Bertazzoni Hk36herfdbxv 36 Inch Built In French Door Refrigerator Instruction Manual

HK36HERFDBXV 36 Inch Built In French Door Refrigerator

Product Information

The product is a kitchen appliance with the model number
3070992-revA. It is designed to be installed on custom cabinets and
comes with four pieces of handle A, four pieces of handle B, and
one piece of handle C. The product is compatible with Bertazzoni
handles.

Product Usage Instructions

To install the product on custom cabinets with Bertazzoni
handles, follow these steps:

  1. Identify the custom cabinet panel where you want to mount the
    appliance.
  2. Ensure that the custom panel is suitable for mounting the
    product.
  3. Obtain brass tapping inserts specifically designed for securing
    the handle on the custom panel.
  4. Locate the appropriate positions on the custom panel where the
    handles will be attached.
  5. Using a suitable tool, install the brass tapping inserts in
    these positions.
  6. Attach handle A to the designated locations on the custom panel
    by aligning the holes in the handle with the brass tapping
    inserts.
  7. Repeat step 6 for the remaining three handle A pieces.
  8. Attach handle B and handle C to their respective designated
    locations on the custom panel using the same method described in
    step 6.
  9. Ensure that all handles are securely fastened to the custom
    panel.

Following these instructions will allow you to properly install
and secure the Bertazzoni handles on your custom cabinet panel for
optimal usage of the product.

A

A x4 B x4 C x1

B C

HANDLE INSTALLATION ON CUSTOM CABINETS In case a custom cabinet panel is to be mounted on any of the models listed below with Bertazzoni handles,it will be necessary to install brass tapping inserts in order to secure the handle properly on the custom panel.

SUGGESTED HANDLE INSERT FOR PANELS – M5 x 0.8 MM BRASS TAPPING INSERTS Recommended drill bit size to drill the pilot hole is 3/8″ Suitable inserts can be ordered at www.encompassparts.com Part Number: 95631A100, contains n°4 M5 brass hardwood inserts and 1 M5 installation bit Do not use a power tool to mount the inserts. Installation of the inserts with improperly calibrated power tools risk damaging the panels.

3070992-revA
