Simpol Home Shl-p-120 5 Lights Pendant Light Instruction Manual

SHL-P-120 5 Lights Pendant Light

Product Information:

The product is a lighting fixture with the model number
SHL-P-120. The package includes a junction box, mounting bracket,
mounting screws, wires, wire nuts, and nuts for assembly. The
fixture requires electrical wiring and is designed to be connected
to a power supply.

Product Usage Instructions:

1. Before installation, ensure that the power supply is switched
   off and that all necessary safety precautions are taken.
2. Attach the mounting bracket to the desired location on the
   ceiling or wall using the provided mounting screws.
3. Connect the wires from the power supply to the wires of the
   fixture using wire nuts. Match the white wire from the power supply
   to the white or identified wire of the fixture. Match the black
   wire from the power supply to the black or neutral wire of the
   fixture. Connect the green or neutral wire from the power supply to
   the green wire of the fixture or to the grounding wire of the
   junction box.
4. Securely attach the fixture to the mounting bracket using the
   provided nuts.
5. Once installation is complete, switch on the power supply and
   test that the fixture is working properly.

If you encounter any issues during installation or usage of the
product, please contact [email protected] for assistance.

Dear Customer,

Assembly & Installation Instructions

SHL-P-120

Thanks for your purchase. If you have any problem about the product, please send an email to [email protected]. We will try our best to make you completely satisfied.

Best regards,

Customer Service Team

Assembly Steps

1.D.E

A

2.H.C

B

3.F.G

D

H

ALAMBRE DEL SUMINSTRO BLANCO
ALAMBRE DEL SUMINSTRO NEGRO
ALAMBRE DE TIERRA VERDE O NEUTRO DEL SUMINISTRO

ALAMBRE BLANCO O IDENTIFICADO
DE LA LAMPARA CONECTADOR UL CALIFICADO
ALAMBRE NEGRO
O NEUTRO DE LA LAMPARA
ALAMBRE DE TIERRA
VERDE O NEUTRO DE LA LAMPARA

O ALAMBRE DE TIERRA
VERDE O NEUTRO DEL SUMINISTRO

TORNILLO DE TIERRA VERDE

A B
C D
E

Parts included

Code Part Description QTY

F

A Junction box

0

B Wires Nuts

3

G

C Wires

2

D Mounting bracket

1

E Mounting screws

2

F Nuts

4

G Frame

1

H Wires

0
