Hilti Te-yx/sx Fs Floor Scraper Instruction Manual

Product Information:

• Product Model: TE-YX/SX FS
• Item No: 2364631-08.2022
• Description: Floor scraper TE-YX/SX FS
• Content:
  • 2312355 – Floor scraper TE-YX FS
  • 2312356 – Floor scraper TE-SX FS
  • 2312441 – FS blade TE-YX/SX FS BLAD
  • 2312455 – FS hold down plates TE-YX/SX FS HDPL
  • 2312456 – FS replacement kit TE-YX/SX FS KIT

Product Usage Instructions:

1. Attach the appropriate floor scraper to the TE-YX/SX FS
   tool.
2. Apply brake oil cleaner to the tool as needed for
   maintenance.
3. For FS blade replacement, use the FS replacement kit
   (2312456).
   1. Remove the old FS blade by unscrewing it from the tool.
   2. Attach the new FS blade from the FS replacement kit by screwing
      it onto the tool.
4. For FS hold down plates replacement, use the FS replacement kit
   (2312456).
   1. Remove the old FS hold down plates by unscrewing them from the
      tool.
   2. Attach the new FS hold down plates from the FS replacement kit
      by screwing them onto the tool.
5. Tighten the screws of the floor scraper and FS blade/hold down
   plates using a torque wrench.

• For the floor scraper screws, tighten to 80 Nm.
• For the FS blade/hold down plates screws, tighten to 115
  Nm.
