Pure Edge Lighting Cww-tw-scene-wh Smart Wi-fi Room Controller User Manual

CWW-TW-SCENE-WH Smart Wi-Fi Room Controller

Product Information:

Pantone 2995C/CP SIZE: 420 x 297 mm 80G 105 x 49.5 mm

The product is a paper material with the Pantone color code
2995C/CP. It has a size of 420 x 297 mm and is made of 80G writing
paper. Additionally, it has a smaller section with dimensions of
105 x 49.5 mm.

Smart Wi-Fi Room Controller Single Pole or 3-Way
Compatible

The product is a Smart Wi-Fi Room Controller that is compatible
with single pole or 3-way installations. Its model number is
CWW-TW-SCENE-WH.

Included in Box:

• Wire nuts x4
• Screws x2
• Room Controller x1

Specifications:

For more details, please refer to the manual. If you have any
questions during installation, please contact us at
[email protected].

Indoor use in dry location

Power: 120VAC, 60Hz

Wireless Frequency: 2.4GHz

Wireless Standard: IEEE802.11b/g/n

FCC ID: 2A9YKCWW-TW-SCENE-WH

Made in China

Product Usage Instructions:

Section 1. Installation

A Few Quick Reminders:

A quick note before we go over the wiring schematics. Please do
not try installing this device if you are unsure of how electrical
circuits operate within your home. As exciting as it is to have a
smart switch installed, it can be dangerous and even
life-threatening if you do not install this correctly. Please
consult a qualified electrician if necessary.

Smart Wi-Fi Room Controller Model: CWW-TW-SCENE-WH

1.7 (4.3cm)

Note before installation:

1. The Pure Smart Room Controller must not exceed 600W for
   hardwired loads. Hardwired installation is optional. No load
   maximum for wireless loads.
2. Works with smart loads only. Not for use with non-smart bulbs
   or fixtures. Compatible with any WiZ Connected or Pure Smart
   lamp/fixture/device.
3. Works only with another Pure Smart or WiZ Connected wall
   control for 2 location control. Only compatible with SWW-SWT-WH,
   SWW-DIM-WH, CWW-TW-SCENE-WH, and CWR-TW-SCENE-WH for multi-location
   control. May NOT be used with traditional non-smart 3-way/4way
   on-off combinations.
4. Please check the original 3-way wiring in your home before
   installation, and then follow the wiring diagram included here in
   the manual.
5. Install the smart room controller in the electrical box which
   directly connects to the power Line and Neutral.
6. This room controller requires a Neutral for installation.
7. Not recommended for use with a fan.

Section 2. Wiring Diagram

Installation:

1. Tools Needed: Flat Head Screwdriver.
2. Turn power OFF at circuit breaker or fuse box.
3. Remove wallplate.
4. Remove the switch mounting screws.
5. Disconnect the wires and label them after removing the old
   switch. Please use our sticker.
6. There are 4 different colored wire leads on the smart room
   controller, each of these are marked. Refer to the wiring diagrams
   included here for how to connect the wire leads with the existing
   conductors in the electrical box.
7. After successful wiring, install the wall plate with the
   included screws.

Pantone 2995C/CP SIZE: 420 x 297 mm 80G 105 x 49.5 mm

SIZE: 420 x 297mm

Material: 80G writing paper

Dismantling method: organ page 105 x 49.5 mm finished product

‘SPOU

Smart Wi-Fi Room Controller Single Pole or 3-Way Compatible

CWW-TW-SCENE-WH

Contents

Section 1. Installation

· Pre-installation preparation · Installation steps

Section 2. Wiring Diagram

· Wiring Instructions · Single pole and 3-way wiring diagram

Section 3. APP Pairing

· Download the app · Add a device in your app using Smart Pairing

Included in Box:
wire nuts x4
screws x2 Room Controller x1

Specifications:
Power: 120V AC, 60Hz Wireless Frequency: 2.4GHz Wireless Standard: IEEE802.11b/g/n Maximum Load: 600W for hardwired loads No Maximum for wireless loads Temperature Range: 32° F~104° F Range: up to 50 ft radius from Wi-Fi Access point Indoor use. For control of WiZ Connected smart loads only

For more details, please refer to the manual. If you have any questions during installation, please contact us [email protected]

Section 1. Installation

A Few Quick Reminders
A quick note before we go over the wiring schematics. Please do not try installing this device if you are unsure of how electrical circuits operate within your home. As exciting as it is to have a smart switch installed, it can be dangerous and even life-threatening if you do not install this correctly. Please consult a qualified electrician if necessary.

1.7″ (4.3cm)

Smart Wi-Fi Room Controller Model: CWW-TW-SCENE-WH
Indoor use in dry location Power: 120VAC, 60Hz Wireless Frequency: 2.4GHz Wireless Standard: IEEE802.11b/g/n FCC ID: 2A9YKCWW-TW-SCENE-WH
Made in China

4.15″ (10.5cm)

LINE LOAD NEUTRAL GROUND

Line Load

Ground Neutral

Line (hot) — black (connected to power)
Neutral — white Load — red (connected to lighting)
Ground — green (connected to green or bare copper ground wire in electrical box)

ON Hold to Dim Up
OFF Hold to Dim Down
Scenes Previous Scene

Air Gap Switch

CCT Up CCT Rocker CCT Down Indicator Light Next Scene

Note before installation 1) The Pure Smart Room Controller must not exceed 600W for hardwired loads. Hardwired installation is optional. No load maximum for wireless
loads. 2) Works with smart loads only. Not for use with non-smart bulbs or fixtures. Compatible with any WiZ Connected or Pure Smart lamp/fixture/device. 3) Works only with another Pure Smart or WiZ Connected wall control for 2 location control. Only compatible with SWW-SWT-WH, SWW-DIM-WH,
CWW-TW-SCENE-WH, and CWR-TW-SCENE-WH for multi-location control. May NOT be used with traditional non-smart 3-way/4way on-off combinations. 4) Please check the original 3-way wiring in your home before installation, and then follow the wiring diagram included here in the manual. 5) Install the smart room controller in the electrical box which directly connects to the power Line and Neutral. 6) This room controller requires a Neutral for installation. 7) Not recommended for use with a fan.
If you have any questions, please contact us at [email protected]

Section 2. Wiring Diagram

Installation
1. Tools Needed: Flat Head Screwdriver. 2. Turn power OFF at circuit breaker or fuse box.
3. Remove wallplate. 4. Remove the switch mounting screws.

5. Disconnect the wires and label them after removing the old switch. Please use our sticker.
Line Load Neutral Ground
6. There are 4 different colored wire leads on the smart room controller, each of these are marked. Refer to the wiring diagrams included here for how to connect the wire leads with the existing conductors in the electrical box.
7. After successful wiring, install the wall plate with the included screws.

1) Neutral wire required. If the electrical box does not have a Neutral, please stop! You may exchange this device for a Battery Operated Smart Room Controller (Type CWR-TW-SCENE-WH) which does not necessitate a neutral wire.
2) Before the old switch is detached, please identify the line voltage.
3) Only works with a smart dimmer, smart on/off, or another smart room controller for 2 location control. Not for use with traditional non-smart wall controls.
NOTE: Only for use with SWW-SWT-WH Smart On/Off Switch, SWW-DIM-WH Smart Dimmer, CWW-TW-SCENE-WH Smart Room Controller, and CWR-TW-SCENE-WH Battery Operated Smart Room Controller for multi-location control.

Single Pole Wiring
Line

CWW-TW-SCENE-WH

Black

Load (Optional)

120VAC 60 Hz
Neutral

White

Green Ground

Load, Pure Smart Light Fixture or
Bulb

Multi – Location Wiring

CWW-TW-SCENE-WH

Line

Black

Load

120VAC 60 Hz
Neutral

Green Ground
White

Black
Load, Pure Smart Light Fixture or
Bulb
White

CWW-TW-SCENE-WH

Load (Optional)

Black

Green Ground

White

Line
120VAC 60 Hz Neutral

FOR MULTI-LOCATION CONTROL: For multi-location control with the Pure Smart Room Controller and Pure Smart Wi-Fi Switch or Dimmer, you’ll place the Room Controller in the same room and make the Smart Switch or Dimmer the target for the Room Controller. For multi-location control with 2 Room Controllers, you’ll place both of them in the same room or in control of the same target. No 3 way wiring is required. Hardwired load is optional. Refer to wiring diagram and pairing instructions for additional information.

Replace Existing Traditional 3-way

Line
120VAC 60 Hz Neutral

CWW-TW-SCENE-WH Black Load
Green Ground
White

Black
Load, Pure Smart Light Fixture or
Bulb
White

CWW-TW-SCENE-WH

Load (Optional)

Black

Green Ground

Black

Section 3. App Pairing

Downloading WiZ App V2: 1. Please scan the QR code to download the application “WiZ App V2”. 2. You may also find the WiZ app in the Apple App Store or the Google Play Store under “WiZ App V2”. 3. After you download the WiZ Connected App and register a new account, please follow the instructions
below to set up your smart switch.
For WiZ Pro Dashboard Users: WiZ Pro Dashboard account and home must be created before starting commissioning in the WiZ app. Please create an account on WiZ Pro Dashboard. Then create your home or location. After doing so, you may proceed to create an invitation in the dashboard by going to “settings” and then the “members” tab. By clicking on the “Invite” button you will be able to generate an invitation to access this dashboard location in the WiZ app. From there you can proceed with commissioning in the WiZ app but also have the added functionality of the Dashboard desktop application.

PLEASE READ BEFORE PAIRING ROOM CONTROLLER IN WiZ APP: In the WiZ app, any Pure Smart / WiZ Connected fixture(s) must be added to a room prior to adding the
Room Controller that will control them. Please refer to the installation manual included with the Pure Smart / WiZ Connected light fixtures for setup.

1
Once your lamps or fixtures have been connected, press the plus sign in the top
right hand corner to add your smart room controller.

2
Select “Wall Controller” from the available device types.

Smart Pairing

3
Select whichever room the Wall Controller will be installed in or
controlling.

4
Follow the on-screen instructions and ensure that your Wall Controller is connected to 120V
power and then press “START”.

5

6

Follow the on-screen instructions by

When you receive the “Accessory found”

pressing the On button 3 times and wait message you may press done and begin while the WiZ app looks for your Wall controlling the light fixtures in that room with

Controller.

your Wall Controller. Follow additional

instructions below to personalize settings and

controls.

FCC This device complies with part 15 of the FCC and Industry Canada license-exempt RSS standard(s). Operation is subjected to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.
— Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Important note: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. This equipment complies w it h FCC radiat ion exposure limit s set f ort h f or an uncont rolled environment .This equipment should be inst alled and operat ed w it h minimum dist ance 2 0 cm bet w een t he radiat or&your body.
CAUTION – PLEASE READ!
This device is intended for installation in accordance with the National Electric Code and local regulations in the United States, or the Canadian Electrical Code and local regulations in Canada. If you are unsure or uncomfortable about performing this installation consult a qualified electrician.
WARNING – SHOCK HAZARD
TURN OFF THE POWER to the circuit for the switch and lighting fixture at the service panel (circuit breaker) prior to installation. ALL WIRING CONNECTIONS MUST BE MADE WITH THE POWER OFF to avoid personal injury and/or damage to the switch.
OTHER WARNINGS
Risk of Fire Risk of Electrical Shock Risk of Burns V1.0
WiZ Pro Software Suite

1
For additional setup, select “Settings” on the bottom right hand corner of the Home
screen.

2
Select “Accessories” from the Settings menu.

Additional Settings for Wall Controller Accessory

3
Select the Wall Controller that you’d like to customize control with.

4
If needed, you have the option to rename your Wall Controller.

5
You can select individual targets that the Wall Controller will control by choosing
specific fixtures or devices.

6
Or you can choose an entire room for the Wall Controller to control.
