Director 2 Portable 20 kW DC Charging Station
Product Information:
The JUICE DIRECTOR 2 is a portable 20 kW DC charging station
designed to offer flexibility in charging electric vehicles. It
features an ergonomic design with a handle positioned at an optimal
height to prevent back pain. The charging station is equipped with
a CCS2 charger plug known for its unbreakable, high-quality
craftsmanship. There is also an emergency switch prioritizing user
safety.
For additional charging options, the JUICE DIRECTOR 2 can be
fitted with a CHAdeMO adapter as an optional extra. The charging
station ensures risk-free charging with its RCD device, overcurrent
protection, and earth fault monitoring in the optional Type 2 AC
socket. It also provides short-circuit protection, over- and
undervoltage protection, and earth fault monitoring at the DC
output terminals for maximum safety.
The JUICE DIRECTOR 2 can be equipped with a 22 kW AC socket on
request, offering guaranteed flexibility. With its IP54 protection
rating, it is suitable for use outdoors, making it a reliable
all-rounder. It can be used in garages, company showrooms or
workshops, and as a fast charging station for employees on the
go.
Designed for convenience, the JUICE DIRECTOR 2 requires no
installation costs. Simply connect it to the mains, plug it into
your vehicle, and start charging with DC power right away. Optional
RFID activation can be included to protect against unauthorized
usage and differentiate between employee usage rights.
The JUICE DIRECTOR 2 is housed in a highly robust housing
protection, ensuring its durability and reliability. It comes with
professional shock-absorbing wheels for added protection and long
service life.
Technical specifications include operating temperature
management, communication adapters (OCPP 1.5/1.6, RFID activation),
and connectivity options such as Ethernet, GSM/GPRS/UMTS, or power
line. The charging station supports CCS2 cable with the option of a
CHAdeMO adapter and/or Type-2 socket.
Compatibility is guaranteed with all existing and new electric
cars on the market fitted with a CCS2 connector. For more
information and accessories, visit juice-technology.com/juice-director.
Product Usage Instructions:
- Position the JUICE DIRECTOR 2 outside the vehicle.
- Connect the charging station to the mains power supply.
- Plug the CCS2 charger plug into your electric vehicle.
- Ensure the emergency switch is in the correct position for
safety. - If desired, add a CHAdeMO adapter or Type-2 socket for
additional charging options. - If available, activate the RFID feature to protect against
unauthorized usage. - Start charging by following the instructions specific to your
electric vehicle. - Monitor the charging process and ensure the vehicle is properly
connected. - Once charging is complete, disconnect the CCS2 charger plug
from your vehicle. - Disconnect the JUICE DIRECTOR 2 from the mains power
supply.
For any further assistance or technical support, refer to the
product manual or contact our customer service at [customer service
contact information].
Portable 20 kW DC charging station
JUICE DIRECTOR 2
JUICE DIRECTOR 2 is a 20 kW fast charging station offering all the flexibility you need.
By positioning the inverter outside the vehicle, you can charge your vehicle with DC power whenever and wherever, saving time in the process.
JUICE DIRECTOR 2 Maximum power to go
Ergonomic design
The handle is fitted at an ergonomically designed height to prevent back pain.
CCS2 charger plug
Unbreakable, high-quality craftsmanship.
Emergency switch
Your safety is our priority.
CHAdeMO
You can add a CHAdeMO adapter to the JUICE DIRECTOR 2 as an optional extra.
Risk-free charging
High power levels are often associated with higher risks. Not with JUICE.
The RCD device, overcurrent protection and earth fault monitoring in the optional Type 2 AC socket guarantee risk-free charging.
Short-circuit protection, overcurrent protection, over- and undervoltage protection, and earth fault monitoring at the DC output terminals protect you against any conceivable hazard or problem. There is no safer way to charge with DC power when you’re on the move.
More is more
Can also be equipped with a 22 kW AC socket on request. Guaranteed flexibility.
Works anywhere
With an IP54 protection rating, JUICE DIRECTOR 2 is suitable for use outdoors, making it a reliable all-rounder. Use it in your own garage at home, your company showroom or workshop, or as a fast charging station for employees on the go. JUICE DIRECTOR 2 offers an infinite range of possibilities.
Charge even faster
Ideal for vehicles with a small on-board power inverter and for vehicles with just single- or two-phase AC charging.
Professional wheels
Shock-absorbing wheels protect the technology used in JUICE DIRECTOR 2, and ensure a particularly long service life.
No installation costs
Simply connect to the mains, plug into your vehicle, and get charging with DC power right away: JUICE DIRECTOR 2 is ready to go in just a few easy steps.
Optional RFID
RFID activation can be included on request. Protect your JUICE DIRECTOR 2 against undesirable ,,charging parasites”, and
differentiate between employee usage rights.
Protection guaranteed
by the JUICE DIRECTOR 2’s highly robust housing protection, making it absolutely fit for purpose.
Technical specifications
Dimensions Weight Input current Mains connection Output power DC Output power AC Protection class conformity
Height: 1060 mm, Depth: 370 mm, Width: 770 mm 70 kg 3 x 400 V AC (± 10 %) / 45 65 Hz / 32 A CEE 32 20 kW, 170 940 V DC, max. 50 A 22 kW, 400 V AC, 32 A IP54 EN 61851-23 / DIN 70121: ISO 15118 Combo 2, CHAdeMO 0.9.1
Operating temperature Management Communication Adapters
Material colour
-20 ºC to +45 ºC
OCPP 1.5 / 1.6, RFID activation
Ethernet, GSM / GPRS / UMTS or power line
CCS2 cable (IEC 62196-3), also with CHAdeMO adapter on request (JEVS G105) and/or Type-2 socket (IEC 62196)
Rugged white 100 % metal housing anthracite housing protection, black cable
Subject to change without prior notice.
juice-technology .com
JUICE DIRECTOR 2 Miniature powerhouse on wheels
Successfully tested on a continuous basis We guarantee compatibility with all existing and new electric cars on the market fitted with a CCS2 connector.
Rugged Rugged housing with specially designed housing protection for uncompromising use in all elements.
No need for expensive installation Just put in position, plug in and charge with 100 % portable DC power no need for complex installation.
Find more information and accessories here: juice-technology.com/juice-director
