FRICO FC1P330 Tiger 2 15 kW Portable Fan Heater
This product is only suitable for well-insulated spaces or occasional use.
Wallbracket for storage of Tiger 2-15 kW
| Item number | Type | Cable | CEE |
| 3082 | P21 | 4G1,5x2m | CEE7 |
| 3083 | P31 | 3G1,5x2m | CEE7 |
| 3119 | P51 | 3G2,5x2m | – |
| 3118 | P33-0 | ||
| 3120 | P53-0 | 4G1,5x2m | CP 416-6 |
| 3121 | P93-0 | ||
| 3091 | P153 | 4G4x2m | CP 432-6 |
| 3084 | P3323 230V3~ | ||
| 3086 | P5323 230V3~ | ||
| 3088 | P9323 230V3~ | 4G2,5x2m | CP 332-9 |
| 10680 | P33 | ||
| 10681 | P53 | ||
| 10742 | P93 | ||
| 3085 | P33B | ||
| 3087 | P53B | ||
| 3089 | P93B | ||
Wiring diagram
Technical specifications
Fan heater Tiger, 2-9 kW
| Type | Output steps | Airflow | Sound level*1 | Dt*2 | Motor | Voltage | Amperage | HxWxD | Weight |
| [kW] | [m³/h] | [dB(A)] | [°C] | [W] | [V] | [A] | [mm] | [kg] | |
| P21*4 | 0/2 | 280 | 41 | 22 | 30 | 230V~ | 8.8 | 450x290x390 | 5.7 |
| P31 | 0/2/3 | 280 | 41 | 32 | 30 | 230V~ | 13 | 450x290x390 | 6.0 |
| P33 | 0/1.5/3 | 280 | 41 | 32 | 30 | 400V3N~*3 | 4.4 | 450x290x390 | 6.3 |
| P3323 | 0/1.5/3 | 280 | 41 | 32 | 30 | 230V3~ | 7.6 | 450x290x390 | 6.3 |
| P51 | 0/3.4/5 | 480 | 40 | 31 | 55 | 230V~ | 21.8 | 450x290x390 | 6.7 |
| P53 | 0/2.5/5 | 480 | 40 | 31 | 55 | 400V3N~*3 | 7.3 | 450x290x390 | 6.7 |
| P5323 | 0/2.5/5 | 480 | 41 | 31 | 55 | 230V3~ | 12.6 | 450x290x390 | 6.7 |
| P93 | 0/4.5/9 | 720 | 44 | 37 | 60 | 400V3N~*3 | 13 | 530x350x480 | 10 |
| P9323 | 0/4.5/9 | 720 | 44 | 32 | 60 | 230V3~ | 23 | 530x350x480 | 10
|
Fan heater Tiger, 15 kW
| Type | Output steps | Airflow | Sound level*1 | Dt*2 | Motor | Voltage | Amperage | HxWxD | Weight |
| [kW] | [m³/h] | [dB(A)] | [°C] | [W] | [V] | [A] | [mm] | [kg] | |
| P153 | 0/7.5/15 | 1120 | 47 | 40 | 80 | 400V3~ | 21.9 | 510x410x530 | 16 |
| P15323 | 0/7,5/15 | 1120 | 47 | 40 | 80 | 230V3~ | 38 | 510x410x530 | 16 |
- Conditions: Distance to the unit 3 meters. Directional factor: 2. Equivalent absorption area: 200 m².
- ∆t = temperature rise of passing air at maximum heat output and lowest/highest airflow.
- Also available without neutral and are then called P33-0, P53-0, and P93-0. These models do not have the 230V socket on the reverse and are equipped with P416-6 connectors.
- Also available as P21CH. P21CH is supplied with a plug for Switzerland.
- Technical specifications
- Airflow
- Motor
- Amperage
- Output steps
- Sound level
- Voltage
- Weight
