Forever Waterslide Ht Instructions

WATERSLIDE HT
FOR CANDLES, CERAMIC, GLASS & MORE

Waterslide HT

PRINT SETTINGS FOR OKI WHITE TONER PRINTERS

• Paper Setting for A-Paper: Ultra Heavy 2
• Paper Feeding: Multi-Purpose Tray
• Image Mode: mirrored

PRINT SETTINGS FOR OKI WHITE TONER PRINTERS WITH TRANSFERRIP AND COLOR MAPPING

• Paper Setting: Labels 1
• Paper Feeding: Multi-Purpose Tray
• Image Mode: not mirrored

PRINT SETTINGS FOR CMYK PRINTERS

• Paper Setting: Labels 1 or similar
• Paper Feeding: Multi-Purpose Tray
• Image Mode: not mirrored

SETTINGS HEAT PRESS

TRANSFER PROCESS FOR OKI WHITE TONER PRINTERS

• Pre-Heat your press until the lower plate is hot.
• Print the picture in mirror image onto the Laser-Dark (No-Cut) A-Paper.
• Place the Waterslide paper on top of the lower plate and place the A-Paper on the top of it.
• Cover them with a sheet of silicone paper.
• Press together as mentioned above.
• Take the papers carefully from the heat press and let them cool down completely.
• Separate the papers from each other when they are absolutely cold.
• Cut around the transfer as exactly as possible.
• Put the transfer in water for 30 seconds. The paper will roll up.
• Rub it carefully between the fingers in order to remove the transfer foil.
• Now you can position the foil on the desired surface.
• To avoid air bubbles, streak with your fingers or a soft squeegee over the foil.
• Remove leftover water for the best quality.
• Let it dry for 3 hours.

TRANSFER PROCESS FOR OKI WHITE TONER PRINTERS WITH TRANSFER & COLOR MAPPING

• Choose the Waterslide Profile in TransferRlP and click on „Color Mapping”.
• Activate Color Mapping.
• Switch the position of Black/White with Cyan in the TransferRlP and in the printer.
• Load your design, fill up with white up to 300% and print not mirrored.
• Cut around the picture as exactly as possible.
• Put the transfer in water for 30 seconds. The paper will roll up.
• Rub it carefully between the fingers in order to remove the transfer foil.
• Now you can position the foil on the desired surface.
• To avoid air bubbles, streak with your fingers or a soft squeegee over the foil.
• Remove leftover water for the best quality.
• Let it dry for 3 hours.

TRANSFER PROCESS FOR CMYK PRINTERS

• Print the non-mirrored design onto the glossy side of the transfer paper.
• Cut around the picture as exactly as possible.
• Put the transfer in water for 30 seconds. The paper will roll up.
• Rub it carefully between the fingers in order to remove the transfer foil.
• Now you can position the foil on the desired surface.
• To avoid air bubbles, streak with your fingers or a soft squeegee over the foil.
• Remove leftover water for the best quality.
• Let it dry for 3 hours.

www.amayauk.com | 02392 590 281 | [email protected]
Southern Office: 400-450 Nest Business Park, Martin Road, Havant, Hampshire, PO9 5TL
Midlands Office: Unit 4A-C East Bridgford Business Park, Kneeton Road, East Bridgford, Nottingham, NG13 8P
