WIZAED 5MP 4X Bullet IP PTZ Camera
Model: ON-IPTZB555G-4X
Features:
- 1/3″ UHD CMOS sensor
- Solution: MC316DM+IMX335
- Max. 5MP resolution 2592 x 1944 output
- low illumination 0.1Lux
- Day/Night (ICR), AWB, 2D/3D-DNR, IR-CUT
- D-WDR, Motion Detection, Privacy Mask, Mirror, Flip
- RTSP and Onvif 2.6 compatible
- H.265/H.264 dual-stream media server
- Easy-to-use P2P Cloud service
- Multi web browser, PC Client, mobile APP remote access
- Optional customization Lens/Audio/POE, etc.
- Lightning protection 4000V
- Strong water-proof housing, IP66
- 6 pcs SMD Array IR Leds, IR distance 20-30 meters
- Network PTZ control , 4 times optical zoom
- HD 2.8 – 12 mm motorized lens
Technical Specifications:
| Model | ON-IPTZB555G-4X |
| Camera | |
| Image Sensor | 1/3″ CMOS SONY IMX335 + MC316DM |
| Effective Pixels | 5 megapixels |
| Electronic Shutter | AUTO |
| Min. Illumination | [email protected](AGC ON), 0Lux IR on |
| Day/Night | Auto/Color/(B/W)/Timing |
| WDR | Digital WDR |
| White Balance | Auto/Manual |
| AGC/BLC | Support |
| DNR | 2D/3D DNR |
| Other | Multi-lines OSD, Motion Detection, Privacy Mask, Mirror, Flip |
| Encode | |
| Video Standard | H.265/H.264 |
| Video Resolution | Main Stream: 15fps@5MP(2592×1944),25fps@4MP(2592×1520),25fps@3MP/1080P/720P Sub Stream: VGA(640×480)/360P/QVGA@25fps, etc. |
| Video Bitrates | 32Kbps – 8Mbps, VBR/CBR |
| Audio Standard | G.711-u/G.711-a |
| OSD Overlay | Title and Time overlay |
| IR Led | |
| IR Led | 6 pcs SMD array IR Led |
| IR Distance | 20-30 M |
| Lens | |
| Focal length | 2.8 -12 mm motorized lens |
| Zoom | 4x optical zoom |
| Optional Function | |
| POE, Audio, etc. | |
| PTZ | |
| Pan/Tilt Range | Pan: 0° ~ 180°; Tilt: 0° ~ 60° |
| Preset Point | 1 |
| Manual Control Speed | Pan: 0.5° ~20° /s; Tilt: 0.5° ~10° /s |
| Guard Position | Support |
| Power-off Recovery | Support |
| Network Services | |
| Protocol | HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc. |
| P2P | Yes |
| Web | IE , Firefox, etc. |
| Media | CMS, Android, IOS |
| ONVIF | 2.6 compatible |
| General | |
| Network Port | 1-RJ45, 100Mbps, POE : Internal type |
| Power Supply | 12 VDC ± 10% |
| Power Consumption | < 10 W |
| Operating Temp. | -20℃-(+60)℃, 10%-90%RH |
