High Lifter Fs-rzrpro-01 Frame Stiffener Sub Frame Gusset Kit Installation Guide (+ PDF)

Please install any warning labels provided with the product in a
visible location for yourself and all passengers. Notify all
passengers of the modifications made to your vehicle before
operating it.

Modifying your vehicle with this product may affect your
insurance coverage. Check with your insurance carrier to ensure
your coverage remains sufficient. Installing this product may also
void your vehicle warranty. If this is a concern, contact the
manufacturer or dealer before purchasing or installing the
product.

Read Before Installation:

If you are a dealer or installer, it is your responsibility to
inform your customers and end users about the potential hazards of
operating a side-by-side equipped with this component. Owners
should notify anyone operating the vehicle, as well as any
passengers, that the vehicle has been modified.

Parts Diagram:

FRAME STIFFENER & HARDWARE FS-RZRPRO-01

Frame Stiffener (1ea) – Part Number: 79-14824
M12x80mm Flange Head Bolt (2ea) – Part Number: 54-96123
M12x120mm Flange Head Bolt (2ea) – Part Number: 54-96125
M12x1.75 Lock Nut (4ea) – Part Number: 54-96126

Removing Stock Components:

For safety, ensure that the unit is supported with jack stands
before working under it and removing the lower control arm bolts.
Refer to step 2 images for proper jack placement.
Remove the factory bolts connecting the lower control arms to
the frame.

Installing the Frame Stiffener:

Position the frame stiffener plate (Part Number: 79-14824) to
align the tab holes with the frame.
Replace the factory hardware with 12mmx80mm bolts (front),
12mmx120mm bolts (back), and 12mm lock nuts.
Tighten the hardware to factory specifications.

High Lifter Limited Lifetime Warranty:

High Lifter offers a Limited Lifetime Warranty to the original
purchaser. The product is warranted to be free from defects in
material and workmanship for the life of the product if utilized in
accordance with the manufacturer’s instructions for installation
and operation.

The warranty extends to various product lines, including lift
kits, control arms, trailing arms, radiator relocation kits, portal
gear lifts, wheel spacers, tow hooks, and control arm link
kits.

This warranty is exclusive and replaces any implied warranty of
merchantability, fitness for a particular purpose, or other
warranty of quality, except for the warranty of title.

Warranty Processing:

If you suspect your product is defective, do not disassemble it
without prior approval, as it may void your warranty status.
Contact the warranty team at [email protected] to begin
the claim process and include the following information in the
email:

Your contact information
Proof of purchase
Description of the issue
Photos or videos showing the defect

View Fullscreen

FS-RZRPRO-01
79-1 5030 POLARIS RZR Pro XP 1000 Sub-Frame Support Kit
Parts Available For These Popular Brands and Others [email protected] 800-699-0947 8 00am – 5 00pm CST 7455 Atkinson Drive, Shreveport, LA 71129

PRODUCT DISCLAIMER
The installation of products sold or manufactured by High Lifter Products, Inc. including, but not limited to suspension components such as lift kits, gear reduction lifts, frame stiffener kits, snorkels, and tires that exceed the original specifications for the vehicle, may change the vehicle’s center of gravity and handling characteristics both on- and off-road. You are aware that the installation of tires that are larger than original vehicle specifications may reduce the effectiveness of the braking system. Use of these products may place added stress to the original factory vehicle components which could cause them to weaken or possibly fail.
Products sold or manufactured by High Lifter Products, Inc. are intended for off-road use only. Operation of a vehicle modified with these products on a road could result in serious bodily injury or death, and such operation may violate the laws of your state or municipality. You agree to operate your vehicle exclusively in the manner intended by the vehicle manufacturer. You agree that failure to safely and reasonably operate your vehicle could result in serious bodily injury or death, and that, as a result of installation of this product(s) to your vehicle, extreme care must be taken to prevent vehicle rollover or loss of control, which may be more likely to occur as a result of said modifications. You will avoid unsafe maneuvers, including sudden sharp turns or other abrupt maneuvers, which could make a vehicular accident more likely. You understand that High Lifter Products, Inc. is not responsible or liable for any damages or any injuries to yourself or your passengers that could occur upon possible accidents due to driver error, incorrect installations, bad judgment, incompatibility with other aftermarket accessories or natural disasters to the fullest extent allowable by law. You will have all vehicle occupants fasten seatbelts, if equipped, and wear proper safety equipment, such as DOT approved helmet and eye protection prior to operating the vehicle. You understand and acknowledge that failure to wear proper safety equipment may increase the risk of serious bodily injury or death to yourself and any passengers.
Proper installation of products sold or manufactured by High Lifter Products, Inc. requires knowledge of the factory recommended procedures for removal and installation of original equipment components. Installation of these products without proper knowledge and experience may affect the performance of these components and the safety of the vehicle and cause serious bodily injury or death. It is strongly recommended that a certified mechanic familiar with the installation of similar components perform the product(s) installation.
Prior to installing any products sold or manufactured by High Lifter Products, Inc., you will perform or cause to be performed an inspection of their vehicle to confirm its condition is suitable for the installation of these products. A proper inspection of the vehicle includes confirmation that the vehicle has not been in a collision and is free of corrosion. If the vehicle is suspected to have been in a collision or misused, or is otherwise unsuitable for modification, you will not install the product(s). You will continue to inspect the vehicle prior to each use to confirm its condition is suitable for its intended use, and you acknowledge that the failure to do so may result in serious bodily injury or death, as well as damage to the vehicle itself.
You will install any warning labels provided with the product so it may be prominently seen by yourself and all passengers. You will notify all passengers of the modifications performed to your vehicle prior to operation.
Insurance companies may handle coverage of a modified vehicle differently. Please check with your insurance carrier prior to modifying the vehicle to ensure your coverage remains sufficient. Installation of this product(s) may void your vehicle warranty. If this is a concern, please check with the manufacturer or dealer before purchase or installation of this product(s).
High Lifter Products, Inc., 7455 Atkinson Drive, Shreveport, LA 71129 – Phone: 1-800-699-0947
2

READ BEFORE INSTALLATION
By purchasing and installing High Lifter products, user agrees that should damages occur, High Lifter will not be held responsible for loss of time, use, labor fees, replacement parts, or freight charges. High Lifter will not be held responsible for any direct, indirect, incidental, special, or consequential damages that result from any product purchased from High Lifter. The total liability of seller to user for all damages, losses, & causes of action, shall not exceed the total purchase price paid for the product that gives rise to the claim.
DEALERS AND INSTALLERS
You are responsible for informing your customer and end user of the information contained above and the increased potential hazards of operating a side-by-side equipped with this component. All owners need to be informed that it is their responsibility to notify anyone operating the vehicle, as well as any passengers, that said vehicle is modified.
PARTS DIAGRAM
FRAME STIFFENER & HARDWARE FS-RZRPRO-01

79-14824
Frame Stiffener (1ea)

54-96123
M12x80mm Flange Head Bolt (2ea)

54-96125
M12x120mm Flange Head Bolt (2ea)

54-96126
M12x1.75 Lock Nut (4ea)

REMOVING STOCK COMPONENTS
1

Front INSTALL

Wheels

PASSENGER SIDE
For safety make sure that the unit is supported with jack stands before working under the unit and before removing the lower control arm bolts.
Refer to step 2 images regarding jack placement to allow for the area of installation.

REMOVING STOCK COMPONENTS
2

Factory Bolts
stiffener plate

Remove the factory bolts connecting the lower control arms to the frame.
STIFFENER

Position the frame stiffener plate 79-14824 to align the tab holes with the frame.
Install

3 Replace the factory hardware with 12mmx80mm bolts (front), 12mmx120mm bolts (back), & 12mm lock nuts.

FASTEN HARDWARE TO FACTORY SPECIFICATIONS. MCS12X80

12mm lock nut

bolt

12mmx120mm

bolt

MCS12X120

front

12mmx80mm bolt

(back)

bolt

(front)

HIGH LIFTER LIMITED LIFETIME WARRANTY
High Lifter offers a Limited Lifetime Warranty to the original purchaser that our product shall be free from defects in material and workmanship for the life of the product if utilized in accordance with the manufacturer’s instructions for installation and operation of said products.

LIMITED LIFETIME WARRANTY EXTENDS TO THE FOLLOWING PRODUCT LINES:

Lift Kits (Signature, Standard and Big Lifts)

Control Arms

Trailing Arms

Radiator Relocation Kits

Portal Gear Lifts

Wheel Spacers

Tow Hooks

Control Arm Link Kits

Damages to vehicle or any other object during the installation, use, or removal of High Lifter products are not covered under this warranty. Normal wear items included with any of the products covered under this Limited Lifetime Warranty are excluded from coverage. These items include, but are not limited to heim joints, tie rods, bearings, bushings, seals, gaskets, zinc plating, painted and powder coated finishes. Other exclusions of coverage under this warranty include, but are not limited to: damage or product failure due to improper installation, lack of maintenance, product modification, abuse, collision or use on vehicles for which product was not designed, repairs performed by anyone other than approved High Lifter personnel or made using non-High Lifter components. This warranty is valid for the original purchaser only and is non-transferable. High Lifter reserves the right to inspect any product before determining if the claim is valid and covered under this warranty. Claims determined to be caused by reasons other than a manufacturer defect will be rejected and an estimate for repair or cost of a replacement product if a repair is not possible, will be provided.
This warranty is exclusive and is in lieu of any implied warranty of merchantability, fitness for a particular purpose or other warranty of quality, whether express or implied, except the warranty of title.

WARRANTY PROCESSING
If you suspect your product is defective, DO NOT disassemble the product to determine the cause without prior approval as it may void your warranty status. This is especially true with our Portal Gear Lift. To begin the claim process, please e-mail our warranty team at [email protected] and include the following in the e-mail:

Your full name, address and contact phone number.

The year, make and model of your vehicle

The part number of the product

Photos of the product installed, and vehicle product is installed on

Proof of Purchase (Required for all warranty claims and you must be the original purchaser)

Once a claim is created, you will receive a return authorization number (RMA). Write this number on the outside of the box containing your defective product and include it along with your name and contact information inside the box. Product must be returned in the original box or a box of equal strength and packaging. Product sent without an RMA number visible on the outside of the box or sent COD will be refused. Ship your product to the following address:

High Lifter Products, Inc. Attn: Returns 7455 Atkinson Drive, Shreveport, LA 71129
Once your product is received, we often have your replacement or repaired product shipped back to you within 3-business days of receiving it. Please note that High Lifter is not responsible for shipping charges on product returned for warranty or repair, including duties and fees required by those residing outside the United States.
