Installation Instructions
Warranty Information
For warranty detalls please contact your local representatlve or visit our website: www.anselluk.com
It is highly recommended that all Ansell luminaires are installed / maintained by a fully qualified electrician and wired in accordance to the latest IEC standards or national equivalent.
Mains power must be switched off during any installation or maintenance.
Should the product fail during the warranty period, Ansell will repair or replace the product in question.
Ansell do not accept any responsibility for any installation costs associated to the replacement of this product.
“Please Note – The warranty period shall be null and void in the following circumstances: Failure by the installer, end user or any third party to exercise caution to protect any covered product or part from outside damage, adverse temperature, humidity conditions, fluctuations in the electrical system or physical abuse as well as failure related to poor workmanship in the installation of the products or parts . Inability to provide correct product information. Any questions or concems with the product, please contact your local representative . ”
The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person.
The external flexible cable or cord of this luminaire cannot be replaced; if the cord is damaged, the luminaire shall be destroyed.
Product Code: [4L2/101_ Range]
PIR Settings
SPECIFICATION:
Power Source: 220-240V/AC
Power Frequency: 50/60Hz
Ambient Light: <3-2000LUX (adjustable)
Time Delay: Min.8sec+ 3sec
Max.10min+2min
Rated Load: Max.500W
Detection Moving Speed: 0.6-1.5m/s
Detection Range: 120°
Detection Distance : 3-10m (<24’C) adjustable
Working Temperature: -20~+40°C
Working Humidity: <93%RH
Power Consumption: approx 0.5W
Installation Height: 1.8-2.5m
Ansell Electrical Products
Unit 6B, Stonecross Industrial
Park,
Yew Tree Way,
Warrington,
WAS 3JD
Ansell (Sales & Distribution)
Unit 2 , M2 Business Park,
Duncrue Street,
Belfast,
BT3 9AQ
Ansell (Gales & Distribution) Republic of Ireland Limited
Unit G1, Block G,
Calmount Park, Calmount Avenue
Dublin 12,
D12 THS6
Warrington Tel: +44 (0/1942 433333 Betfast Tel: +44 (0)2890 773750 Intemational Tel: +44 (0)1942 433343 Spain Tek: 00 34 938 005642
