R6 Corner Rounder Cutter
Product Information: Manual Fillet Machine
Manual fillet machine is a lightweight and easy-to-operate
device that is widely used for fillet-cutting of business cards,
books, packages, decorations, documents, certificates, bags, and
notebook’s PVC cards, etc. It is applicable to paper, cardboard,
film, PVC certificates, leather, etc. It has a cutting height of
30mm and fillet radius of R3, R4, R6, R8, R10 (R6,
R10-Random,Others-Please purchasing separately); Dimension: 250 X
150 X 168MM (L*W*H) Net Weight: 4 KG. The product is manufactured
by FS CHUANG TUO MECH EQUIP CO.LTP. in GuangDong China.
Product Usage Instructions:
1. Cut the fillet radius as required using a knife with the same
radius as the machine.
2. Ensure that the machine is adjusted and tested before
use.
3. Do not remove the adjustment unless necessary or adjusting
the distance between upper and lower blades after replacing the
blades.
4. Do not place your hand between the upper and lower blades
when operating the handle.
5. If you face troubles such as unsmooth fillet cut but
connected deckle edge left or cut but irregular, follow the below
troubleshooting steps:
Troubleshooting:
- Cause: Blunt blade
- Elimination Method: Grind or replace the blade
- Cause: Too large gaps between upper and lower
blades - Elimination Method: Adjust it until fitted
- Cause: Wrong Position of Cut Material Displacement
- Elimination Method: Adjust the positioning block until
the cut material is tangent to the 90-degree straight edge, then
tighten the positioning block. Hold the material to prevent it from
displacement.
Instructions ManualFillet Machine
FS CHUANG TUO MECH EQUIP CO.LTP.
GuangDong China
Made In China
Instructions—-Maual Fillet Machine
A. Applications Manual fillet machine is widely used for fillet-cutting of business cards, books,
package and decoration, documents, certificates, bags,and notebook’s PVC cards, etc, which applys to paper, cardboard, film, PVC certificates, leather, etc. Light weight and strength-saving, easy operation and low cost, it is popular with no
needs of maintenance.
B. Specifications Cutting Height: 30MM; Fillet Radius: R3, R4, R6, R8, R10 (R6, R10-Random,Others-Please purchasing
seperately); Dimension: 250 X 150 X 168MM (L*W*H) Net Weight: 4 KG.
C. How to Use Cut the fillet radius as required, ensure to use knife with the same redius as the
upper and lower molding blades, tighten the pressure screw since the touch of concave and convex part of the upper and lower molding blades, test with a piece of paper then on products. Knife Replacement . Remove paper pressing device; . Press to the limit of handle, plug lock pin to lock pin hole and fasten the tool carrier; . Replace the upper blade and lower blade with needed blade; . Fasten the upper blade first, touch tightly with the lower blade, then lock the lower blade; . Press the handle and remove the lock pin; . Finished.
VEVOR
D. Maintenance and Safe Adjusted and tested before shipping, it SHOULD NOT be removed unless you
have special requirement or need to adjust the distance between upper and lower
blades after replacing the blades. Dive your hand between upper and lower blades when operate the handle is FORBIDDEN!
Trouble Unsmooth fillet
Cut but connected Deckle edge left
Cut but Irregular
Trouble shooting
Cause Blunt blade Too large gaps between upper and lower blades Wrong Position of Cut
Material
Displacement
Elimination methods Grind or replace the blade
Adjust it untill fited
Adjust the positioning block until the cut material is tangent to the 90-degree straight
edge, then tighten the positioning block Hold the material to prevent it
