F-Tile PMA-FEC Direct PHY Multirate Intel FPGA IP
Product Information
The F-Tile PMA/FEC Direct PHY Multirate Intel FPGA IP is a
versatile IP (Intellectual Property) designed for Intel FPGA
(Field-Programmable Gate Array) devices. It provides advanced
features for physical layer communication and error correction. The
IP is compatible with the Intel Quartus Prime Pro Edition
software.
The IP is available in different versions, each offering
specific enhancements and bug fixes:
- v2.0.1 (2022.09.26): This version includes IP
enhancements and bug fixes. It is recommended to regenerate your IP
to incorporate these changes. - v2.0.0 (2022.06.21): This version adds support
for Reconfiguration groups with a total bandwidth greater than
100G. It also includes IP enhancements and bug fixes. Note that
auto upgrade does not work in this release, so you must manually
upgrade the IP after regeneration. - v1.0.0 (2022.03.28): This is the initial
release of the IP.
For access to previous versions of the user guide, please refer
to the F-Tile PMA and FEC Direct PHY Multirate Intel FPGA IP User
Guide.
Product Usage Instructions
To use the F-Tile PMA/FEC Direct PHY Multirate Intel FPGA IP,
follow these steps:
- Ensure you have the Intel Quartus Prime Pro Edition software
installed. - If you are using version v2.0.1 or v2.0.0 of the IP, regenerate
your IP to include the latest enhancements and bug fixes. - If you are using version v2.0.0 of the IP, and you require
support for Reconfiguration groups with a total bandwidth >100G,
manually upgrade the IP after regeneration. Note that auto upgrade
does not work in this release. - Refer to the F-Tile PMA and FEC Direct PHY Multirate Intel FPGA
IP User Guide for detailed instructions on configuring and
utilizing the IP for your specific application.
For any further assistance or feedback regarding the F-Tile
PMA/FEC Direct PHY Multirate Intel FPGA IP, please refer to the
provided contact information in the user manual.
F-Tile PMA/FEC Direct PHY Multirate Intel FPGA IP Release Notes
Online Version
Send Feedback
RN
ID: 726811 Version: 2022.09.26
Contents
Contents
1. F-Tile PMA/FEC Direct PHY Multirate Intel® FPGA IP Release Notes…………………………. 3 1.1. F-Tile PMA/FEC Direct PHY Multirate Intel FPGA IP v2.0.1…………………………………….. 3 1.2. F-Tile PMA/FEC Direct PHY Multirate Intel FPGA IP v2.0.0…………………………………….. 4 1.3. F-Tile PMA/FEC Direct PHY Multirate Intel FPGA IP v1.0.0…………………………………….. 4 1.4. F-Tile PMA and FEC Direct PHY Multirate Intel FPGA IP User Guide Archives………………. 4
F-Tile PMA/FEC Direct PHY Multirate Intel FPGA IP Release Notes 2
Send Feedback
726811 | 2022.09.26 Send Feedback
1. F-Tile PMA/FEC Direct PHY Multirate Intel® FPGA IP Release Notes
The Intel® FPGA IP version (X.Y.Z) number can change with each Intel Quartus® Prime software version. A change in:
· X indicates a major revision of the IP. If you update the Intel Quartus Prime software, you must regenerate the IP.
· Y indicates the IP includes new features. Regenerate your IP to include these new features.
· Z indicates the IP includes minor changes. Regenerate your IP to include these changes.
Related Information · Introduction to Intel FPGA IP Cores · F-Tile PMA and FEC Direct PHY Multirate Intel FPGA IP User Guide · F-Tile Architecture and PMA and FEC Direct PHY IP User Guide
1.1. F-Tile PMA/FEC Direct PHY Multirate Intel FPGA IP v2.0.1
Table 1.
v2.0.1 2022.09.26
Intel Quartus Prime Pro Edition
Version
Description
22.3
IP enhancements and bug fixes:
· Improved System Messages for the number of profiles.
· Improved Reconfiguration clock source parameter selection.
· Corrected Number of secondary profiles parameter numbering to start from 1.
· Added the QSF settings required for the IP.
Impact
Regenerate your IP to include these changes.
Intel Corporation. All rights reserved. Intel, the Intel logo, and other Intel marks are trademarks of Intel Corporation or its subsidiaries. Intel warrants performance of its FPGA and semiconductor products to current specifications in accordance with Intel’s standard warranty, but reserves the right to make changes to any products and services at any time without notice. Intel assumes no responsibility or liability arising out of the application or use of any information, product, or service described herein except as expressly agreed to in writing by Intel. Intel customers are advised to obtain the latest version of device specifications before relying on any published information and before placing orders for products or services. *Other names and brands may be claimed as the property of others.
ISO 9001:2015 Registered
1. F-Tile PMA/FEC Direct PHY Multirate Intel® FPGA IP Release Notes 726811 | 2022.09.26
1.2. F-Tile PMA/FEC Direct PHY Multirate Intel FPGA IP v2.0.0
Table 2.
v2.0.0 2022.06.21
Intel Quartus Prime Pro Edition
Version
Description
22.2
Added support for Reconfiguration group with total bandwidth >100G.
IP enhancements and bug fixes.
Impact
Added support for 400G-8, 300G-12, 150G-6, 200G-8 and 200G-4 Reconfigurable
groups.
You must regenerate the IP. Note: Auto upgrade does not
work in this release and you must manually upgrade the IP.
1.3. F-Tile PMA/FEC Direct PHY Multirate Intel FPGA IP v1.0.0
Table 3.
v1.0.0 2022.03.28
Intel Quartus Prime Pro Edition
Version
22.1
Initial release.
Description
Impact —
1.4. F-Tile PMA and FEC Direct PHY Multirate Intel FPGA IP User Guide Archives
For the latest and previous versions of this user guide, refer to the F-Tile PMA and FEC Direct PHY Multirate Intel FPGA IP User Guide. If an IP or software version is not listed, the user guide for the previous IP or software version applies.
F-Tile PMA/FEC Direct PHY Multirate Intel FPGA IP Release Notes 4
