MTP61 Wireless Microphone
Product Information:
The MTP61 is a wireless transmitter device manufactured by
Wisycom. It is designed for professional audio applications and
offers various features and accessories to enhance its
functionality.
The main accessories available for the MTP61 include:
- LBC61: Multiple battery charger that can charge 4 MTP61
transmitters and 4 batteries. It also provides TX management and
LTC (Timecode) functionality. - CAUSBM5P: USB/A to magnetic connector 5pin-M cable with a
length of 1050mm. This cable is used for battery charging, TX
management, and LTC Timecode sync. - LBP61: Rechargeable Lithium-ion battery (Model CS-BCE10, Part
No. CGA-S008E). It has a voltage of 3.7V, capacity of 1050 mAh, and
energy capacity of 3.9Wh. The battery is manufactured by Cameron
Sino. - BCL61: Spring-loaded belt clip for attaching the MTP61
transmitter to a belt or clothing. - BCLW61: Reversible wire belt clip for versatile attachment
options.
The MTP61 is compliant with the following regulations:
- RADIO Directive 2014/53/EU Radio Equipment Directive (RED)
- FCC-ID: POUMTP61 (for compliance with FCC regulations in the
USA) - IC IC: 11967A-MTP61 (for compliance with regulations in the
UK)
The product is manufactured by WISYCOM S.r.l, an Italian company
with global distribution and support centers.
Product Usage Instructions:
Follow the steps below to use the MTP61 transmitter:
- Ensure that the MTP61 is powered by inserting a fully charged
LBP61 Lithium-ion battery into the battery compartment. Press the
compartment to open it. - Connect a microphone to the Mic Input using the provided LEMO
type connector. - Turn on the device by pressing the SEL/ON button. To enter the
main MENU, press SEL/ON together with GAIN/UP. - Use the GAIN/UP button to quickly access gain setup frequency
menu and/or scroll up while in the menu. - Monitor the audio status using the Audio LED. It will be OFF if
audio is muted, GREEN if audio is enabled, and RED if audio is
peaking. - Check the RF/Power LED for transmission status. It will be OFF
when the MTP61 is off, GREEN when transmission is on, RED when
transmission is off, RED SLOW BLINK when battery level is below
25%, and RED FAST BLINK when battery level is below 12%. - Refer to the user manual for detailed information on advanced
settings and features of the MTP61.
If you require technical support, service, or repairs, you can
contact Wisycom Authorized Distributors in your area or directly
reach out to Wisycom via email or phone using the following contact
details:
Email: [email protected] / [email protected] /
[email protected] / [email protected]
Phone (Italy): +39 0424 382605
Phone (USA): +1 703-574-7505
For documentation, firmware, product registration, and warranty
information, visit the Wisycom website:
Website: wisycom.com
Download Page: wisycom.com/products/d/MTP61
Product Registration: wisycom.com/registration
Stay updated with Wisycom by following them on Facebook,
Instagram, and YouTube:
Facebook: facebook.com/wisycom
Instagram: instagram.com/wisycom
YouTube: youtube.com/wisycomnews
MTP61 QUICK USER GUIDE
Main Accesories (find more information at Wisycom.com )
LBC61: Multiple battery charger (4 MTP61
+ 4 batteries) + TX management + LTC
CAUSBM5P: Cable from USB/A to mag-
netic connector 5pin-M, lenght=1050mm for battery charging, TX management and LTC Timecode sync
LBP61: rechargeable Lithium-ion battery
Model CS-BCE10, Part No. CGA-S008E 3.7V, 1050 mAh, 3.9Wh, Cameron Sino
BCL61: spring loaded belt clip
BCLW61: reversible wire belt clip
LBP61: rechargeable Lithium-ion battery
Model CS-BCE10, Cameron Sino Part No. CGA-S008E. 3.7V, 1050 mAh, 3.9Wh
Conformity
conformity identification is visible on the display by accessing from the Main menu the Info> STD submenus: step 1: access submenu Info; step 2: access submenu STD.
RADIO Directive 2014/53/ EU Radio Equipment Directive (RED)
FCC-ID: POUMTP61 *
UK Conformity
IC IC: 11967A-MTP61 **
(*)The Wisycom microphone pocket transmitter model MTP61 complies with the following requirements: FCC (Federal Communications Commission) Part 74. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operations. Changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC ID can be found inside the battery compartment. This device complies with part 15 of the fcc rules. operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Note: the grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. such modifications could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. (**) EN This device complies with Industry Canada license-exempt RSS-123 and RSS-210 standard. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This radio transmitter IC: 11967A-MTP61 has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. FR Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence RSS-123 et RSS-210. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Le présent émetteur radio IC: 11967A-MTP61a été approuvé par Industrie Canada pour fonctionner avec les types d’antenne é numérés ci-dessous et ayant un gain admissible maximal et l’impédance requise pour chaque type d’antenne. Les types d’antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l’exploitation de l’émetteur. Antenna types (50 Ohm impedance, max gain 2.1dBi): AWSS-507: band 470-547 MHz, AWSS-590: band 547-663 MHz, AWSS30-950: band 940-960 MHz. This equipment complies has been evaluated for and shown compliant with the FCC and ISED RF Exposure limits. The unit of measurement for RF exposure is Specific Absorption Rate (SAR). The FCC SAR limits for is 1.6W/Kg per 1g of tissue The maximum SAR levels tested has been shown to be 0.85 W/kg at head with 0mm of separation distance from the body. This device operates on a no-interference, no-protection basis. Should the user seek to obtain protection from other radio services operating in the same TV bands, a radio license is required. For further details, consult Innovation, Science and Economic development Canada’s Client Procedures Circular CPC-2-128, Voluntary Licensing of License-Exempt Wireless Microphones in TV Bands.
MTP61-en-q03#ISTR-MTP61
Serial Number:
MTP61 QUICK USER GUIDE
Purchase Date:
This guide is intended to assist you with initial quick setup and operation of your Wisycom product.
You can refer to Wisycom Autorized Distributors for technical Support and information about service and repairs available in your area or contact us directly by email.
WISYCOM S.r.l. Via Tiepolo 7/E 35019 Tombolo (PD) – ITALY
WISYCOM INC. 14301 Sullyfield Circle, Suite C Chantilly, VA 20151- USA
+39 0424 382605
+1 703-574-7505
[email protected] [email protected]
[email protected] [email protected]
Download Documentation and Firmware
Get declarations, user manual, specifications and softwares on the download page:
wisycom.com/products/d/MTP61
Product Registration and Warranty
Register your product to extend your warranty and receive update on latest firmware:
wisycom.com/registration
Keep up with Wisycom online
Follow us on Facebook and Instagram. You can also subscribe on Youtube for more.
wisycom.com/social
Mic Mode 2 W
2 W+B 3 W AUX
Pinout 1 = GND / 3 = AF
Transmitter name
1 = GND / 3 = AF+5,5 V 1 = GND / 2 = 5,5 V / 3 = AF 1 = GND / 3 = AF (High impedance)
Frequency Group
Channel
Recording ON Bluetooth Audio bar
Mic Input (LEMO type)
Tx PWR status
Load a mic PRESET to suit your wiring or enter the Audio menu.
Battery Panel RF level status locked in mW
Antenna type
Label 507 590 552 646 710 796 808 950 1K1 1K2
Code AWSS-507 AWSS-590 AWSS-552 AWSS-646 AWSS-710 AWSS-796 AWSS-808 AWSS-950 AWSS-1K1 AWSS-1K2
Band MHz 470-547 547-663 510-595 595-698 663-760 760-832 806-810 940-960 960-1160
1240-1260
Antenna Connector (SSMA type).
Audio LED OFF: Audio is muted GREEN: Audio is enabled RED: Audio is peaking
SEL / ON Push to switch ON the device. Push together with GAIN/UP to enter the main MENU. When in menu single push to save and confirm selections.
EXIT / OFF Long press to switch the unit OFF. Short press to step back in menu Press together with SEL/ON to mute/ unmute the audio.
Battery compartment
Press to open
RF/Power LED OFF: MTP61 is OFF GREEN: Transmission is ON RED: Transmission is OFF RED SLOW BLINK: battery < 25% RED FAST BLINK: battery < 12%
Gain Shortcut/Up Push to quickly access gain setup frequency menu and/or scroll up while in the menu.
Recording Status Led Solid red when recording has started.
Ch Shortcut/Down Short press to access channel/group/ frequency menu and/or scroll down while in the menu. Long press it with EXIT/OFF to lock the front panel.
Magnetic Connector 5 pin to recharge battery, connect to Wisycom Manager, LTC Timecode sync, Download recorded files (USB High Speed).
