150 CRZ Aluminum Electrolytic Capacitors SMD (Chip), Very Low Z
Product Information
The 150 CRZ is an aluminum electrolytic capacitor SMD (chip)
manufactured by Vishay BCcomponents. It is designed with a very low
impedance (Z) and is suitable for various applications.
The capacitor comes in different nominal case sizes ranging from
8 x 8 x 10 mm to 18 x 18 x 21 mm. It has a rated capacitance range
from 6.3 V to 100 V and a tolerance on CR. The rated voltage range
is 6.3 V to 63 V for certain types, and 80 V to 100 V for others.
The category temperature range varies from 2000 h to 8000 h for
some types, and 2500 h to 10,000 h for others. The climatic
category is IEC 60068.
For more detailed specifications and information, please refer
to the document available at www.vishay.com/doc?99912.
Product Usage Instructions
1. Determine the required capacitance value (CR) and rated
voltage (UR) for your application.
2. Refer to the selection chart provided in the user manual to
find the relevant nominal case size (L x W x H in mm) for your
desired CR and UR.
3. Once you have identified the appropriate nominal case size,
locate the corresponding dimensions in Fig. 2 – Dimensional outline
for reference.
4. The capacitor is supplied in blister tape on a reel
packaging.
5. Follow standard guidelines for handling and soldering SMD
components when installing the capacitor onto your circuit
board.
Note: This product is subject to change without notice. For any
technical questions or further assistance, please contact
[email protected].
www.vishay.com
150 CRZ
Vishay BCcomponents
Aluminum Electrolytic Capacitors SMD (Chip), Very Low Z
140 CRH 125 °C
Lower Z
146 CTI
High temp.
153 CRV
Lower Z
150 CRZ Fig. 1
QUICK REFERENCE DATA
DESCRIPTION
VALUE
Nominal case sizes (L x W x H in mm)
8 x 8 x 10 to 18 x 18 x 21
Rated capacitance range, CR Tolerance on CR Rated voltage range, UR Category temperature range
4.7 F to 10 000 F ± 20 %
6.3 V to 100 V
6.3 V to 63 V:
-55 °C to +105 °C
80 V to 100 V:
-40 °C to +105 °C
Endurance test at 105 °C
2000 h to 8000 h
Useful life at 105 °C
2500 h to 10 000 h
Useful life at 40 °C; 1.8 x lR applied
Shelf life at 0 V, 105 °C
125 000 h to 500 000 h 1000 h
Based on sectional specification
IEC 60384-18 / CECC 32300
Climatic category IEC 60068
6.3 V to 63 V:
55 / 105 / 56
80 V to 100 V:
40 / 105 / 56
FEATURES · Extended useful life: up to 10 000 h at 105 °C
for MAL215099…E3 parts · Polarized aluminum electrolytic capacitors,
non-solid electrolyte, self healing · SMD-version with base plate, lead (Pb)-free
reflow solderable · Very low impedance, very high ripple current · Charge and discharge proof, no peak current limitation · Parts for advanced high temperature reflow soldering
according to JEDEC® J-STD-020 · Vibration proof, 4-pin version and 6-pin version · AEC-Q200 qualified · High reliability · Low ESR · Material categorization: for definitions of compliance
please see www.vishay.com/doc?99912
APPLICATIONS · SMD technology, for high temperature reflow soldering · Industrial and professional applications · Automotive, general industrial, telecom · Smoothing, filtering, buffering
MARKING · Rated capacitance (in F) · Rated voltage (in V) · Date code, in accordance with IEC 60062 · Black mark or “-” sign indicating the cathode (the anode is
identified by bevelled edges) · Code indicating group number (Z)
PACKAGING Supplied in blister tape on reel
Revision: 12-Dec-16
1
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
150 CRZ
Vishay BCcomponents
SELECTION CHART FOR CR, UR, AND RELEVANT NOMINAL CASE SIZES (L x W x H in mm)
CR
UR (V)
(µF)
6.3
10
16
25
35
50
63
80
100
4.7
10 x 10 x 10
10
10 x 10 x 10
22
10 x 10 x 10
33
8 x 8 x 10
10 x 10 x 10
47
8 x 8 x 10 10 x 10 x 10
10 x 10 x 10
10 x 10 x 12 –
68
8 x 8 x 10 10 x 10 x 10
12.5 x 12.5 x 13
100
8 x 8 x 10 10 x 10 x 10 10 x 10 x 12 10 x 10 x 12 12.5 x 12.5 x 13
10 x 10 x 14
–
150
8 x 8 x 10
12.5 x 12.5 x 1312.5 x 12.5 x 1312.5 x 12.5 x 16
220
8 x 8 x 10
8 x 8 x 10
10 x 10 x 10
10 x 10 x 12 10 x 10 x 14
12.5 x 12.5 x 1612.5 x 12.5 x 16
16 x 16 x 16 –
330
8 x 8 x 10
8 x 8 x 10
10 x 10 x 12
16 x 16 x 21
10 x 10 x 10
12.5 x 12.5 x 13 16 x 16 x 16 16 x 16 x 16
10 x 10 x 14
18 x 18 x 16
10 x 10 x 12
470 8 x 8 x 10 8 x 8 x 10 10 x 10 x 10
12.5 x 12.5 x 13
10 x 10 x 14
16 x 16 x 21 16 x 16 x 21 18 x 18 x 21
18 x 18 x 16 18 x 18 x 16
–
680
10 x 10 x 10 10 x 10 x 12 12.5 x 12.5 x 1312.5 x 12.5 x 16 16 x 16 x 16 18 x 18 x 21 18 x 18 x 21
–
10 x 10 x 14
–
10 x 10 x 12
16 x 16 x 21
–
–
–
1000 10 x 10 x 10
12.5 x 12.5 x 1312.5 x 12.5 x 16 16 x 16 x 16
10 x 10 x 14
18 x 18 x 16
–
–
–
1500
16 x 16 x 21 18 x 18 x 21
12.5 x 12.5 x 1312.5 x 12.5 x 16 16 x 16 x 16 18 x 18 x 16
–
–
–
–
16 x 16 x 21 18 x 18 x 21
–
–
–
–
2200 12.5 x 12.5 x 1312.5 x 12.5 x 16 16 x 16 x 16
18 x 18 x 16
–
–
–
–
–
3300
16 x 16 x 21 18 x 18 x 21 16 x 16 x 16
–
–
–
–
–
18 x 18 x 16
–
–
–
–
–
–
16 x 16 x 21 18 x 18 x 21
–
–
–
–
–
–
4700 16 x 16 x 16 18 x 18 x 16
–
–
–
–
–
–
–
16 x 16 x 21 18 x 18 x 21
–
–
–
–
–
–
–
6800
18 x 18 x 16
–
–
–
–
–
–
–
–
10 000 18 x 18 x 21
–
–
–
–
–
–
–
–
2-pin: Ø 10 mm
HMAX. MAX 0.3
4-pin: Ø 12.5 mm
D
HMAX. MAX 0.3
6-pin: Ø 16 mm
D
HMAX. MAX. 0.3
D
min. 0.4/max. 1.0 (2 x) min. 0.4/max. 1.0 (2 x) min. 0.4/max. 1.0 (2 x)
35V 1000u 3R-H 25V 1000u A4-H 25V 220 u A4-H
WMAX. B
L1MAX.S
LMAX.
WMAX. B
L1MAX. S
LMAX.
WMAX. B
L1MAX. S
LMAX.
Fig. 2 – Dimensional outline
Revision: 12-Dec-16
2
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
150 CRZ
Vishay BCcomponents
Table 1
DIMENSIONS in millimeters AND MASS
NOMINAL CASE SIZE L x W x H
CASE CODE
LMAX.
WMAX.
HMAX.
Ø D
BMAX.
8 x 8 x 10
0810
8.5
8.5
10.5
8.0
1.0
10 x 10 x 10
1010
10.5
10.5
10.5
10.0
1.0
10 x 10 x 12
1012
10.5
10.5
12.5
10.0
1.0
10 x 10 x 14
1014
10.5
10.5
14.3
10.0
1.0
12.5 x 12.5 x 13
1213
12.9
12.9
14.0
12.5
1.3
12.5 x 12.5 x 16
1216
12.9
12.9
16.5
12.5
1.3
16 x 16 x 16
1616
16.6
16.6
17.5
16.0
1.3
16 x 16 x 21
1621
16.6
16.6
22.0
16.0
1.3
18 x 18 x 16
1816
19.0
19.0
17.5
18.0
1.3
18 x 18 x 21
1821
19.0
19.0
22.0
18.0
1.3
S
L1MAX.
MASS (g)
2.2
10.2
1.0
3.5
12.1
1.3
3.5
12.1
1.5
3.5
12.1
1.5
3.6
14.9
2.6
3.6
14.9
2.8
6.5
18.6
5.5
6.5
18.6
6.0
6.5
21.0
8.0
6.5
21.0
8.3
Table 2
TAPE AND REEL DIMENSIONS in millimeters, PACKAGING QUANTITIES
NOMINAL CASE SIZE L x W x H
CASE CODE
PITCH P1
TAPE WIDTH W
TAPE THICKNESS
T2
REEL DIAMETER
8 x 8 x 10
0810
16
24
11.6
380
10 x 10 x 10
1010
16
24
11.6
380
10 x 10 x 12
1012
16
24
12.8
330
10 x 10 x 14
1014
16
24
15.4
330
12.5 x 12.5 x 13
1213
20
24
16.2
380
12.5 x 12.5 x 16
1216
24
32
18.5
380
16 x 16 x 16
1616
28
44
18.9
380
16 x 16 x 21
1621
28
44
23.4
380
18 x 18 x 16
1816
32
44
18.9
380
18 x 18 x 21
1821
32
44
23.4
380
Note · Detailed tape dimensions see section “PACKAGING”.
PACKAGING QUANTITY PER REEL
500 500 250 250 250 200 150 100 125 100
Revision: 12-Dec-16
3
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
MOUNTING The capacitors are designed for automatic placement on to printed-circuit boards. Optimum dimensions of soldering pads depend amongst others on soldering method, mounting accuracy, print layout and / or adjacent components. For recommended soldering pad dimensions, refer to Fig. 3 and Table 3.
150 CRZ
Vishay BCcomponents
SOLDERING Soldering conditions are defined by the curve, temperature versus time, where the temperature is that measured on the component during processing. For maximum conditions refer to Fig. 4 or Fig. 5. Any temperature versus time curve which does not exceed the specified maximum curves may be applied. As a general principle, temperature and duration shall be the minimum necessary required to ensure good soldering connections. However, the specified maximum curves should never be exceeded.
b
a
c
a
Case size Ø D 10 mm
e d
b
f
d
a
c
a
Case size Ø D = 12.5 mm
Fig. 3 – Recommended soldering pad dimensions
a
c
a
b
Case size Ø D 16 mm
Table 3
RECOMMENDED SOLDERING PAD DIMENSIONS in millimeters
CASE CODE
a
b
c
d
e
f
0810
4.4
2.5
3.0
–
–
–
1010
4.4
2.5
4.0
–
–
–
1012
4.4
2.5
4.0
–
–
–
1014
4.4
2.5
4.0
–
–
–
1213
6.3
2.5
4.0
4.2
5.0
5.6
1216
6.3
2.5
4.0
4.2
5.0
5.6
1616
7.8
9.6
4.7
–
–
–
1621
7.8
9.6
4.7
–
–
–
1816
8.8
9.6
4.7
–
–
–
1821
8.8
9.6
4.7
–
–
–
Revision: 12-Dec-16
4
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
150 CRZ
Vishay BCcomponents
STANDARD SOLDERING PROFILE FOR LEAD (Pb)-FREE REFLOW PROCESS
T (°C) TPeak
230
217
t4
200
t3
150
t1
t2
Fig. 4 – Maximum temperature load during reflow soldering
time (s)
Table 4
REFLOW SOLDERING CONDITIONS for MAL215097xxxE3
PROFILE FEATURES
CASE CODE 0810 TO 1014
Max. time from 25 °C to Tpeak Max. ramp-up rate to 150 °C
240 s 3 K/s
Max. time from 150 °C to 200 °C (t1)
150 s
Ramp up rate from 200 °C to Tpeak
0.5 K/s to 3 K/s
Max. time from 200 °C to 217 °C (t2)
60 s
Max. time above TLiquidus (217 °C) (t3)
90 s
Max. time above 230 °C (t4)
40 s
Peak temperature Tpeak
250 °C
Max. time above Tpeak minus 5 °C
5 s
Max. ramp-down rate from TLiquidus
3 K/s to 6 K/s
Notes · Temperature measuring point on top of the case and on terminals. · Max. 2 runs with pause of min. 30 min in between.
CASE CODE 1213 TO 1216
200 s 3 K/s 120 s 0.5 K/s to 3 K/s 60 s 60 s 30 s 240 °C 10 s 3 K/s to 6 K/s
Revision: 12-Dec-16
5
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
150 CRZ
Vishay BCcomponents
ADVANCED SOLDERING PROFILE FOR LEAD (Pb)-FREE REFLOW PROCESS ACCORDING TO JEDEC J-STD-020
T (°C) TPeak
230 217 200 190
150
t4 t3
t2 t1
25
Fig. 5 – Maximum temperature load during reflow soldering
time (s)
Table 5
REFLOW SOLDERING CONDITIONS for MAL215099xxxE3
PROFILE FEATURES
CASE CODE 1010 TO 1012
Max. time from 25 °C to TPeak Max. ramp-up rate to 150 °C
300 s 3 K/s
Max. time from 150 °C to 200 °C (t1)
150 s
Max. time from 190 °C to 200 °C (t2)
110 s
Ramp up rate from 200 °C to TPeak
0.5 K/s to 3 K/s
Max. time above TLiquidus (217 °C) (t3)
90 s
Max. time above 230 °C (t4)
70 s
Peak temperature TPeak
260 °C
Max. time above TPeak minus 5 °C
40 s
Ramp-down rate from TLiquidus
3 K/s to 6 K/s
Notes · Temperature measuring point on top of the case and on terminals. · Max. 2 runs with pause of min. 30 min in between.
CASE CODE 1213 TO 1216
300 s 3 K/s 150 s 110 s 0.5 K/s to 3 K/s 90 s 65 s 250 °C 30 s 3 K/s to 6 K/s
CASE CODE 1616 TO 1821
300 s 3 K/s 150 s 110 s 0.5 K/s to 3 K/s 90 s 60 s 245 °C 30 s 3 K/s to 6 K/s
Revision: 12-Dec-16
6
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
150 CRZ
Vishay BCcomponents
ELECTRICAL DATA
SYMBOL
DESCRIPTION
CR IR IL2 tan
Rated capacitance at 100 Hz, tolerance ± 20 % Rated RMS ripple current at 100 kHz, 105 °C Max. leakage current after 2 min at UR Max. dissipation factor at 100 Hz
Z
Max. impedance at 100 kHz
Note
· Unless otherwise specified, all electrical values in Table 6 apply at Tamb = 20 °C, P = 86 kPa to 106 kPa, RH = 45 % to 75 %
ORDERING EXAMPLE Electrolytic capacitor 150 CRZ series 470 F / 35 V; ± 20 % Nominal case size: 12.5 mm x 12.5 mm x 13 mm; taped on reel Ordering code: MAL215099012E3
Table 6
ELECTRICAL DATA AND ORDERING INFORMATION
UR (V)
CR (µF)
NOMINAL CASE SIZE IR 105 °C
L x W x H
100 kHz
(mm)
(mA)
IL 2 min
(µA)
tan 100 Hz
Z 100 kHz
20 °C ()
Z 100 kHz -40 °C
()
LIFE CODE (3)
470 1000 2200 2200 6.3 4700 6800 6800 10 000 330 470 680 1000 1000 1500 10 1500 2200 2200 3300 4700 4700 6800 220 330 470 680 680 1000 16 1000 1500 1500 2200 3300 3300 4700
8 x 8 x 10 10 x 10 x 10 12.5 x 12.5 x 13 12.5 x 12.5 x 13 16 x 16 x 16 16 x 16 x 21 18 x 18 x 16 18 x 18 x 21
8 x 8 x 10 8 x 8 x 10 10 x 10 x 10 10 x 10 x 12 10 x 10 x 14 12.5 x 12.5 x 13 12.5 x 12.5 x 13 12.5 x 12.5 x 16 12.5 x 12.5 x 16 16 x 16 x 16 16 x 16 x 21 18 x 18 x 16 18 x 18 x 21 8 x 8 x 10 8 x 8 x 10 10 x 10 x 10 10 x 10 x 12 10 x 10 x 14 12.5 x 12.5 x 13 12.5 x 12.5 x 13 12.5 x 12.5 x 16 12.5 x 12.5 x 16 16 x 16 x 16 16 x 16 x 21 18 x 18 x 16 18 x 18 x 21
435
30
0.24 0.250 2.00
L1
670
63
0.24 0.130 1.10
L2
905
139
0.26 0.077 0.60
L3
905
139
0.26 0.077 0.60
L4
1350
296
0.28 0.050 0.40
L6
1666
428
0.30 0.035 0.28
L6
1400
428
0.32 0.050 0.40
L6
1756
630
0.34 0.035 0.28
L6
435
33
0.20 0.250 2.00
L1
435
47
0.20 0.250 2.00
L1
670
68
0.20 0.130 1.10
L2
850
100
0.20 0.100 0.80
L2
850
100
0.20 0.100 0.80
L2
905
150
0.22 0.077 0.60
L3
905
150
0.22 0.077 0.60
L4
1007
220
0.22 0.060 0.48
L3
1007
220
0.22 0.060 0.48
L5
1350
330
0.24 0.050 0.40
L6
1666
470
0.26 0.035 0.28
L6
1400
470
0.26 0.050 0.40
L6
1756
680
0.28 0.035 0.28
L6
435
35
0.16 0.250 2.00
L1
435
53
0.16 0.250 2.00
L1
670
75
0.16 0.130 1.10
L2
850
109
0.16 0.100 0.80
L2
850
109
0.16 0.100 0.80
L2
905
160
0.18 0.077 0.60
L3
905
160
0.18 0.077 0.60
L4
1007
240
0.18 0.060 0.48
L3
1007
240
0.18 0.060 0.48
L5
1350
352
0.20 0.050 0.40
L6
1666
528
0.22 0.035 0.28
L6
1400
528
0.22 0.050 0.40
L6
1756
752
0.26 0.035 0.28
L6
Notes
(1) Standard reflow soldering profile, see Fig. 4 and Table 4 (2) Advanced reflow soldering profile, according to JEDEC J-STD-020, see Fig. 5 and Table 5 (3) Determines the applicable row in the table “Endurance Test Duration and Useful Life”
ORDERING CODE (1)
MAL2150…
97311E3 97301E3 97312E3
97411E3 97412E3 97401E3 97402E3 97413E3 97414E3 97511E3 97512E3 97501E3 97502E3 97513E3 97514E3 –
ORDERING CODE (2)
MAL2150…
99301E3
99312E3 99313E3 99314E3 99315E3 99316E3
99401E3 99403E3 99413E3 99414E3 99415E3 99416E3 99417E3 99418E3 99501E3 99503E3 99513E3 99514E3 99515E3 99516E3 99517E3 99518E3
Revision: 12-Dec-16
7
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
150 CRZ
Vishay BCcomponents
ELECTRICAL DATA AND ORDERING INFORMATION
UR (V)
CR (µF)
NOMINAL CASE SIZE IR 105 °C
L x W x H
100 kHz
(mm)
(mA)
IL 2 min
(µA)
tan 100 Hz
Z 100 kHz
20 °C ()
Z 100 kHz -40 °C
()
LIFE CODE (3)
150
8 x 8 x 10
420
38
0.14 0.280 2.24
L1
220
8 x 8 x 10
420
55
0.14 0.280 2.24
L1
330
10 x 10 x 10
640
83
0.14 0.140 1.12
L2
470
10 x 10 x 12
820
118
0.14 0.110 0.88
L2
470
10 x 10 x 14
820
118
0.14 0.110 0.88
L2
680
12.5 x 12.5 x 13
905
170
0.16 0.077 0.60
L3
25
680
12.5 x 12.5 x 13
905
170
0.16 0.077 0.60
L4
1000
12.5 x 12.5 x 16
1007
250
0.16 0.060 0.48
L3
1000
12.5 x 12.5 x 16
1007
250
0.16 0.060 0.48
L5
1500
16 x 16 x 16
1350
375
0.16 0.050 0.40
L6
2200
16 x 16 x 21
1666
550
0.18 0.035 0.28
L6
2200
18 x 18 x 16
1400
550
0.18 0.050 0.40
L6
3300
18 x 18 x 21
1756
825
0.20 0.035 0.28
L6
100
8 x 8 x 10
405
35
0.12 0.300 2.40
L1
220
10 x 10 x 10
630
77
0.12 0.150 1.20
L2
330
10 x 10 x 12
790
116
0.12 0.120 0.96
L2
330
10 x 10 x 14
790
116
0.12 0.120 0.96
L2
470
12.5 x 12.5 x 13
905
165
0.14 0.077 0.60
L3
470 35
680
12.5 x 12.5 x 13 12.5 x 12.5 x 16
905
165
0.14 0.077 0.60
L4
1007
238
0.14 0.060 0.48
L3
680
12.5 x 12.5 x 16
1007
238
0.14 0.060 0.48
L5
1000
16 x 16 x 16
1350
350
0.14 0.050 0.40
L6
1500
16 x 16 x 21
1666
525
0.14 0.035 0.28
L6
1500
18 x 18 x 16
1400
525
0.14 0.050 0.40
L6
2200
18 x 18 x 21
1756
770
0.16 0.035 0.28
L6
68
8 x 8 x 10
333
34
0.12 0.480 3.84
L1
100
10 x 10 x 10
490
50
0.12 0.240 1.92
L2
220
10 x 10 x 12
620
110
0.12 0.190 1.52
L2
220
10 x 10 x 14
620
110
0.12 0.190 1.52
L2
330 50
330
12.5 x 12.5 x 13 12.5 x 12.5 x 13
690
165
0.12 0.130 1.04
L3
690
165
0.12 0.130 1.04
L4
680
16 x 16 x 16
1035
340
0.12 0.085 0.68
L6
1000
16 x 16 x 21
1100
500
0.12 0.080 0.64
L6
1000
18 x 18 x 16
1074
500
0.12 0.085 0.68
L6
1500
18 x 18 x 21
1470
750
0.12 0.080 0.64
L6
33
8 x 8 x 10
270
21
0.10 0.650 5.20
L1
47
8 x 8 x 10
270
30
0.10 0.650 5.20
L1
47
10 x 10 x 10
390
30
0.10 0.380 3.00
L2
68
10 x 10 x 10
390
43
0.10 0.380 3.00
L2
100
10 x 10 x 12
507
63
0.10 0.290 2.32
L2
100
10 x 10 x 14
507
63
0.10 0.290 2.32
L2
150 63
150
12.5 x 12.5 x 13 12.5 x 12.5 x 13
507
97
0.10 0.250 2.00
L3
507
97
0.10 0.250 2.00
L4
220
12.5 x 12.5 x 16
637
141
0.10 0.200 1.60
L3
220
12.5 x 12.5 x 16
637
141
0.10 0.200 1.60
L5
330
16 x 16 x 16
910
208
0.10 0.150 1.20
L6
470
16 x 16 x 21
987
296
0.10 0.120 0.96
L6
470
18 x 18 x 16
944
296
0.10 0.150 1.20
L6
680
18 x 18 x 21
1160
428
0.10 0.120 0.96
L6
Notes
(1) Standard reflow soldering profile, see Fig. 4 and Table 4 (2) Advanced reflow soldering profile, according to JEDEC J-STD-020, see Fig. 5 and Table 5 (3) Determines the applicable row in the table “Endurance Test Duration and Useful Life”
ORDERING CODE (1)
MAL2150…
97611E3 97612E3 97601E3
97602E3 97613E3
97614E3
97011E3 97001E3 97002E3 97012E3 97013E3 97111E3 97101E3 97102E3 97112E3 97812E3 97811E3 97801E3 97802E3 97803E3 97821E3 97815E3 –
ORDERING CODE (2)
MAL2150…
99601E3 99603E3 99613E3 99614E3 99615E3 99616E3 99617E3 99618E3 99001E3 99003E3 99012E3 99013E3 99014E3 99015E3 99016E3 99017E3 99101E3 99103E3 99112E3 99114E3 99115E3 99116E3 99117E3 99801E3 99802E3 99804E3 99821E3 99815E3 99816E3 99817E3 99818E3 99819E3
Revision: 12-Dec-16
8
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
150 CRZ
Vishay BCcomponents
ELECTRICAL DATA AND ORDERING INFORMATION
UR (V)
CR (µF)
NOMINAL CASE SIZE IR 105 °C
L x W x H
100 kHz
(mm)
(mA)
IL 2 min
(µA)
tan 100 Hz
Z 100 kHz
20 °C ()
Z 100 kHz -40 °C
()
LIFE CODE (3)
47
10 x 10 x 10
240
38
0.10 0.800 6.40
L2
100
10 x 10 x 12
300
80
0.10 0.620 4.96
L2
150
12.5 x 12.5 x 13
670
120
0.10 0.350 2.80
L3
220 80
330
12.5 x 12.5 x 16 16 x 16 x 16
750
176
0.10 0.250 2.00
L3
1000
264
0.10 0.180 1.44
L3
470
16 x 16 x 21
1400
376
0.10 0.120 0.96
L3
470
18 x 18 x 16
1050
376
0.10 0.160 1.28
L3
680
18 x 18 x 21
1450
544
0.10 0.110 0.88
L3
4.7
10 x 10 x 10
210
5
0.10 0.800 6.40
L2
10
10 x 10 x 10
240
10
0.10 0.800 6.40
L2
22
10 x 10 x 10
240
22
0.10 0.800 6.40
L2
33
10 x 10 x 10
250
33
0.10 0.800 6.40
L2
47
10 x 10 x 12
270
47
0.10 0.620 4.96
L2
68 100
100
12.5 x 12.5 x 13 12.5 x 12.5 x 13
660
68
0.10 0.350 2.80
L3
660
100
0.10 0.350 2.80
L3
150
12.5 x 12.5 x 16
750
150
0.10 0.250 2.00
L3
220
16 x 16 x 16
1000
220
0.10 0.180 1.44
L3
330
16 x 16 x 21
1400
330
0.10 0.120 0.96
L3
330
18 x 18 x 16
1050
330
0.10 0.160 1.28
L3
470
18 x 18 x 21
1450
470
0.10 0.110 0.80
L3
Notes
(1) Standard reflow soldering profile, see Fig. 4 and Table 4 (2) Advanced reflow soldering profile, according to JEDEC J-STD-020, see Fig. 5 and Table 5 (3) Determines the applicable row in the table “Endurance Test Duration and Useful Life”
ORDERING CODE (1)
MAL2150…
97701E3 –
97901E3 97902E3 97903E3 97904E3
–
ORDERING CODE (2)
MAL2150…
99701E3 99702E3 99703E3 99704E3 99705E3 99706E3 99707E3 99708E3
99902E3 99903E3 99904E3 99905E3 99906E3 99907E3 99908E3 99909E3 99911E3 99912E3 99913E3
Table 7 ADDITIONAL ELECTRICAL DATA
PARAMETER Voltage Surge voltage for short periods Reverse voltage for short periods Current Leakage current Inductance
Equivalent series inductance (ESL)
Resistance Equivalent series resistance (ESR) at 100 Hz
CONDITIONS
IEC 60384-18, subclause 4.14 IEC 60384-18, subclause 4.16
After 2 min at UR
Ø D = 8 mm Ø D = 10 mm Ø D 12.5 mm
Calculated from tan max. and CR (see Table 6)
VALUE
Us 1.1 x UR Urev 1 V
IL2 0.01 x CR x UR
Typ. 6 nH Typ. 8 nH Typ. 11 nH
ESR = tan /2fCR
Revision: 12-Dec-16
9
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
CAPACITANCE
1.2 C/C0
1 1.1
2, 3 1.0
0.9
2
3
1
Curve 1: 10 V Curve 2: 63 V
Curve 3: 100 V
0.8
-60 -40 -20 0
20 40 60 80 100 T (°C)
C0 = Capacitance at 20 °C, 100 Hz
Fig. 6 – Typical multiplier of capacitance as a function of temperature at 100 Hz
EQUIVALENT SERIES RESISTANCE (ESR)
100 ESR/ ESR0
2 10
1 1
Curve 1: 6.3 V to 63 V
Curve 2: 100 V 0.1
-60 -40 -20
0
20 40 60 80 100
T (°C)
ESR0 = Typical ESR at 20 °C, 100 Hz
Fig. 8 – Typical multiplier of ESR as a function of temperature at 100 Hz
DISSIPATION FACTOR (tan )
100
tan/ tan0
2 10
1 1
Curve 1: 6.3 V to 63 V Curve 2: 100 V
0.1
-60 -40 -20 0
20 40 60 80 100 T (°C)
tan 0 = Typical tan at 20 °C, 100 Hz
Fig. 10 – Typical multiplier of dissipation factor tan as a function of temperature at 20 °C at 100 Hz
150 CRZ
Vishay BCcomponents
1.2 C/C0
1.0
0.8 2
0.6 1
0.4
0.2
Curve 1: 10 V
Curve 2: 63 V, 100 V
0.0
101
102
103
C0 = Typical capacitance at 20 °C, 100 Hz
104
105
f (Hz)
Fig. 7 – Typical multiplier of capacitance as a function of frequency at 20 °C
10 ESR/ ESR0
1
0.1
101
10 2
103
104
105
f (Hz)
ESR0 = Typical ESR at 20 °C, 100 Hz
Fig. 9 – Typical multiplier ESR as a function of frequency at 20 °C
IMPEDANCE (Z)
100
Z/Z0 2
10
1 1
Curve 1: 6.3 V to 63 V Curve 2: 100 V 0.1 -60 -40 -20 0 20 40 60
Z0 = Typical impedance Z at 20 °C, 100 kHz
80 100 T (°C)
Fig. 11 – Typical multiplier of impedance Z as a function of temperature at 100 kHz
Revision: 12-Dec-16
10
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
IMPEDANCE (Z)
100 Z ()
10
1
Curve 1: 220-25-0810 Curve 2: 330-25-1010 Curve 3: 470-25-1014 Curve 4: 680-25-1213 Curve 5: 1000-25-1216 Curve 6: 1500-25-1616 Curve 7: 3300-25-1821
0.1
0.01 101
1 2 3 4 5 6 7
102
103
104
105
f (Hz)
Fig. 12 – Typical impedance Z as a function of frequency at 20 °C
150 CRZ
Vishay BCcomponents
1000 Z () 100
10
1
0.1
Curve 1: 47-63-0810 Curve 2: 68-63-1010 Curve 3: 100-63-1014 Curve 4: 150-63-1213 Curve 5: 220-63-1216 Curve 6: 330-63-1616 Curve 7: 680-63-1821 1 2 3 4 5 6 7
0.01
101
102
103
104
105
f (Hz)
Fig. 13 – Typical impedance Z as a function of frequency at 20 °C
10 000 Z ()
1000
100
1
10
2
3
4
Curve 1: 4,7-100-1010
1
Curve 2: 10-100-1010
Curve 3: 22-100-1010
Curve 4: 33-100-1010
0.1
101
102
103
104
105
f (Hz)
Fig. 14 – Typical impedance Z as a function of frequency at 20 °C
RIPPLE CURRENT AND USEFUL LIFE
Table 8
ENDURANCE TEST DURATION AND USEFUL LIFE
LIFE CODE
ENDURANCE AT 105 °C (h)
L1
2000
L2
2000
L3
3000
L4
5000
L5
6500
L6
8000
Note · Multiplier of useful life code: CCC206
USEFUL LIFE AT 105 °C (h)
2500 3000
5000 6000 7500
10 000
USEFUL LIFE AT 40 °C 1.8 x IR APPLIED (h)
125 000 150 000 250 000 300 000 375 000 500 000
Revision: 12-Dec-16
11
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
150 CRZ
Vishay BCcomponents
3.8
IA 3.7 IR 3.6
3.5 3.4 3.3 3.2 3.1 3.0
CCC206
2.8 Lifetime multiplier
2.6
1.0 1.52.0 3.0 4.0 6.0 8.012 2030
60100152000
2.4
2.2
2.0
IA = actual ripple current at 100 kHz
IR = rated ripple current at 100 kHz, 105 °C (1) Useful life at 105 °C and IR applied: see Table 8
1.8
1.6
1.4
1.2 1.0
(1)
0.8
0.5
0.0
40
50
60
70
80
90
100 110
Tamb (°C)
Fig. 15 – Multiplier of useful life as a function of ambient temperature and ripple current load
Table 9
MULTIPLIER OF RIPPLE CURRENT (IR) AS A FUNCTION OF FREQUENCY
FREQUENCY (Hz)
VR (V)
100
300
1000
3000
10 000
IR MULTIPLIER
6.3
0.70
0.80
0.85
0.93
0.95
10
0.70
0.80
0.85
0.93
0.95
16
0.70
0.80
0.85
0.93
0.95
25
0.70
0.80
0.85
0.93
0.95
35
0.65
0.80
0.85
0.93
0.95
50
0.60
0.75
0.85
0.93
0.95
63
0.60
0.75
0.85
0.93
0.95
80
0.60
0.75
0.85
0.93
0.95
100
0.60
0.75
0.85
0.93
0.95
30 000
0.97 0.97 0.97 0.97 0.97 0.97 0.97 0.97 0.97
100 000
1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00
Revision: 12-Dec-16
12
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
150 CRZ
Vishay BCcomponents
Table 10
TEST PROCEDURES AND REQUIREMENTS
NAME OF TEST
TEST REFERENCE
PROCEDURE (quick reference)
REQUIREMENTS
Mounting
IEC 60 384-18, subclause 4.3
Shall be performed prior to tests mentioned below; reflow soldering; for maximum temperature load refer to chapter “Mounting”
C/C: ± 5 % tan spec. limit IL2 spec. limit
Endurance
IEC 60384-18 / CECC32300, Tamb = 105 °C; UR applied;
subclause 4.15
for test duration see Table 8
UR = 6.3 V; C/C: ± 25 % UR 10 V; C/C: ± 20 % tan 2 x spec. limit
IL2 spec. limit
C/C: ± 30 %
Useful life
CECC 30301, subclause 1.8.1
Tamb = 105 °C; UR and IR applied; for test duration see Table 8
tan 3 x spec. limit IL2 spec. limit no short or open circuit total failure percentage: 1 %
Shelf life (storage at high temperature)
IEC 60 384-18 / CECC32 300, subclause 4.17
Tamb = 105 °C; no voltage applied; 1000 h
after test: UR to be applied for 30 min, 24 h to 48 h before measurement
For requirements see “Endurance test” above
Statements about product lifetime are based on calculations and internal testing. They should only be interpreted as estimations. Also due to external factors, the
lifetime in the field application may deviate from the calculated lifetime. In general, nothing stated herein shall be construed as a guarantee of durability.
Revision: 12-Dec-16
13
Document Number: 28395
For technical questions, contact: [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
www.vishay.com
Disclaimer
Legal Disclaimer Notice
Vishay
ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other disclosure relating to any product.
Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special, consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular purpose, non-infringement and merchantability.
Statements regarding the suitability of products for certain types of applications are based on Vishay’s knowledge of typical requirements that are often placed on Vishay products in generic applications. Such statements are not binding statements about the suitability of products for a particular application. It is the customer’s responsibility to validate that a particular product with the properties described in the product specification is suitable for use in a particular application. Parameters provided in datasheets and / or specifications may vary in different applications and performance may vary over time. All operating parameters, including typical parameters, must be validated for each customer application by the customer’s technical experts. Product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed therein.
Hyperlinks included in this datasheet may direct users to third-party websites. These links are provided as a convenience and for informational purposes only. Inclusion of these hyperlinks does not constitute an endorsement or an approval by Vishay of any of the products, services or opinions of the corporation, organization or individual associated with the third-party website. Vishay disclaims any and all liability and bears no responsibility for the accuracy, legality or content of the third-party website or for that of subsequent links.
Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining applications or for any other application in which the failure of the Vishay product could result in personal injury or death. Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk. Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for such applications.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or by any conduct of Vishay. Product names and markings noted herein may be trademarks of their respective owners.
© 2023 VISHAY INTERTECHNOLOGY, INC. ALL RIGHTS RESERVED
Revision: 01-Jan-2023
1
Document Number: 91000
Vishay Intertechnology: Passives & Discrete Semiconductors
