Troy Lighting Morgan P1275 Hill Outdoor Post Light Installation Guide

Morgan P1275 Hill Outdoor Post Light

Product Information

The P1274 and P1275 are lighting fixtures that require
installation by an electrician or certified factory trained
technician. The fixture is designed to be mounted on a standard
round or octagon box or a through wiring box with a plaster frame,
and must be installed in compliance with all applicable national
and local electrical/building codes. The fixture is rated for 60
watt type B, BA, C or CA lamps.

Product Usage Instructions

  1. Disconnect power before relamping or wiring the fixture.
  2. If an existing fixture is being replaced, remove it and note to
    which of the wires in the outlet box the fixture was attached. Do
    not separate any other wires that may be in the box. Do not damage
    the insulation of older wiring.
  3. Fasten the bare copper fixture wire to the green or bare copper
    wire in the post. Never fasten the ground wire to the black or hot
    wire!
  4. Fasten the white fixture wire to the white wire in the post.
    Fasten the wires together with an approved fastener (wire nut).
    Starting about 1 below the fastener, tightly wrap connection with
    electrical tape so that the tape seals the end of the fastener.
    Make sure that there is no exposed wire or strands that could cause
    a dangerous short circuit!
  5. Connect the black fixture lead to the black wire in the outlet
    box. Fasten the joined wires as in step 2.
  6. Place the fixture on the post and fasten it in place with the 3
    set screws and mounting screws provided.
  7. Unscrew the loop and remove the sealing washer, ornament, and
    roof.
  8. Install the glass panels and bend the tabs over the panels to
    hold them in place.
  9. Install the lamps (light bulbs). Do not exceed recommended
    wattage!

For your safety, be certain that all circuit breakers
controlling outdoor lighting and equipment are GFI breakers.
Caution and care must be supplied by the person(s) installing,
operating, and caring for this lighting fixture. The important
safeguards and instructions outlined in the manual cannot cover all
possible conditions and situations that may occur. It must be
understood that common sense, caution, and care are factors that
cannot be built into any product.

P1274 ,P1275 INSTALLATION INSTRUCTIONS

WARNING
DISCONNECT POWER BEFORE RELAMPING OR WIRING THE FIXTURE. READ ALL INSTRUCTIONS COMPLETELY BEFORE STARTING INSTALLATION.

CAUTION

TO AVOID THE RISK OF FIRE OR SHOCK, FIXTURE MUST BE INSTALLED IN COMPLIANCE WITH

ALL APPLICABLE NATIONAL AND LOCAL ELECTRICAL/BUILDING CODES.

INSTALLATION AND MAINTENANCE OF THIS UNIT REQUIRES AN ELECTRICIAN OR

CERTIFIED FACTORY TRAINED TECHNICIAN.

If an existing fixture is being replaced, remove it and note to which of the wires in the outlet box the fixture was attached.
DO NOT SEPARATE ANY OTHER WIRES THAT MAY BE IN THE BOX. DO NOT DAMAGE THE INSULATION OF OLDER WIRING. In regular circumstances the BLACK wire will be the “Hot” lead and the WHITE wire will be the “Neutral” or “Common” lead. A GREEN or BARE COPPER wire is the “Ground”. In older buildings it is always good practice to reconfirm the polarity of the wiring.

NOTICE
z The important safeguards and instructions outlined on this sheet cannot cover all possible conditions and situations that may occur. It must be understood that common sense, caution and care are factors that cannot be built into any product. Caution and care must be supplied by the person(s) installing, operating and caring for this lighting fixture.
z This fixture is designed to be mounted on a correctly installed standard round or octagon box or a through wiring box with a plaster frame. The box must be securely mounted to the structure of the building. The crossbar and hardware supplied should be used. Directly mounting the fixture to the outlet box may make it impossible to correctly align the fixture.
z For your safety be certain that all circuit breakers controlling outdoor lighting and equipment are GFI breakers.
FIXTURE PREPARATION 1. Remove the fixture, parts and parts bag(s) from the carton.
NOTICE:
Before discarding the carton, double check to make certain that all parts are found.
FIXTURE INSTALLATION 1. Fasten the bare copper fixture wire to the green or bare copper wire in the post
WARNING
Never fasten the ground wire to the black or “hot” wire! Failure to follow this instruction could result in serious injury or death
2. Fasten the white fixture wire to the white wire in the post. Fasten the wires to together with an approved fastener (wire nut). Starting about 1″ below the fastener, tightly wrap connection with electrical tape so that the tape seals the end of the fastener.
WARNING
Make sure that there is no exposed wire or strands that could cause a dangerous short circuit !
electrical tape
approved fastener (wire nut)
3. Connect the black fixture lead to the black wire in the outlet box. Fasten the joined wires as in step 2.

4. Place the fixture on the post and fasten it in place with the 3 set screws. 5. Place the fixture on the post and fasten it in place with the mounting screws provided. 6 . Unscrew the loop and remove the sealing washer, ornament and roof 7. Install the glass panels.Bend the tabs over the panels to hold them in place. 8. Install the lamps (light bulbs) NOTE:
This fixture is rated for 60 watt type B, BA, C or CA lamps.
WARNING
DO NOT EXCEED RECOMMENDED WATTAGE!
9. Reinstall the roof, ornament, sealing washer and loop. 10. Restore power to circuit at breaker or fuse box

3
