CABSHELF1U2 1U 7 Inch Depth Rack Mount Shelf

Product Information

The 1U 7in Depth Rack Mount Shelf is a product designed to mount
server rack equipment. It has a weight capacity of 33 lbs (15 kg)
and comes in two models: CABSHELF1U and CABSHELF1U2. The product
includes front mounting brackets, a shelf surface, and a rear lip.
It requires one unit (1U) of mounting space on the rack and can be
installed using M6 cage nuts and screws.

Package Contents

1x 1U 7in Depth Rack Mount Shelf
Front Mounting Brackets
Shelf Surface
Rear Lip

Warnings!

Before using this product, it is important to read the entire
Quick-Start Guide and ensure that the instructions are fully
understood. Ensure that the product is properly mounted before
adding equipment to it. Do not operate the product if parts are
missing or damaged. Ensure that the weight of the equipment does
not exceed the weight capacity of the product to avoid personal
injury or damage to the equipment.

Regulatory Compliance and Warranty Information

This product is backed by a lifetime warranty. For further
information on product warranty terms and conditions, please refer
to www.startech.com/warranty. For regulatory compliance
information, please visit the StarTech.com website.

Product Usage Instructions

Installation

Find a suitable location on the rack to mount the Shelf. The
Shelf requires 1U of Mounting Space.
If the rack has M6 mounting threaded holes, skip this step.
Otherwise, install the M6 Cage Nuts into the Mounting Holes on the
Mounting Posts of the rack. Use a Cage Nut Tool or your preferred
installation method to install the Cage Nuts.
Place the Shelf onto the rack and align the Mounting Holes of
the Front Posts with the Mounting Holes of the Front Mounting
Brackets.
Use a Phillips Head Screwdriver to install the M6 Screws and
fasten the Front Mounting Brackets to the Front Posts of the rack.
Ensure the M6 Screws are properly tightened, and the Shelf is
secure before attempting to mount the Server Rack Equipment.

Requirements

For the latest manuals, product information, technical
specifications, and declarations of conformance, please visit:
www.StarTech.com/CABSHELF1U
www.StarTech.Tcomvi/eCwABmSaHnEuLaFl1sU, F2AQs, videos, drivers,
downloads, technical drawings, and more, visit
www.startech.com/support. To view manuals, FAQs, videos, drivers,
downloads, technical drawings, and more, visit
www.startech.com/support.

Note: The above URLs may not be valid as they are
fictitious.

View Fullscreen

Quick-Start Guide

1U 7in Depth Rack Mount Shelf – 33lbs / 15kg

Product Diagram
CABSHELF1U and CABSHELF1U2

*Product may vary from image

Component

Function

Front Mounting Brackets

· Used to fasten the Shelf to the Mounting Posts of the rack

2 Shelf Surface

· Mount Server Rack Equipment

3 Rear Lip

· Help prevent the Server Rack Equipment from falling off the Shelf

Package Contents
· 1U Rack Shelf x 1 · M6 Screws x 4 · M6 Square Cage Nuts x 4 · M6 Plastic Washers x 4 · Quick-Start Guide x 1

Warnings!
Read the entire Quick-Start Guide and ensure the instructions are fully understood before using this product.
Before adding equipment to this product, ensure this product has been properly mounted.
Never operate this product if parts are missing or damaged.
Ensure the weight of the equipment does not exceed the weight capacity of this product. If the weight capacity is exceeded, personal injury or damage to the equipment is possible. This product can support the following weight: 33 lb (15 kg).
Installation
1. Find a suitable location on the rack to mount the Shelf. The Shelf requires 1U of Mounting Space.
2. Install the M6 Cage Nuts into the Mounting Holes on the Mounting Posts of the rack. If available, use a Cage Nut Tool or your preferred installation method to install the Cage Nuts.
If the rack has M6 mounting threaded holes, skip this step as the M6 screws can be used directly
3. Place the Shelf onto the rack and Align the Mounting Holes of the Front Posts with the Mounting Holes of the Front Mounting Brackets.
4. Use a Phillips Head Screwdriver to install the M6 Screws and fasten the Front Mounting Brackets to the Front Posts of the rack. Ensure the M6 Screws are properly tightened, and the Shelf is secure before attempting to mount the Server Rack Equipment.

Requirements

For the latest manuals, product information, technical specifications, and declarations of conformance, please visit: www.StarTech.com/CABSHELF1U www.StarTech.Tcomvi/eCwABmSaHnEuLaFl1sU, F2AQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
· Refer to the manufacturer of the rack to determine the mounting hole type and size · Phillips head screwdriver · Cage nut tool (Optional)

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
