E Thirteen 02072023 Wheel Valve User Manual

02072023 Wheel Valve

Product Information:

The product is a gravel bike wheelset manufactured by
e*thirteen. It is available in various models and configurations,
including Optimus, Sylvan, Grappler EN, and Grappler DH. The
wheelset is designed for use in different terrains such as down
country, trail, and all mountain riding.

The product is compatible with two different driver options:
XD/XDRTM and HGTM. It comes with a XDRTM Spacer and a Hub Seal that
need to be installed correctly for optimal performance. The Shim +
Freehub Spacer assembly is required for all hubs found on Optimus,
Sylvan, Grappler, and e*spec wheels.

The product also includes an e*thirteen GEN 2 Valve, which
allows for easy addition of sealant through the valve or directly
into the tire.

Product Usage Instructions:

1. To install the Hub Seal, make sure to orient it correctly and
   press all four quarter points to ensure a tight and even fit.
2. For Shim + Freehub Spacer installation, follow the provided
   instructions. Apply grease after maintenance.
3. To remove the wheels, rotate them counter-clockwise.
4. For more detailed information on the specific driver
   configurations and hub sizes, visit support.ethirteen.com.
5. To add sealant to the tires, use the e*thirteen GEN 2 Valve.
   You can either add the sealant through the valve or directly into
   the tire.
6. For additional guidance and support, visit
   support.ethirteen.com.

GRAVEL

PIEDMONT

OPTIMUS, SYLVAN, GRAPPLER EN
DOWN COUNTRY, TRAIL, ALL MOUNTAIN, EN

*INSTRUCTIONS APPLY TO ALL DRIVER CONFIGURATIONS
GRAPPLER DH
DH

e*spec

e*spec

RevA 02072023

DRIVER OPTION: XD/XDRTM (shown) or HGTM
XDRTM Spacer

HUB SEAL
*INSTALL BEFORE ASSEMBLY *NOTICE THE ORIENTATION AND PRESS FOUR QUARTER POINT TO MAKE SURE SEAL SITS TIGHT AND EVENLY

SHIM + FREEHUB SPACER INSTALLATION
ALL HUBS FOUND ON OPTIMUS, SYLVAN, GRAPPLER AND E*SPEC WHEELS REQUIRED SHIM/FREEHUB SPACER ASSEMBLY AS SHOWN HERE

*APPLY GREASE AFTER MAINTANENCE

*FOR REMOVAL, ROTATE COUNTER-CLOCKWISE

(ALL WHEELS)

15MM

12MM

(ALL WHEELS) FOR MORE INFORMATION, VISIT SUPPORT.ETHIRTEEN.COM

e*thirteen GEN 2 VALVE
*ADD SEALANT THROUGH VALVE OR DIRECTLY INTO TIRE
FOR MORE INFORMATION, VISIT SUPPORT.ETHIRTEEN.COM
