Lubemate L-awp1015 Air Water Retractable Hose Reel Instruction Manual

L-AWP1015 Air Water Retractable Hose Reel

Product Information

The Lubemate L-AWP1015 is an air/water retractable hose reel
designed for easy and convenient hose storage. The reel is made
from high-quality impact resistant polypropylene, which makes it
durable, lightweight, and compact. It comes with a delivery hose,
feeder hose, and mounting bracket.

The hose reel features a UV stabilised construction, ensuring
its longevity even when exposed to sunlight. It has a positive
latch and a built-in hose layering mechanism that prevents hose
bunching. The powerful spring in the reel helps to wind the hose
back into the drum effortlessly.

Features and Benefits:

1. UV stabilised reel
2. Easy-to-use positive latch
3. Built-in hose layering mechanism
4. Durable construction
5. Compact and lightweight
6. Powerful spring for easy retraction

Caution and General Safety:

• Do not let go of the hose during rewinding to prevent injury or
  damage.
• Hold the hose stop ball when retracting the hose.
• Do not disassemble the hose reel.
• Avoid contact with sharp objects or high temperatures.
• Avoid dropping the reel to prevent damage.
• Use only with water and do not use with chemicals or other
  liquids.
• Turn off the air/water supply after use or at the end of the
  day.

Product Usage Instructions

Installation:

1. Take out the unit and accessories from the box.
2. Choose a suitable place near the source of air/water.
3. Use the mounting bracket as a template to mark the position for
   screws and drill four holes on the wall.
4. Securely fix the bracket to the wall using four self-tapping
   screws.
5. Connect the reel to the mounting bracket, ensuring it is
   installed horizontally and approximately 1 meter above the
   ground.

Operation:

1. Connect the feeder hose to the supply.
2. Pull out the hose to the desired length and stop.

Retract Hose:

1. Always hold the hose when retracting it back into the
   reel.
2. Turn off the air/water supply.

Storage:

When not in use, turn off the supply and release the line
pressure. Store the hose reel in a cool, dry place.

Cleaning:

The hose reel is maintenance-free and should not be cleaned
internally with water.

l-awp1015_inst_issue1
INSTRUCTION MANUAL
AIR / WATER RETRACTABLE HOSE REEL
Model L-AWP1015
1

INSTRUCTION MANUAL
AIR / WATER RETRACTABLE HOSE REEL
DESCRIPTION Thank you for purchasing a Lubemate hose reel. Each reel is a quality UV Stabilised reel, supplied complete with a delivery hose, feeder hose and mounting bracket.
FEATURES AND BENIFITS 1. The hose reel is UV stabilised. 2. The reel is easy to use positive latch and a built in hose layering mechanism to prevent hose bunching. 3. Durable construction, made from high quality impact resistant polypropylene, light in weight and more
compact. 4. A powerful spring winds the hose back into the drum.
CAUTION
GENERAL SAFETY Please read these operating instructions carefully and note the information given. Use these operating instructions to familiarize yourself with the product, the proper use and the safety instructions.

* To prevent injury or damage do not let go of the hose during rewinding. * Hold the hose stop ball when retracting hose. * Do not disassemble hose reel. * Ensure the reel or hose is not in contact with any sharp objects or exposed to high temperatures. * Do not drop this reel or damage will occur. * Do Not use this product with any chemicals or liquid other than water. * Turn off air/water supply after use or at the end of the day.
Installation:
1. Take out the unit and accessories from the box 2. Choose a suitable place near source of air/water. 3 . Take the mounting bracket as a template to mark the position for screws and drill four holes on the
wall( Fig.2)

1 Hose reel

1

2 Mounting bracket 1

3 Self-tapping bolts 4

4. Fix the bracket by four self-taping screws accordingly, (Fig.1)

Fig.1 lubemate by macnaught / instruction manual

Fig.2
2

INSTRUCTION MANUAL

AIR / WATER RETRACTABLE HOSE REEL
5.Connect the reel to the mounting bracket.
Note:
1. The reel should be installed horizontally to a wall or post.
2. It is recommended to mount the reel approximately 1 meter above the ground.
Fig.3
Operation
1.Connect feeder hose and turn on supply 2. Pull out hose to desired length and stop.
Retract hose
1. Always hold hose when rectracting back into reel 2. Turn off the air/water supply.
Storage
Cleaning
This Reel is maintenance-free and must not be cleaned internally with water.
Maintenance When not in use, turn off supply, and release the line pressure The reel must not be used to transmit any chemical and substance When not in use for an extended period of time it is recommended to be stored in a cool dry place.

Item Description 29 Synchronous belt 28 Right Cover 27 Lead hose 26 Small Spring 25 Inlet 24 Right Casing 23 Tooth Wheel 22 Slow return mechanism 21 O-Ring 20 Outlet 19 Lock System 18 Fix Piece 17 Sleeve 16 Inner Hexagon Screw 15 Drum 14 Mounting Bracket 13 Spring 12 Mounting Pin 11 Lock Plate 10 Hose guide system 9 Hose Stop 8 Pre-loading Cap 7 Output Hose 6 Handle 5 Pre-loading Wheel 4 Guide Pole 3 Lock Piece 2 Left Casing 1 Left Cover

Material PU PP Hybrid Spring Steel Brass PP PA PA6+GF30 NBR Aluminium PA PP ABS Q235 PP+GF30 PP+GF30 Spring Steel PA66+GF30 PP+GF30 PA+POM PP PA6+GF30 Hybrid PP PA66+GF30 Stainless Steel POM PP PP

no off 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

EXPLODED DIAGRAM
Note: no spare parts available macnaught.com
3

INSTRUCTION MANUAL
AIR / WATER RETRACTABLE HOSE REEL

TROUBLESHOOTING

FAULT The hose does not retract

DESCRIPTION Hose has been pulled out too far and locked
Not enough spring tension

SOLUTION Access the drum through the window and carefully rotate the drum half a turn in the direction of the hose being pulled out to release latch. Add 1-2 turns extra turns: 1. Remove the small cover, 2. Use spanner to clamp the groove of preload wheel, 3. Unscrew four bolts on the wheel, then rotate it for 1-2 turns in counterclockwise, then fasten the bolts, and replace the cover.Fig.4

Fig.4

SPECIFICATIONS – L-AWP1015

Maximum Pressure Maximum Temperature Hose type Hose Size and Length Inlet / Outlet Dimensions Weight

300psi/20bar + 55 deg C Hybrid Polymer 3/8″ (10mm) x 15m (50ft) 1/4″ BSPT (M) 42.5 x 20.4 x 39.5cm 5.5kg

lubemate by macnaught / instruction manual

For warranty terms and condi ons refer to www.macnaught.com.au
4
