plug out of the socket before carrying out any work on the power tool.
u To ensure safe and efficient operation, always keep the power tool and the ventilation slots clean.
Keep the parking rest (29) clear and clean it regularly.
When the carbon brushes are worn out, the power tool switches itself off. The power tool must be sent to the aftersales service for maintenance; see the “After-sales service and advice on using products” section for addresses.
In order to avoid safety hazards, if the power supply cord needs to be replaced, this must be done by Bosch or by a customer service centre that is authorised to repair Bosch power tools.

1 609 92A 4E6 | (14.09.2018)

Bosch Power Tools

Changing the Drive Belt (see figures PQ)
Unscrew the screw (6) completely and take off the belt cover (7). Remove the worn drive belt (30).
Before fitting a new drive belt (30), clean the two belt wheels ((31) and (32)).
First place the new drive belt (30) onto the small drive wheel (32), and then press the drive belt (30) onto the large drive belt (31), turning it by hand.
Make sure that the drive belt (30) runs exactly in the lengthways grooves in the drive wheels ((31) and (32)).
Put the belt cover (7) on and tighten the screw (6).
After-sales Service and Advice on Using Products
Our after-sales service can answer questions concerning product maintenance and repair, as well as spare parts. You can find exploded drawings and information on spare parts at: www.bosch-pt.com The Bosch product use advice team will be happy to help you with any questions about our products and their accessories. www.powertool-portal.de, the internet portal for tradespeople and DIY enthusiasts.
In all correspondence and spare parts orders, please always include the 10digit article number given on the type plate of the product.
Cambodia
Robert Bosch (Cambodia) Co., Ltd Unit 8BC, GT Tower, 08th Floor, Street 169, Czechoslovakia Blvd, Sangkat Veal Vong Khan 7 Makara, Phnom Penh VAT TIN: 100 169 511 Tel.: +855 23 900 685 Tel.: +855 23 900 660 www.bosch.com.kh
People’s Republic of China China Mainland Bosch Power Tool (China) Co. Ltd. Bosch Service Center 567, Bin Kang Road Bin Kang District Hangzhou, Zhejiang Province China 310052 Tel.: (0571) 8887 5566 / 5588 Fax: (0571) 8887 6688 x 5566# / 5588# E-mail: [email protected] www.bosch-pt.com.cn
HK and Macau Special Administrative Regions
Robert Bosch Co. Ltd. 21st Floor, 625 King’s Road North Point, Hong Kong Customer Service Hotline: +852 2101 0235 Fax: +852 2590 9762 E-mail: [email protected] www.bosch-pt.com.hk
India

English | 13
Bosch Service Center 69, Habibullah Road, (next to PSBB School), T. Nagar Chennai600077 Phone: (044) 64561816
Bosch Service Center Rishyamook 85A, Panchkuin Road New Delhi110001 Phone: (011) 43166190
Bosch Service Center 79, Crystal Bldg., Dr. Annie Besant Road, Worli Mumbai400018 Phone: (022) 39569936 / (022 )39569959 / (022) 39569967 / (022) 24952071
Indonesia
PT Robert Bosch Palma Tower 10th Floor Jalan RA Kartini II-S Kaveling 6 Pondok Pinang, Kebayoran Lama Jakarta Selatan 12310 Tel.: (21) 3005-5800 www.bosch-pt.co.id
Malaysia
Robert Bosch Sdn. Bhd.(220975-V) PT/SMY No. 8A, Jalan 13/6 46200 Petaling Jaya Selangor Tel.: (03) 79663194 Toll-Free: 1800 880188 Fax: (03) 79583838 E-mail: [email protected] www.bosch-pt.com.my
Pakistan
Robert Bosch Middle East FZE Pakistan Liaison Office 2nd Floor Plaza # 10, CCA Block, DHA Phase 5 Lahore, 54810 Phone: +92(303)4444311 E-mail: [email protected]
Philippines
Robert Bosch, Inc. 28th Floor Fort Legend Towers, 3rd Avenue corner 31st Street, Fort Bonifacio, Global City, 1634 Taguig City Tel.: (632) 8703871 Fax: (632) 8703870 www.bosch-pt.com.ph
Singapore
Powerwell Service Centre Ptd Ltd Bosch Authorised Service Centre (Power Tools) 4012 Ang Mo Kio Ave 10, #01-02 TECHplace Singapore 569628 Tel.: 6452 1770 Fax: 6452 1760 E-mail: [email protected] www.powerwellsc.com www.bosch-pt.com.sg
Thailand

Bosch Power Tools

1 609 92A 4E6 | (14.09.2018)

14 | English
Robert Bosch Ltd. Liberty Square Building No. 287, 11 Floor Silom Road, Bangrak Bangkok 10500 Tel.: 02 6393111 Fax: 02 2384783 Robert Bosch Ltd., P. O. Box 2054 Bangkok 10501 www.bosch.co.th
Bosch Service Training Centre La Salle Tower Ground Floor Unit No.2 10/11 La Salle Moo 16 Srinakharin Road Bangkaew, Bang Plee Samutprakarn 10540 Tel.: 02 7587555 Fax: 02 7587525
Vietnam Branch of Bosch Vietnam Co., Ltd in HCMC 14th floor, Deutsches Haus, 33 Le Duan Ben Nghe Ward, District 1, Ho Chi Minh City Tel.: (028) 6258 3690 Fax: (028) 6258 3692 – 6258 3694 Hotline: (028) 6250 8555 E-mail: [email protected] www.bosch-pt.com.vn
Armenia, Azerbaijan, Georgia, Kyrgyzstan, Mongolia, Tajikistan, Turkmenistan, Uzbekistan
TOO “Robert Bosch” Power Tools, After Sales Service Rayimbek Ave., 169/1 050050, Almaty, Kazakhstan Service e-mail: [email protected] Official website: www.bosch.com, www.bosch-pt.com
Bahrain
Hatem Al Juffali Technical Equipment Establishment. Kingdom of Bahrain, Setra Highway, Al Aker Area Phone: +966126971777-311 Fax: +97317704257 E-mail: [email protected]
Egypt
Unimar 20 Markaz kadmat El tagmoa EL Aoul New Cairo Phone: +20 2224 76091-95 Phone: +20 2224 78072-73 Fax: +20222478075 E-mail: [email protected]
Iran
Robert Bosch Iran 3rd Floor, No 3, Maadiran Building Aftab St., Khodami St., Vanak Sq. Tehran 1994834571 Phone: +9821 86092057
Iraq
Sahba Technology Group Al Muthana airport road
1 609 92A 4E6 | (14.09.2018)

Baghdad Phone: +9647901906953 Phone Dubai: +97143973851 E-mail: [email protected] Jordan Roots Arabia Jordan Nasser Bin Jameel street, Building 37 Al Rabiah 11194 Amman Phone: +962 6 5545778 E-mail: [email protected] Kuwait Al Qurain Automotive Trading Company Shuwaikh Industrial Area, Block 1, Plot 16, Street 3rd P.O. Box 164 Safat 13002 Phone: 24810844 Fax: 24810879 E-mail: [email protected] Lebanon Tehini Hana & Co. S.A.R.L. P.O. Box 90-449 Jdeideh Dora-Beirut Phone: +9611255211 E-mail: [email protected] Libya El Naser for Workshop Tools Swanee Road, Alfalah Area Tripoli Phone: +218 21 4811184 Oman Malatan Trading & Contracting LLC P.O. Box 131 Ruwi, 112 Sultanate of Oman Phone: +968 99886794 E-mail: [email protected] Qatar International Construction Solutions W L L P. O. Box 51, Doha Phone: +974 40065458 Fax: +974 4453 8585 E-mail: [email protected] Saudi Arabia Juffali Technical Equipment Co. (JTECO) Kilo 14, Madinah Road, Al Bawadi District Jeddah 21431 Phone: +966 2 6672222 Ext. 1528 Fax: +966 2 6676308 E-mail: [email protected] Syria Dallal Establishment for Power Tools P.O. Box 1030 Aleppo Phone: +963212116083 E-mail: [email protected] United Arab Emirates
Bosch Power Tools

Central Motors & Equipment LLC, P.O. Box 1984 Al-Wahda Street Old Sana Building Sharjah Phone: +971 6 593 2777 Fax: +971 6 533 2269 E-mail: [email protected]
Yemen
Abualrejal Trading Corporation Sana’a Zubiery St. Front to new Parliament Building Phone: +967-1-202010 Fax: +967-1-279029 E-mail: [email protected]
Ethiopia
Forever plc Kebele 2,754, BP 4806, Addis Ababa Phone: +251 111 560 600 E-mail: [email protected]
Ghana
C.WOERMANN LTD. Nsawam Road/Avenor Junction, P.O. Box 1779 Accra Phone: +233 302 225 141
Kenya
Robert Bosch East Africa Ltd Mpaka Road P.O. Box 856 00606 Nairobi
Nigeria
Robert Bosch Nigeria Ltd. 5254 Isaac John Street P.O. Box GRA Ikeja Lagos
Republic of South Africa
Customer service Hotline: (011) 6519600
Gauteng BSC Service Centre 35 Roper Street, New Centre Johannesburg Tel.: (011) 4939375 Fax: (011) 4930126 E-mail: [email protected]
KZN BSC Service Centre Unit E, Almar Centre 143 Crompton Street Pinetown Tel.: (031) 7012120 Fax: (031) 7012446 E-mail: [email protected]
Western Cape BSC Service Centre Democracy Way, Prosperity Park Milnerton Tel.: (021) 5512577 Fax: (021) 5513223 E-mail: [email protected]
Bosch Headquarters Midrand, Gauteng Tel.: (011) 6519600 Fax: (011) 6519880 E-mail: [email protected]
Bosch Power Tools

Français | 15
Tanzania Diesel & Autoelectric Service Ltd. 117 Nyerere Rd., P.O. Box 70839 Vingunguti 12109, Dar Es Salaam Phone: +255 222 861 793/794 Australia, New Zealand and Pacific Islands Robert Bosch Australia Pty. Ltd. Power Tools Locked Bag 66 Clayton South VIC 3169 Customer Contact Center Inside Australia: Phone: (01300) 307044 Fax: (01300) 307045 Inside New Zealand: Phone: (0800) 543353 Fax: (0800) 428570 Outside AU and NZ: Phone: +61 3 95415555 www.bosch-pt.com.au www.bosch-pt.co.nz
Disposal
The power tool, accessories and packaging should be recycled in an environmentally friendly manner.
Do not dispose of power tools along with household waste.

Français

Consignes de sécurité

Avertissements de sécurité généraux pour l’outil électrique

AVERTISSE- Lire tous les avertissements de sé-

MENT

curité, les instructions, les illustrations et les spécifications fournis

avec cet outil électrique. Ne pas suivre les instructions

énumérées ci-dessous peut provoquer un choc électrique,

un incendie et/ou une blessure sérieuse.

Conserver tous les avertissements et toutes les instructions pour pouvoir s’y reporter ultérieurement.

Le terme “outil électrique” dans les avertissements fait référence à votre outil électrique alimenté par le secteur (avec cordon d’alimentation) ou votre outil électrique fonctionnant sur batterie (sans cordon d’alimentation).

1 609 92A 4E6 | (14.09.2018)

Robert Bosch Power Tools GmbH 70538 Stuttgart GERMANY www.bosch-pt.com 1 609 92A 4E6 (2018.09) O / 70
1 609 92A 4E6

GH
en Or fr No pt M zh zh th
id Pe
aa vi B ar fa
